Eaton Crouse Hinds LED Explosion proof Lighting Guide

In harsh and hazardous environments such as petrochemicals, offshore platforms, mines, and wastewater treatment, lighting equipment must not only provide sufficient light, but also ensure absolute safety in the presence of explosive gases and dust. Eaton's Crouse Hinds series LED lighting products, with a century of explosion-proof experience and advanced LED technology, provide a full range of lighting solutions for industrial users worldwide, from hazardous areas to heavy industrial sites. This article is based on the official product manual and provides a comprehensive analysis of the technical characteristics, certification standards, selection points, and application scenarios of the Crouse Hinds series LED lighting fixtures, providing professional technical references for engineering designers, safety management personnel, and procurement experts.

Why choose LED? Why choose Crouse Hinds?

1.1 Advantages of LED Technology

Compared with traditional HID or fluorescent lamps, LED lighting has significant advantages in industrial applications:

Energy saving and efficient: The average energy consumption of LED is much lower than that of traditional light sources, with an energy-saving rate of up to 50% to 90%.

Instant start: No need to wait for a 10 minute restart time like HID lamps, it lights up when powered on.

Excellent light quality: Higher color rendering index (CRI), providing a more realistic visual environment.

Environmentally friendly and mercury free: free from harmful substances such as mercury, reducing disposal costs and minimizing carbon footprint.

1.2 Core advantages of Crouse Hinds series LED

Industry leading reliability: designed for harsh industrial environments and rigorously tested.

Excellent thermal management: Efficient heat dissipation structure ensures LED lifespan of over 60000 hours.

High quality optical design: Customize optical lenses to optimize light distribution and intensity.

Global certification: Meets both NEC (North America) and IEC (International) standards, and has multiple regional certifications.

Maintainability: Drivers and LED engines can be replaced on-site, extending the product lifecycle.

Product Selection Guide

The Crouse Hinds series LED products cover two major application scenarios: Hazardous Areas and Harsh/Heavy&Light Industrial.

2.1 Hazardous Area Selection Table (excerpt)

Application Product Series Equivalent Light Source Luminous Flux (lm) Environmental Temperature Emergency Battery Options

Projection lamp CEAG PXLED 70W-600W HID 5000-30000-50 ° C to+55 ° C-

High/Medium Ceiling Light Hazard Gad EVLLA 100W-400W HID 6200-13000-25 ° C to+65 ° C-

Linear lamp Hazard Gad XPLA/ZPLA 2 lamp T5HO 3800-8300-25 ° C to+55 ° C ✔

Linear lamp CEAG ExLin 2x18W/2x36W/2x58W fluorescent 2900-11200-40 ° C to+55 ° C ✔

2.2 Heavy Industry/Light Industry Selection Table (excerpt)

Application Product Series Equivalent Light Source Luminous Flux (lm) Environmental Temperature Emergency Battery Options

Projection lamp Champ Pro PFMA 70W-1500W HID 3400-50500-40 ° C to+65 ° C-

High ceiling lamp Champ Intelligent PVML 70W-175W HID 3000-7000-40 ° C to+65 ° C ✔

Linear lamp Pauluhn APEX 3-6 lamp T5HO 13000-25000-40 ° C to+55 ° C-

Low ceiling lamp Vaporgard Pro P2L/P3L 100W-200W incandescent lamp 1700-3300-30 ° C to+55 ° C-

Detailed explanation of LED lighting products in hazardous areas

3.1 Champ FMVA LED floodlight

Main applications: Lighting for indoor and outdoor areas such as manufacturing factories, heavy industry chemical and petrochemical facilities, platforms, loading and unloading areas, parking lots, etc.

Model and equivalent light source:

FMVA-3：70W HID

FMVA-5：100W HID

FMVA-7：175W HID

FMVA-9：250W HID

FMVA-11：320W HID

FMVA-13：400W HID

FMVA-15：500W HID

FMVA20L：600W-750W HID

FMVA25L：750W-1,000W HID

FMVA40L/50L：1,500W+ HID

Certification and Compliance:

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2 (20L-50L models)

Class II, Division 1, Groups E, F, G

Type 4X, IP66

UL844, UL1598, UL1598A, UL8750

CSA C22.2 No.137

Electrical parameters:

Voltage: 100-277 VAC/125-250 VDC, 347-480 VAC

Input power: 31W~400W (depending on model)

Design features:

Durable heat sink design, suitable for ambient temperatures ranging from -40 ° C to+65 ° C

Up to 162 lm/W light efficiency

Full frame yoke, compatible with SFA6 sliding joint and SWB6 wall mount bracket

Multiple lens options: tempered transparent glass, polycarbonate, diffuse glass

Drivers and LED engines can be replaced on-site (FMVA-9 to FMVA-15)

3.2 Champ VMVL LED Intelligent Lighting Fixture

Main applications: Places that require continuous and stable lighting under extreme environmental temperatures, such as manufacturing factories, heavy industry/petrochemical facilities, food and beverage factories, tunnels, outdoor wall and column lighting areas.

Model: VMVL-3 to VMVL-25, equivalent HID 70W to 1000W.

Certification

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2 nA； Zone 21 tb

Class II, Division 1, Groups E, F, G

Type 4X, IP66

UL844, UL1598, UL1598A, UL8750

IECEx/ATEX Zone 2/21

Electrical parameters: Input power of 28W~199W, voltage of 100-277 VAC/127-250 VDC or 347-480 VAC.
