NI SCXI-1349 Adapter Connection Guide

来源: | 作者:FAN | 发布时间 :2026-04-10 | 19 次浏览: | 🔊 Click to read aloud ❚❚ ▶ | Share:

Confirm that the SCXI chassis power is turned on and the power indicator light is on.

Refresh the device list in MAX and check if SCXI chassis and modules are detected.

Check if the connection between SCXI-1349 and the module is fully inserted and if the screws are tightened.

Check if the connection at both ends of the 68 pin cable is secure and if there is any obvious damage to the cable.

Confirm that the SCXI module used is not a switch module (not supported by SCXI-1349).

Try replacing the known good 68 pin cable for testing.
