GE PACSystems RX7i power module (IC698PSA100/350 series)

Noise protection: Ensure that the power supply installation screws are tightened and grounded according to specifications; The RX7i power module has noise reduction pads on both sides, which need to be in contact with adjacent modules/racks. Modules without pads will increase the sensitivity of the system to electromagnetic noise.

2. Safety Warning

When the input power is turned on, there is a lethal voltage inside the module. It is forbidden to plug and unplug the module with power on, otherwise it may cause personal injury, module damage, or system loss of control;

When used in Class I Zone 2 hazardous environments, it is necessary to comply with: only applicable to Class I Zone 2 A/B/C/D hazardous areas or non hazardous areas; Prohibit replacing components (which may affect explosion-proof applicability); It is prohibited to disconnect equipment before power outage or confirming the safety of the area.

Order Information

In addition to the power module, the matching fan tray should be selected according to the rack specifications and power supply type. The specific models are as follows:

Product Description Product Model

RX7i 100W power module (85-264VAC/100-150VDC input) IC698PSA100

RX7i 350W power module (85-264VAC/100-150VDC input) IC698PSA350

17 slot rack 120VAC input fan component IC697ACC721

17 slot rack 240VAC input fan assembly IC697ACC724

17 slot rack 24VDC input fan component IC697ACC744

9-slot rack 120VAC input fan component IC697ACC621

9-slot rack 240VAC input fan assembly IC697ACC624

9-slot rack 24VDC input fan component IC697ACC644
