Detailed explanation of core product categories

（1） Industrial connectors

1. Circular connector (core specifications: M12/M16/M23)

Specification, Model, Code Type, Number of Cores, Rated Current (A), Rated Voltage (V), Protection Level, Installation Method, Material (Shell/Contact), Applicable Scenarios, Packaging Specifications

M12 A/B/D 2-12 2-8 250-600 IP67/IP68 straight/elbow PA66/brass (gold-plated) sensor, encoder connection 10 pieces/pack

M16-4-8 5-10 600 IP67/IP69K panel installation PA66/brass (nickel plated) industrial motor, valve 10 pieces/pack

M23-12-24 10 600 IP67 cable installation PA66/copper alloy (tin plated) servo motor, PLC 5 pieces/pack

7/8 "-3-6 10 250 IP67 quick plug PA66/brass (nickel plated) pneumatic equipment, sensors 10 pieces/pack

2. Rectangular connector (focusing on indoor/outdoor dual scenarios)

Indoor type (IP20):

Specification: 10-64 cores, 2-10P, spacing 3.81mm/5.08mm

Features: Equipped with anti misoperation lock buckle, supporting modular splicing, compatible with PCB board and terminal block connection

Typical model: RS-2324 (16 core, IP20， 10 pieces/pack)

Outdoor type (IP65):

Specification: 12-48 cores, single/double-layer design

Features: Waterproof sealing ring, weather resistant PA shell, suitable for outdoor control cabinets

Typical model: RS-6536 (36 cores, IP65， 5 pieces/pack)

3. Heavy duty connector (for heavy equipment)

Core parameters:

Core count range: 10-240 cores (single/double-layer structure)

Electrical performance: rated current 10-25A, rated voltage 690V, insulation resistance ≥ 100M Ω

Protection level: IP65/IP67, impact resistance 1000g (1ms)

Material and Craftsmanship:

Shell: PC material (temperature resistance -40...+120 ° C)

Contact: Copper alloy (tin plated), contact resistance ≤ 10m Ω

Applicable scenarios: Rail transit vehicles, heavy machinery, wind power equipment

Typical model: RS-HD120 (120 cores, IP67， 2 pieces/pack)

（2） Cable management products

1. Cable ties and fixing bases

Product Type Material Width (mm) Length (mm) Temperature Range (° C) Special Characteristics Applicable Scenarios Packaging Specifications

Standard cable tie nylon 66 2.5-12 100-1000-40...+105 tensile strength 50-200N indoor cable sorting 100 pieces/pack

Loose zip ties nylon 66 3.6-8 150-500-40...+105, removable, temporary wiring, equipment maintenance 50 pieces/pack

Fireproof zip ties nylon 66 (UL94 V0) 4.8-12 200-800-40...+125 flame retardant, low smoke and halogen-free distribution box, fire equipment 50 pieces/pack

Adhesive fixed seat PA66 compatible zip tie width -40...+80 3M adhesive without screws installation scenario 20 pieces/pack

Screw fixed seat PA66 compatible zip tie width -40...+105 compatible M3-M5 screw metal cabinet, equipment shell 20 pieces/pack

2. Cable protection hose and connector

Protective hose:

PA material hose: inner diameter 6-50mm, temperature resistance -40...+125 ° C, bending radius 50-200mm, UV resistant (UV stable), suitable for outdoor cable protection

PP material hose: inner diameter 8-32mm, temperature resistance -20...+80 ° C, lightweight, suitable for indoor lightweight cables

Typical model: RS-PA20 (inner diameter 20mm, PA material, 10m/roll)

Connector:

Type: Quick fit (compatible with PA hoses), threaded (M12-M20, compatible with PP hoses)

Protection level: IP68, resistant to oil and chemical corrosion

Suitable for hose inner diameter: 6-50mm, 10 pieces per pack

3. Cable identification and conduit

Identification card:

Material: paper (indoor), plastic (temperature resistant -20...+80 ° C, outdoor)

Size: 25 × 12mm, 30 × 15mm, supports laser/inkjet printers

Packaging: 100 sheets/pack

Heat shrinkable sleeve:

Material: PE, shrinkage ratio 2:1, temperature resistance -55...+125 ° C

Diameter: 2-50mm, color black/red/blue/yellow

Packaging: 10m/roll

（3） Wiring terminals and accessories

1. Wiring terminal (screw/spring connection dual type)

Connection type nominal cross-sectional area (mm ²) rated current (A) rated voltage (V) protection level shell material conductive material installation method packaging specifications

Screw connection 3.5-35 10-125 600-1000 IP20 PA66 brass (tin plated) DIN rail 20 pieces/pack

Spring connection 2.5-10 10-32 600 IP20 PA66 brass (tin plated) DIN rail 20 pieces/pack

Fence terminal 1.5-25 8-80 600 IP20 PA66 brass (nickel plated) panel installation 15 pieces/pack

2. Terminal block and DIN rail

Terminal block:

Number of digits: 10-40, compatible with 35mm standard DIN rail

Features: With partition board, supports jumper connection, current capacity matches terminal

Typical model: RS-TB20 (20 bits, compatible with 10mm ² terminals, 10 pieces/pack)

DIN rail:

Steel guide rail: 35 × 15mm, thickness 1.5mm, current carrying capacity 125A/m, 2m/piece, 10 pieces/pack

Aluminum guide rail: 35 × 7.5mm, thickness 1.2mm, lightweight, 2m/piece, 10 pieces/pack

3. Terminal accessories

Marking strip: paper/plastic material, size 5 × 8mm, 10 × 12mm, compatible terminal spacing, 100 strips/pack

Jumper: 2-4 channels, compatible with screw/spring terminals, copper material (tin plated), 20 pieces/pack

End plate: PA66 material, used for protection at both ends of the terminal block to prevent accidental contact, 50 pieces/pack
