Product Description P/N: DS3820DIMC DESCRIPTION / SPECIFICATIONS Description The DS3820DIMC is a Datatronics Isolation Module from General Electric, used within the Mark IV Speedtronic turbine control system. This module provides isolation between wetting power and core control power, protecting against power surges and dips. It is mounted on a metal carrier with two screw connections. The board features two large components for additional connections, with one component vertically placed and housing further components within its hollow core. Additional components include TP test points, jumper switches, resistors, variable resistors, capacitors, and diodes.

Each component is marked with a reference designation or manufacturer code for further information Technical Specifications Part Number DS3820DIMC Manufacturer General Electric Series Mark IV Product Type Datatronics Isolation Module Power Requirements #ERROR! Power Supply Voltage 24 V DC Operating Temperature -40 to +65掳C Size 15.7 cm high x 18.5 cm Weight 0.5 kg Information About DS3820DIMC The General Electric DS3820DIMC is a specialized Datatronics Isolation Module designed as part of the Mark IV series, a well-established line of control systems known for their reliability and precision in industrial applications. This module plays a crucial role in isolating and protecting critical data and signal pathways within complex control environments, ensuring that sensitive electronic components are shielded from electrical noise, interference, and other potential disturbances that could compromise system integrity.

 Manufactured by General Electric, a leader in industrial automation and control technology, the DS3820DIMC is engineered to meet the high standards required for modern industrial operations. Its primary function as an isolation module is to maintain the integrity of data transmission by isolating different parts of the system, thereby preventing the transmission of unwanted electrical noise or interference that could lead to data corruption or system malfunctions. This capability is particularly important in environments where multiple signals and data streams must be managed concurrently without cross-contamination. The DS3820DIMC operates within a power supply voltage of 24 V DC, ensuring compatibility with standard industrial power systems. This voltage level is common in control environments, making the module easy to integrate into existing systems without requiring significant modifications.

The module鈥檚 power requirements are designed to be efficient, minimizing energy consumption while providing the necessary isolation and protection for sensitive data pathways. One of the key features of the DS3820DIMC is its ability to operate within a wide temperature range, from -40 to +65掳C. This broad operating temperature range highlights the module鈥檚 robust design, allowing it to function reliably in a variety of challenging industrial conditions, including extreme cold and heat. This versatility ensures that the module can be deployed in diverse environments, from outdoor installations in harsh climates to high-temperature industrial processes. The DS3820DIMC is compact in size, measuring 15.7 cm in height and 18.5 cm in width, with a weight of 0.5 kg. This compact design makes the module easy to install within control cabinets or other confined spaces, while its lightweight construction simplifies handling during installation and maintenance.

Despite its compact size, the module is built to provide robust isolation capabilities, ensuring that it delivers reliable performance over extended periods of use. As part of the Mark IV series, the DS3820DIMC is designed to integrate seamlessly with other components within the series, providing a cohesive solution for complex control systems. The Mark IV series is well-regarded for its modularity and flexibility, allowing users to build and customize control systems that meet specific operational requirements. The DS3820DIMC contributes to this flexibility by offering a reliable means of data and signal isolation, enhancing the overall performance and stability of the control system. In summary, the General Electric DS3820DIMC Datatronics Isolation Module is a highly reliable and efficient solution for managing data and signal isolation within the Mark IV series of industrial control systems. Its 24 V DC power supply voltage, wide operating temperature range, and compact design make it a versatile choice for a variety of industrial applications.

The module鈥檚 robust construction ensures that it can withstand the demands of harsh industrial environments, providing long-term reliability and protection for critical data pathways. Whether used in new installations or as part of an upgrade to existing systems, the DS3820DIMC delivers the performance and dependability needed to support complex industrial operations, making it an essential component for maintaining the integrity and efficiency of modern control systems. Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power.
