EMERSON KJ3203X1-BA2 13P0085X022 Dry Contact Card

EMERSON  KJ3203X1-BA2 13P0085X022 Dry  Contact Card

Power Specifications

Local Bus Power：12 VDC at 75 mA

Bussed Field Power：24 VDC at 150 mA

Field Circuit：24 VDC at 5 mA/Channel

Environmental Specifications

Ambient Temperature：-40°C to +70°C

Shock：10g ½ Sinewave for 11msec

Vibration：1mm Peak to Peak from 2 to 13.2Hz; 0.7g from 13.2 to 150Hz

Airborne Contaminants：ISA-S71.04 –1985 Airborne Contaminants Class G3

Relative Humidity：5 to 95% Non-Condensing

Terminal Block key Position：B3

Removal and Insertion

Field power supplied to this device, either at the field terminal or as bussed field power through the Carrier, must be removed before removing or connecting the device.

This unit cannot be removed or inserted with system power energized

A rotary keying system ensures compatibility between I/O cards and terminal blocks after installation is complete. The terminal block must have the keys set for the I/O card with which it is used.

Maintenance and Adjustment

This unit contains no user serviceable parts and should not be disassembled for any reason. Calibration is not required.
