PROMESS 850040060P Force Displacement Monitor

The PROMESS 850040060P is a high-precision force and displacement monitoring module engineered for press-fit, riveting, and general assembly processes. It provides real-time acquisition of force vs. position data, enabling statistical process control and 100% in-process verification. The module is widely used in automotive, electronics, and medical device manufacturing to detect assembly defects such as missing parts, incorrect seating, or material variations.

Press Monitoring Functionality

The 850040060P captures force and displacement simultaneously, generating a real-time curve that is compared to a reference master curve. User-defined tolerance bands (e.g., envelope, window, or multi-point) detect deviations caused by part absence, incorrect part orientation, excessive press force, or insufficient travel. The module outputs a pass/fail signal and can store curves for later analysis. It supports both single-stroke and automated assembly lines.

Integration and Configuration

The device is configured via a front-panel touchscreen or PC software. It allows programming of up to 100 different assembly jobs (recipes) with independent tolerance parameters. The unit includes a built-in web server for remote monitoring and data retrieval. For integration with PLCs, it provides Ethernet/IP and Profibus interfaces, allowing the host controller to read pass/fail results and trigger the next cycle.

Application Domains

This monitor is essential for press-fit assembly of bearings, bushings, gears, and electrical contacts. It is used in automotive powertrain assembly, electric motor manufacturing, medical device assembly, and consumer electronics production. The 850040060P helps reduce scrap and ensures compliance with quality standards such as IATF 16949.
