Pro-Face PL5901-T42-24V HMI Touch Panel
The Pro-Face PL5901-T42-24V is a rugged industrial human-machine interface (HMI) with a 5.7-inch STN color LCD and analog resistive touch screen. It is designed for machine control, process monitoring, and data entry applications in manufacturing, packaging, and building automation. The panel offers a bright display with wide viewing angles and multiple connectivity options for PLCs and drives.
Technical Specifications
Display Size: 5.7 inches diagonal
Display Type: STN color LCD (256 colors)
Resolution: 320 × 240 pixels (QVGA)
Backlight: CCFL, 50,000 hours typical life
Touch Technology: Resistive analog, 4-wire
CPU: 32-bit RISC (200 MHz)
Memory: 4 MB flash (application storage), 1 MB SRAM
Communication Ports: 2 × RS-232C, 1 × RS-422/485, 1 × Ethernet 10Base-T
Protocols: Modbus RTU/TCP, Mitsubishi, Omron, Siemens, Allen-Bradley (native drivers)
Power Supply: 24 V DC (18-30 V), 15 W max
Operating Temperature: 0°C to +50°C
Protection Rating: IP65 (front panel), IP20 (rear)
Dimensions: 185 × 135 × 50 mm
Mounting: Panel cutout: 168 × 128 mm
HMI Software and Features
The PL5901-T42-24V is programmed using Pro-Face's GP-Pro EX software (version 3.0 or later). The software supports creation of screens with buttons, numeric entry, trend graphs, alarms, recipes, and data logging. The panel includes a real-time clock and battery-backed SRAM for data retention. It can also be configured as a Modbus TCP server to allow external SCADA access to screen data.
Connectivity and Integration
The unit can simultaneously connect to multiple PLCs via different ports (e.g., Ethernet to a Rockwell PLC and RS-232 to a VFD). It supports up to 16 devices with separate communication protocols. The built-in Ethernet port also enables remote monitoring via web server (optional) and firmware updates.
Application Domains
This HMI is commonly used in packaging lines, conveyor systems, injection molding machines, and HVAC control panels. Its compact size and rugged construction make it suitable for both OEM equipment and retrofit projects.
