Foxboro I/A Series Compact 200 16 Slot Horizontal Substrate (31H2C480B4)

Support redundant communication links (with the cooperation of the controller). When the main communication link fails, the backup link will automatically switch to ensure that data is not lost.

（3） Fault diagnosis and maintenance convenience

Status indication:

The front of the substrate is equipped with LED indicator lights, including a "power status light" (main/backup power, green constant light indicates normal, red flashing indicates fault), a "bus status light" (yellow constant light indicates normal, off indicates bus interruption), and a "module fault summary light" (red light indicates any slot module fault), which facilitate quick judgment of the system status;

Module hot plug support:

All 16 slots support "hot swappable" (the module itself needs to have a hot swappable design). When replacing the I/O module, there is no need to disconnect the power supply or communication cable of the substrate. Simply unlock the module buckle to plug and unplug, reducing maintenance downtime;

Fault isolation:

A single slot is equipped with an independent fault isolation circuit. When a certain I/O module fails, the substrate automatically cuts off the abnormal signal between the slot and the bus to prevent the fault from spreading to other modules or higher-level controllers.

（4） Environmental protection and durability

Anti pollution capability: meets the G3 level (harsh) environmental requirements of ISA standard S71.04, can withstand industrial dust, oil and gas, corrosive gases (such as hydrogen sulfide), and the substrate surface is coated with anti-corrosion coating (such as epoxy resin) to extend its service life;

Resistance to vibration and impact:

Vibration protection: Within the frequency range of 5-500Hz, it can withstand a sine vibration of 7.5m/S ² (0.75g), meeting the installation requirements near vibration sources such as pumps and compressors;

Impact protection: capable of withstanding a 15g (half sine wave, duration of 11ms) impact, suitable for the impact environment of industrial equipment transportation and on-site installation;

Temperature adaptability: Operating temperature range -20 ° C to+60 ° C, storage temperature range -40 ° C to+85 ° C, suitable for most industrial scenarios (such as chemical workshops, outdoor control cabinets).

Detailed explanation of technical specifications

（1） Electrical specifications

Specification category parameter details

Power input voltage: 24V DC (redundant dual input); Voltage fluctuation range:+5%/-10%; Maximum input current: 10A (total power consumption varies with the number of modules)

Maximum output current of a single slot for power distribution: 1A; power bus voltage drop: ≤ 0.5V (at full load)

Signal bus type: differential signal bus; Transmission rate: ≥ 1Mbps; Signal delay: ≤ 10ms

Isolation performance power signal isolation: 500V AC/1 minute; Slot isolation: 600V AC/1 minute

Overcurrent protection single slot overcurrent protection threshold: 1.5A (self resetting, automatically restoring power supply after troubleshooting)

（2） Mechanical and Environmental Specifications

Specification category parameter details

Dimensions and Length: 483mm (19 inches); Height: 130mm; Depth: 150mm; Weight: Approximately 1.8kg (excluding modules)

Installation method: 19 inch cabinet installation (requires bracket), 35mm DIN rail installation (EN 60715)

Working temperature -20 ° C to+60 ° C (non condensing)

Storage temperature -40 ° C to+85 ° C (non condensing)

Working humidity 5% -95% RH (non condensing, temperature ≤ 40 ° C)

Anti vibration of 5-500Hz, 7.5m/S ² (0.75g), in compliance with IEC 60068-2-6 standard

15g shock resistance (half sine wave, 11ms), in compliance with IEC 60068-2-27 standard

（3） Compliance certification

Electromagnetic compatibility (EMC): complies with the EU EMC Directive (2014/30/EU), meets the Class A emission requirements (industrial environment electromagnetic radiation control) and industrial immunity level (anti-static discharge, radio frequency interference, electrical fast transient pulse group) of EN 61326-1:2013 standard;

Security certification:

UL/UL-C certification: suitable for hazardous environments with Class I A-D groups, Zone 2, T4 temperature codes (requires Foxboro I/A Series certified controllers and modules);

ATEX certification: Ex nA IIC T4 Ga, suitable for Zone 2 hazardous environments (such as chemical explosion risk areas);

IECEx certification: compliant with IEC 60079-15 standard, supporting global hazardous area applications;

Environmental compliance: Compliant with the EU RoHS Directive (2011/65/EU), restricting the use of harmful substances such as lead, mercury, cadmium, etc;

Marine certification: Some models have been certified by American Bureau of Shipping (ABS) and Bureau Veritas, meeting the environmental and safety requirements of marine environments such as ship power systems and offshore oil platforms.

Supporting components and reference documents

（1） Key supporting components

Component type, model/specification, core function

The redundant power module is compatible with the Compact 200 series (such as relevant RH models) to provide dual 24V DC redundant power input for the substrate, ensuring power reliability
