General

The programming and test software 907 PC 33 serves to create programs for the ABB Procontic T200, ABB Procontic CS31 and Advant Controller 31 programmable logic controllers (PLCs). An installation program that functions largely automatically installs the software package on the PC.

Features

The scope of features and functions listed depends on individual PLCs’ capabilities.

Menu prompting

● Modern, clearly–arranged menu interface employing pop–up menus

● Color display

● Fast selection of menu options by mouse or on the keyboard

● Calls of external programs at the DOS level directly from the menu (DOS shell) Path information

● Input of a file name with the affiliated DOS path

● Display of the project overview in a file directory Password protection

● Several access privilege levels Modularization

● Handling of large projects

● Arrangement of projects in logical structures

● Subdivision into program and variable modules FBD/LD editor

● Uniform editor for programming with graphic symbols as a function block diagram and as a ladder diagram

● Connection of ladder diagram networks with elements of the function block diagram Extended IL editor

● Notation with symbols and long text in various forms

● Cursor control by mouse

● Selection of connection elements via a selection menu and using a mouse Variable editor

● Complete list of all entered variables

● Selectable sorting according to absolute or symbolic variables

● Adoption and transfer of variable lists from and to any chosen word processing systems

● Provision and adoption of variable lists for specific CAD/CAE systems

The programming and test software 907 PC 33 is executable on:

● at least 4 Mbyte RAM for optimum performance

● Hard disk drive

● Diskette drive, 3 1/2”, 1.44 MB

● EIA RS–232 serial interface for the PLC system

● Parallel or second serial interface for printer

● MS–DOS operating system V5.0 or higher

● Optionally a mouse for fast cursor control

The programming and test software 907 PC 33 permits simple and economical programming of PLC programs in the following notations:

● Function block diagram (FBD)

● Ladder diagram (LD)

● Instruction list (IL)
