EATON ELPRO 245U-E series industrial wireless Ethernet products

environmental adaptability

Working temperature: -40 to+60 ℃;

Humidity: 0-99% RH (non condensing);

Shell: Powder coated aluminum alloy, supporting DIN rail installation;

Size: 114 x 140 x 30 mm, weight<0.5kg.

Network Security and Bandwidth Management

The 245U-E series provides multiple layers of security mechanisms:

Data encryption: supports 64/128 bit WEP, WPA2-PSK, 802.11i, 802.1x;

Access control: MAC address whitelist/blacklist, IP filtering, ARP filtering;

Web management encryption: Supports HTTPS access to prevent configuration information leakage.

In addition, the device supports broadcast/control mode selection, point-to-point/point to multipoint communication, WDS relay, Modbus gateway, serial multicast and other functions to meet the requirements of complex industrial networks.

Diagnosis and maintenance

The equipment provides comprehensive diagnostic tools:

LED indicator lights: power, receive/send, link status, serial port activity, I/O status;

Remote diagnosis: RSSI measurement, connection statistics, system logs;

Configuration method: Built in web server, supports HTTP/HTTPS access, simplifies the setup process.

Compliance and Certification

The 245U-E series complies with multiple international standards:

EMC：EN 301 489-17，FCC Part 15；

Radio: EN 300 328, FCC Part 15.247, RSS 210;

Safety: EN 60950, CSA Class I Division 2 (pending approval);

Environment: RoHS compliant.
