Communication failure (EGD/Modbus)

Check Ethernet physical connection and switch configuration

Confirm if the IP address, port, and data mapping table are correct

Monitor UDH status words using ToolboxST

PT disconnection false alarm

Verify PT secondary circuit wiring and insurance

Confirm PTFD parameter settings (such as detection threshold, delay)

If the generator is not connected to the grid, the PTFD function can be temporarily disabled, but it needs to be restored before grid connection

Frequent overexcitation restriction actions

Check if the actual excitation current exceeds the OEL curve setting

Verify the calculation of generator magnetic field temperature (through field voltage/current ratio)

If the system operates at the edge of strong excitation for a long time, it should be considered to increase the OEL setting value or improve reactive power balance

V/Hz protection tripping

Check the frequency change rate during the start stop process of the unit

Adjust the setting value of the V/Hz limiter (typically 1.05~1.10 p.u.)

Attention: At the moment of load shedding or disconnection of the unit, V/Hz may exceed the limit instantaneously, and a reasonable delay should be set to avoid false tripping

Dynamic discharge (DD) resistor frequently activated

Check if the DC bus voltage frequently exceeds the set threshold

Confirm whether the DC contactor in the demagnetization circuit is opening and closing normally

Assess whether there are frequent demagnetization operations or load fluctuations on site

4.3 Spare parts management and lifecycle

Due to the fact that EX2100e is based on IGBT technology (fourth generation), compared to old-fashioned SCR excitation, its power module has a longer lifespan and lower maintenance requirements

Suggest keeping key spare parts on hand: one PCM, one ESYS board, one UCSB controller, and one set of DD resistors

Regularly (every 5 years) conduct capacity tests on the DC bus capacitor and replace it if necessary

4.4 Interface precautions with old systems in renovation projects

If the original excitation system uses PMG power supply, confirm that the PMG frequency is compatible with EX2100e (≤ 480Hz)

If the original system uses a DC battery as a backup power source, the voltage should be within the range of 125-250V dc

For SCT/PPT excitation mode, EX2100e can directly replace the original SCR control cabinet, but the excitation transformer parameters need to be reconfigured

Communication with DCS: It is recommended to use Modbus TCP, and address mapping can be customized through ToolboxST

Technical Specification Quick Reference Table

Project 35A System 120A System

Main AC input range: 90-280V rms, maximum 480V rms

Input frequency ≤ 480Hz ≤ 480Hz

DC backup input 125-250V DC 125-250V DC

Rated output 250V DC/35A 250V DC/120A

Strong motivation ability 210% (73.5A) 210% (252A)

IGBT switching frequency is approximately 1000Hz

Control cabinet size 610/800mm wide, optional 800mm wide

Protection level IP20/IP21 (optional IP54) IP20/IP21 (optional IP54)

Environmental temperature 0~40 ℃ (50 ℃ derating) 0~40 ℃ (50 ℃ derating)

Applicable standards UL508C, CSA22.2, EN50178, IEEE421 series are the same as the left
