Keyence CV-3000 Visual System Selection

The camera cooling fan (if any) needs to be regularly dusted.

CF card lifespan management:

CF cards have a write life of approximately 100000 times. Avoid writing every image into the card during regular operation, only save NG images.

When there is a save failure or formatting exception, a new card should be replaced in a timely manner.

Battery replacement:

The internal lithium battery of the controller is used to maintain SRAM data and clock. The battery life is specified in the technical specifications, and it is recommended to replace it every 5 years. The replacement needs to be carried out by an authorized service provider.

Practical cases of maximizing performance

Case: Character detection of mobile phone shell (high-speed line)

Requirement: Check for missing characters in laser engraving at a speed of 200 characters per minute.

Configuration: CV-3502P+CV-035C camera+coaxial light.

Problem: The initial use of full frame images (656 × 492) resulted in a processing time of 28ms, exceeding the beat.

Solution: Enable partial reading function, only capture ROI area containing characters (200 × 150). Simultaneously narrow down the search range to the vicinity of the character position in the previous image. Reduce the processing time to 12ms.

Extra benefit: Utilize statistical functions to monitor the standard deviation of character position X coordinate and promptly detect mechanical vibration anomalies.

Case: Multi camera detection of tablet packaging

Requirement: Four cameras are required to detect aluminum foil sealing, tablet color, batch number, and missing particles.

Configuration: CV-3502P+CV-E300 expansion unit+4 CV-035C color cameras.

Key setting: Use separate trigger inputs to avoid power surges caused by simultaneous triggering. Each camera uses independent gating light output to light up their respective light sources at the moment of exposure, avoiding mutual interference.

Debugging tip: Use the "batch retest" function to retest hundreds of saved NG images and quickly optimize the threshold of each window.
