Pacific Scientific 6410 Stepper Driver

Application Fields and Selection Suggestions

6410 stepper driver is typically used for:

X-Y worktable and slide table

Packaging machinery (labeling machine, sealing and cutting machine)

Robots (material handling, assembly)

Specialized machine tools (engraving, winding)

Fixed length feeding device

Labeling Machine

Attention should be paid when selecting: the rated current of the motor winding must match the output current of the driver; The higher the power supply voltage, the better the high-speed torque performance, but it must not exceed 75V; for high-speed operation, a higher-level controller that can generate acceleration and deceleration slopes must be used (otherwise the risk of stepping out is extremely high); It is recommended to refer to the torque speed curve in Pacific Science's "Motion Control Solution Catalog" during initial design, or contact local distributors for motor selection support.

Maintenance and repair

The daily maintenance of the 6410 drive only requires regular cleaning of surface dust with dry low-pressure compressed air. If you suspect that the drive is damaged, do not replace it directly and then turn it on. Instead, first review whether the power supply design is compliant (especially whether the voltage exceeds 75V), as this is the most common cause of damage. If repair is required, an RMA (Return Merchandise Authorization) number must be obtained from Pacific Science, the drive must be placed in its original packaging box, and sent to: Pacific Scientific Motion Technology Division, 110 Fordham Road, Wilmington, MA 01887, Attn: Repair Department。 Attention: Motor repairs should be sent to the Motor Products Division in Rockford and should not be confused.
