ROSS Pneumatic Valve Full Series

Dale series: Direct acting lift valves (2/2, 3/2), suitable for high flow, harsh environments, with manual reset option.

21 series: Metal lift valve, suitable for high/low temperature (-40 ° C to 150 ° C) and vacuum applications.

95 series: Compact spool valve, 1/8 "-1/2", Cv 0.9-4.5, extremely low power consumption (2.5 W DC).

SAE 80/84 series: Complies with SAE standards in the automotive industry and comes with various in car connectors.

AIR‑FUSE ®： Flow diffuser, automatically reduces flow when hose ruptures to prevent whipping, in compliance with OSHA requirements.

Foot operated valve, manual valve, mechanical valve: multiple operating modes.

Attachments and selection precautions

Electrical connector: DIN 43650 Form A/C or M12, with optional indicator lights.

Muffler: Standard brass or stainless steel, high flow noise reduction type.

Pressure switch: used for downstream pressure monitoring or status indication.

Pre installed cable kit: includes J-Box or multi pin cables to simplify wiring.

Material compatibility: Avoid using lubricating oil containing phosphate ester additives to prevent damage to polyurethane components.

Environmental restrictions: The polycarbonate cup body must not come into contact with organic solvents, ammonia, strong acids, etc.

Safe application: Dual valves used for press clutch/brake must be equipped with monitoring devices (such as DM2 built-in monitoring or external monitoring).
