BENTLY 3500/40M 140734-01 Proximitor Monitor Module

The BENTLY 3500/40M 140734-01 is a key component of the Bently Nevada 3500 Series machinery protection system. Designed as a 4-channel monitor, it accepts input from proximity transducers (such as the 3300 XL series) to measure radial vibration, axial (thrust) position, and eccentricity of rotating shafts. This module provides continuous, real-time monitoring and is essential for preventing catastrophic failures in turbines, compressors, and other critical rotating equipment.

Functional Overview

The 3500/40M processes signals from eddy-current proximity probes and converts them into engineering units (e.g., mils or micrometers). Each channel can be independently configured for various measurement types: direct vibration, gap (position), or both. The module compares measured values against user-programmable alarm setpoints and generates alert signals when thresholds are exceeded. It also provides buffered transducer outputs for external diagnostic equipment.

Key Features

• 4 Independent Channels: Simultaneous monitoring of up to four transducer inputs.

• Flexible Measurement Modes: Supports radial vibration, axial position, eccentricity, and differential expansion.

• Programmable Alarms: Dual setpoints per channel with adjustable hysteresis and time delays.

• Signal Conditioning: Built-in integration for velocity or acceleration signals when using compatible sensors.

• Front Panel Indicators: LED status for channel OK, alarm, and module health.

• Redundant Power Options: Compatible with 3500 series redundant power supplies for high availability.

Technical Specifications

• Input Channels: 4, accepts proximity probe inputs (‑24Vdc or ‑10.2Vdc systems).

• Frequency Response: 0 to 10 kHz (typical).

• Accuracy: ±0.5% of full scale.

• Outputs: Buffered transducer signals (BNC or terminal block), 4‑20 mA re-transmission optional via external converters.

• Compatibility: Fits any 3500 series rack; requires a 3500/20 Rack Interface Module for configuration.

• Certifications: CSA, CE, ATEX (for use in non-hazardous areas).

Applications

The 3500/40M is widely used in industries such as power generation, oil & gas, petrochemical, and pulp & paper. It monitors critical rotating machinery including steam turbines, gas turbines, centrifugal compressors, pumps, and gearboxes. By providing early warning of shaft vibration or position changes, it helps operators schedule maintenance and avoid unplanned downtime.

Configuration and Integration

The module is configured via the 3500 Framework software using a proprietary communication interface. Each channel's parameters (range, alarm setpoints, time delays) are set in the 3500/20 RIM and stored in the module's nonvolatile memory. The monitor continuously communicates with the rack interface and can share data with distributed control systems (DCS) through optional communication gateways like the 3500/92.

In summary, the BENTLY 3500/40M 140734-01 is a reliable and accurate monitoring solution that forms the backbone of modern machinery protection strategies. Its robust design, flexibility, and seamless integration with the 3500 series make it a preferred choice for critical asset monitoring worldwide.
