FOXBORO AD198GV module

FOXBORO AD198GV module

DESCRIPTION

The FOXBORO AD198GV module is an intelligent pressure transmitter for measuring and controlling differential pressure.

FEATURES

·High accuracy and reliability
·FOUNDATION fieldbus H1 protocol support for easy integration with a wide range of DCS and PLC systems
·Easy to install and maintain

Product parameters:

Measuring range: -1900 to 6900 kPa (-275 to 1000 psi)
Output range: 4-20 mA DC
Accuracy: ±0.15% full scale
Resolution: 0.01% full scale

Response time: <2 seconds
Operating temperature: -40 to 85 °C
Protection level: IP67

Product Specifications:

Dimensions: 115 mm x 80 mm x 50 mm
Weight: 0.7kg
Material: Stainless steel

Applications:

Industrial process control
Oil and gas
chemicals
electricity

IO module has the following main functions

Input Function

The IO module can receive input signals sent by external devices and convert them into digital or analogue signals for use by the computer system or control system. These input signals can come from a variety of sensors, such as temperature sensors, pressure sensors, photosensitive sensors and so on. By receiving and parsing these input signals, the system can monitor and control the external environment in real time.

Output Functions

The IO module is capable of converting the output signals generated by a computer system or control system into the form required by an external device. These output signals are typically used to control actuators such as motors, valves, lights, etc. By sending appropriate output signals to external devices, the system enables control and operation of the external environment.

Data Acquisition and Processing

The IO module is capable of acquiring data from external devices and transferring it to a computer system or control system for further processing. This enables the system to acquire environmental data, status information and user inputs in real time and make appropriate decisions or perform specific tasks based on this data.
