HONEYWELL TH115-A-240D-B/U thermostats with advanced programming

HONEYWELL TH115-A-240D-B/U thermostats with advanced programming

Basic Information

Brand: Honeywell (Honeywell)

Model: TH115-A-240D-B/U

Type: Programmable thermostat, may be suitable for electric heating systems

Functional features

High-precision sensor: Built-in high-precision sensor can monitor the room temperature in real time and compare it with the temperature set by the user to adjust the heating system automatically.

User-friendly interface: may be equipped with an intuitive display and buttons for easy temperature setting and programming.

Energy saving mode: with programmable functions, the user can reduce the temperature setting for periods of time when heating is not required, thus saving energy.

Safety protection: may be equipped with safety functions such as overload protection and short circuit protection to ensure safety during use.

BENEFITS

Advanced temperature control ensures total comfort by minimizing temperature swings

ON/STANDBY switch enables thermsotat shutdown at the end of heating season for added security

On-screen heating power indicator gives at-a-glance verification of power being used

Early Start function ensures programmed temperature is reached by programmed time

Temporary bypass enables temperature override without changing programming

Attractive design includes hidden programming buttons

Battery-free backup means no re-programming your schedule after a power outage

Product Specifications

Dimensions (in.)：4.9 in. X 2.8 in. X 0.9 in.

Dimensions (mm)：124 mm X 70 mm X 23 mm

Used With：Aube RC840 Series Electromechanical Relays

Comments：Aube CT240/CT241 Telephone Controller

Item Type：Product

Mounting：Vertical

Electrical Ratings

Maximum Load: 15 A (resistive only), 3120 W @ 208 Vac, 3600 W @ 240 Vac

Frequency：50 Hz; 60 Hz

Electrical Connections：6 in. (150 mm) tinned copper lead wires

Supply Voltage：240 Vac 15A

Operating Temperature Range (F)：32 F to 120 F

Operating Temperature Range (C)：0 C to 50 C

Power Method：Hardwired

Ambient Temperature Range (C)：0 C to 70 C

Ambient Temperature Range (F)：32 F to 158 F

Color：White

Sensor Element：Thermistor

Differential Temperature (F)；1 F

Differential Temperature (C)：0.5 C

Switching Action：SPDT

Switch Type：Epoxy-soundproofed relay

Programmability：7 Day program

Setting Temperature Range (F)：40 F to 86 F

Setting Temperature Range (C)：5 C to 30 C
