EATON MVX9000 Variable Frequency Drive

Power factor:>0.95

Efficiency:>95%

3. Environmental requirements

Operating Temperature

0~50 ° C (below 7.5HP)

0~40 ° C (7.5HP and above)

Humidity: 20%~90% (without condensation)

Altitude: ≤ 1000 meters (higher than this, it needs to be downgraded for use)

Protection level: IP20 (open rack)

4. Heat dissipation data

The typical thermal losses of different models at a carrier frequency of 9kHz are shown in the following table (excerpt):

Model Power Heat Loss (W)

MVXF25A0-1 1/4HP 115V 20

MVX001A0-2 1HP 230V 38

MVX003A0-4 3HP 460V 110

MVX010A0-5 10HP 575V 211

5. Selection of braking resistor

The MVX9000 has a built-in brake chopper and can be equipped with brake resistors as needed. The following table shows a typical configuration (230V series example):

Motor power braking resistor kit resistance value/power braking torque

1/2HP K13-000034-0821 200Ω / 180W 220%

2HP K13-000034-0824 70Ω / 300W 125%

5HP K13-000034-0825 40Ω / 400W 125%

7.5HP K13-000034-0826 30 Ω/500W (2 in parallel) 125%

6. External dimensions

Power Range Width (mm) Height (mm) Depth (mm) Weight (kg)

1/4-3HP 100 151 145 2.8

5-7.5HP (230V) 125 220 193 5.5

5-10HP (460V/575V) 125 220 193 5.5

Selection of Enclosed Drivers

MVX9000 can also provide multiple levels of protection for enclosed models, suitable for harsh industrial environments.

1. Protection type

NEMA 1: Universal Indoor, Ventilated

NEMA 3R: Rain resistant, suitable for outdoor use

NEMA 12: Dustproof, Industrial Environment

NEMA 4X: Waterproof, corrosion-resistant, made of stainless steel material (304 or 316)

2. Configuration options

Non combination type: only includes frequency converter

Combination type: with isolating switch or circuit breaker

Bypass type: 2-contactor or 3-contactor bypass, including overload protection

3. Counter control options

Provide multiple combinations of control components that can be factory installed or on-site modified:

Start/Stop button

Operation indicator light (red/green)

Hand/stop/automatic selection switch

Forward/Reverse/Stop button

Speed potentiometer

4. Certification

UL listed

CUL listed (compliant with CSA standards)

ABS type approval

CE mark (requires EMI filter)

Selection and ordering information

1. Example of open rack selection (partial)

Power Voltage Input Current Output Current Order Number

1/2HP 230V 5.8/3.4A 2.5A MVXF50A0-2

1HP 460V —/4.2A 3.0A MVX001A0-4

3HP 575V —/5.9A 4.2A MVX003A0-5

7.5HP 230V —/31A 25A MVX007A0-2

10HP 460V —/20.6A 18A MVX010A0-4

2. Example of Closed Type Selection

Non combination NEMA 1:

Power Voltage Order Number

1HP 230V ECS80C1BAA-C1

5HP 460V ECS80F1CAA-C1

Combination isolation switch type NEMA 1:

Order number for power voltage fuse

2HP 230V 30A ECSB1D1BAC-C1

7.5HP 460V 60A ECSB1G1BAC-C1

Combination circuit breaker type NEMA 4X stainless steel:

Order number for power voltage circuit breaker

1HP 460V 15A ECS82C4CAA-C1

5HP 230V 30A ECS82F4BAA-C1

Optional accessories

Accessory Type Order Number

Copy keyboard MVXCOPY

Remote keyboard kit MVXRMM

DIN rail installation kit MVXDR

DeviceNet Communication Module MVXDNN

NEMA 1 Small Cabinet Kit MVXENCSC

Input reactor (3%) K64-000989-2091, etc

EMI filter K13-000034-0111, etc

Dynamic braking resistor K13-000034-0821, etc
