Product Core Overview

（1） Product positioning and design objectives

The MICE series is a modular network component designed specifically for industrial environments. Its core function is to build a switched industrial Ethernet that complies with the IEEE 802.3 standard, which can adapt to various complex industrial scenarios such as standard industry, marine, railway (track area), substations, etc. It has industrial grade characteristics such as anti-interference, resistance to harsh environments, and flexible scalability, meeting the stability and reliability requirements of industrial equipment interconnection and data transmission.

（2） Compliance certification and scope of application

Core Certification Standards

European compliance: 2004/108/EG Electromagnetic Compatibility Directive, 2011/65/EU (RoHS) Hazardous Substance Restriction Directive, ATEX 94/9/EG Explosion Protection Directive (applicable to gas explosion hazardous areas);

International standards: FCC Part 15 (US Electromagnetic Compatibility Standard), IEC 60825-1 (Laser Safety Level 1), IEC 60079 series (Explosion proof Standard), IEEE 802.3 (Ethernet Standard), IEEE 802.3af (PoE Power Supply Standard);

Other certifications: CE, UL 508, ISA 12.12.01 (Industrial Control Equipment Safety), etc. Some models support classification society certification (GL, ABS, BV, DNV, etc.).

Applicable scenario segmentation

Standard application: Office areas, commercial premises, small business industrial environments (compliant with EN 61131-2);

Marine application: interconnection of merchant ship equipment (model including B/E/H/S authorization code);

Railway application: Track area communication (compliant with EN 50121-4, with model including E/H/S authorization code);

Substation application: Power system communication (compliant with EN 61850-3, IEEE 1613, with model number including H/S authorization code).

Full analysis of module system

The MICE series adopts a modular architecture of "basic module+expansion module+functional module", and each module can be flexibly combined to adapt to different industrial communication needs.

（1） Basic module (Switch Grundmodule)

As the core carrier of the device, it supports the access of various media modules and expansion modules. The main models and features are as follows:

Series representative models, core features, adaptation and expansion

MICE 2000 MS2108-2 10/100 Mbit/s rate support, basic industrial grade design for all MM2 series media modules and MB20 expansion modules

MICE 3000 MS3124-4 10/100 Mbit/s rate support, some models are compatible with PTP protocol MM3 series media modules, MB20 expansion modules

MICE 4000/Power MICE MS4128-5 supports 10/100/1000 Mbit/s gigabit rates and has power expansion capabilities for MM4 series media modules, SFP modules, and MB20 expansion modules

Other basic modules MS20-..., MS30-... Lightweight design, adapted to specific scene simplification requirements corresponding to series of media modules

（2） Medium module

As an interface module between devices and LAN, it provides different types of communication ports (Twisted Pair/TP, Optical Fiber/LWL, AUI, etc.), classified according to the adaptation basic module series as follows:

1. MICE 2000 series media module (10/100 Mbit/s)

Module model, port configuration, interface type, power consumption, typical applications

MM2-4TX1 (- EEC) 4 TP ports RJ45 0.8W short distance industrial equipment interconnection (such as sensors, IP phones)

MM2-2FLM4 2 multi-mode LWL ports (10 Mbit/s) ST - Low rate optical fiber transmission scenario

MM2-4FXM3 4 multi-mode LWL ports (100 Mbit/s) MTRJ 6.8W multi device optical fiber interconnect, requiring high-density ports

MM2-2FXM3/2TX1 2 multi-mode LWL ports+2 TP ports MTRJ+RJ45 3.8W hybrid medium (optical fiber+Ethernet cable) transmission scenario

MM2-2FXM2 2 multi-mode LWL ports (100 Mbit/s) DSC 3.8W optical fiber communication requirements for specific interface types

MM2-2FXS2 2 single-mode LWL ports (100 Mbit/s, 1300nm) DSC 3.8W medium short distance single-mode optical fiber transmission

2. MICE 3000 series media module (10/100 Mbit/s, partially supports PTP)

Module model, port configuration, interface type, power consumption, special characteristics

MM3-2AUI 2 AUI ports Sub-D-St. 3.4W old industrial equipment AUI interface adaptation

MM3-4TX5 4 TP ports M12 0.8W industrial environment foolproof interface, anti vibration

MM3-4TX1-RT 4 TP ports RJ45 0.8W support IEEE 1588 PTPv2, precise clock synchronization

MM3-4FLM4 4 multi-mode LWL ports (10 Mbit/s) ST 5.0W multi port low-speed optical fiber transmission

MM3-2FXM4/2TX1 2 multi-mode LWL ports+2 TP ports ST+RJ45 3.8W mixed medium transmission, compatible with ST interface optical fiber

MM3-4FXS2 4 single-mode LWL ports (100 Mbit/s, 1300nm) DSC 6.8W high-density single-mode optical fiber interconnect

MM3-1FXL2/3TX1 1 single-mode LWL port (100 Mbit/s, 1550nm)+3 TP ports DSC+RJ45 3.4W long-distance single-mode optical fiber+short distance network cable mixed scenario

3. MICE 4000 series media module (1000 Mbit/s, gigabit rate)
