THQL21125 | General Electric 2 Pole Circuit Breaker

THQL21125 | General Electric 2 Pole Circuit Breaker

Product Description P/N: THQL21125 Description / Specifications Description The General Electric THQL21125 is a 2-pole circuit breaker designed for residential panels. Manufactured by General Electric, it belongs to the THQL Series. Its catalog number is THQL21125, with an alternative number THQL2125. It operates at 125 Amps and 240 Volts, featuring a plug-in connection and single-phase functionality. The breaker has an interrupting rating of 10000 Amperes. Its dimensions are 3 inches in height, 2 inches in width, and 3 inches in length. This product is an authentic General Electric item, approved by CSA and listed by UL.

 Technical Specifications Part # THQL21125 Category Circuit Breaker Subcategory Load Center Circuit Breaker Interrupting Capacity Rating 10 kAIC Voltage 120/240 V Trip Style Non-Interchangeable Frame Type Q-Line Amperage 125 A System Voltage 120 Vac, 120/240 Vac Poles 2 Trip Function LI Continuous Current Rated Standard 120 Vac Interrupting Rating 10 KAIC 120/240 Vac Interrupting Rating 10 KAIC Suitable for Reverse Feed Yes Long Time Fixed Instantaneous Fixed Protective Relays No Current Metering No Special Markings HACR GSA Compliance Yes Information About THQL21125 The General Electric THQL21125 is a 2-pole circuit breaker designed for residential panels within GE's THQL series.

 It operates at 125 Amps and 240 Volts, featuring a plug-in connection suitable for single-phase applications. The breaker is equipped with an interrupting rating of 10000 Amperes, ensuring efficient protection against overloads and short circuits. Identified by catalog number THQL21125, with an alternative number THQL2125, it adheres to standard dimensions of 3 inches in height, 2 inches in width, and 3 inches in length. As an authentic General Electric product, it meets the rigorous safety standards set by CSA and is UL listed, assuring reliability and compliance with industry regulations.

 Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor.

QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.

Features

▪ Contains 10 Mbytes of battery-backed user memory and 10 Mbytes of non-volatile flash user  memory.

▪ Provides access to bulk memory via reference table %W.

▪ Configurable data and program memory.

▪ Programming in Ladder Diagram, C, Structured Text, and Function Block Diagram.

▪ Supports auto-located Symbolic Variables that can use any amount of user memory.

▪ Reference table sizes include 32Kbits for discrete %I and %Q and up to 32K words each for  analog %AI and %AQ.

▪ Supports Series 90-70 discrete and analog I/O, communications, and other modules. For a  list of modules supported, refer to the PACSystems RX7i Installation Manual, GFK-2223.

▪ Supports all VME modules supported by Series 90-70.

▪ Supports RX7i data monitoring over the web. Allows a combined total of up to 16 web server  and FTP connections.

▪ Supports up to 512 program blocks. Maximum size for a block is 128KB.

▪ Test Edit mode allows you to easily test modifications to a running program.

▪ Bit-in-word referencing.

▪ Battery-backed calendar clock.

▪ In-system upgradeable firmware.

▪ Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232  Ethernet station manager serial port.

▪ The embedded Ethernet interface provides:

- Data exchange using Ethernet Global Data (EGD)

- TCP/IP communication services using SRTP

- Support for SRTP Channels, Modbus/TCP Server, and Modbus/TCP Client

- Full programming and configuration services

- Comprehensive station management and diagnostic tools

- Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network  switch providing auto-negotiated network speed, duplex mode, and crossover detection.

- User-configurable Redundant IP address

- Time synchronization to SNTP time server on Ethernet network (when used with  Release 5.00 or later CPU module).
