YOKOGAWA 22.5 × 17.4 × 10 compact industrial control module is a highly integrated control module developed by Yokogawa Electric in Japan for space limited scenarios in the field of industrial automation. The core size specification is 22.5mm × 17.4mm × 10mm (length × width × height), and efficient installation and system integration within limited space are achieved through extreme miniaturization design. This module combines signal acquisition, logic control, and data transmission functions, and can accurately process on-site analog and digital signals, providing stable and reliable control core support for small industrial equipment and compact control systems. The product adopts industrial grade micro packaging technology, which has excellent anti-interference ability and environmental adaptability. It is widely used in small intelligent manufacturing equipment, precision instruments, embedded industrial control systems, and special industrial scenarios with limited space (such as small chemical reaction devices, micro power generation equipment monitoring, etc.). The module provides a standard 12-month warranty period and is seamlessly compatible with Yokogawa small DCS systems and third-party embedded control platforms. It is one of Yokogawa's core products in the compact industrial control field.

From the logical analysis of product identification, "22.5 × 17.4 × 10" is the core physical dimension parameter of the module, which directly reflects its compact design core characteristics, making it easy for users to quickly judge the compatibility of installation space; As the universal specification label for Yokogawa's compact industrial control module series, this size model covers multiple functional sub models and can be selected according to actual needs with different configurations such as analog input, digital input/output, hybrid control, etc., to adapt to diverse small-scale industrial control scenarios. Users can accurately select by adding functional suffix codes to achieve a perfect match between control requirements and spatial conditions.

Core performance characteristics

1. Extremely compact design, space utilization breakthrough

The module adopts the ultimate miniaturization structure design, with a core size of only 22.5mm × 17.4mm × 10mm, reducing its volume by more than 60% compared to traditional industrial control modules, and weighing only about 0.05kg. It can be easily installed on micro rails, narrow cavities inside equipment, and embedded installation positions, greatly improving space utilization. In response to the installation requirements of small industrial equipment and compact control systems, the module adopts a non redundant structure design, maximizing the simplification of volume while ensuring core functions. At the same time, it is equipped with micro pluggable terminal blocks, which balance installation convenience and space adaptability, solving the pain point of traditional modules that cannot be installed in narrow spaces.

2. Highly integrated and multifunctional, suitable for small control needs

The module adopts a highly integrated circuit design, integrating multi-channel signal processing, logic control, and data transmission functions within a miniature volume. The standard configuration includes 2 analog input channels, 2 digital input channels, and 1 digital output channel. The analog input channel supports 0-10V DC voltage signals and 4-20mA current signals, and can be directly adapted to small pressure sensors, temperature sensors, and other field devices; The digital input and output channels support 12-24V DC signals, which can achieve functions such as small actuator control and equipment status monitoring. Some sub models can support thermocouple (K/J type) and thermistor (PT100) inputs, adapting to the temperature monitoring needs of small industrial equipment without the need for additional dedicated modules, greatly simplifying the architecture of small control systems.

3. Industrial grade anti-interference, stable operation guarantee

Despite its compact size, the module still adopts full industrial grade design standards, with built-in multi-channel optoelectronic isolation circuits to achieve electrical isolation between input/output signals and core control circuits. The isolation withstand voltage can reach 1kV AC/1 minute, effectively blocking electromagnetic interference, surge voltage, and ground loop interference in industrial sites. The module is equipped with miniature Transorb surge protection devices, which can withstand instantaneous 30V DC surge impact. At the same time, it adopts anti electromagnetic radiation packaging materials, which comply with the IEC 61000-4 electromagnetic compatibility standard, ensuring stable operation in complex electromagnetic environments with dense installation of small equipment. In addition, the module adopts a low-power design, with a normal operating current of only 20mA or less, reducing energy consumption and heat generation, and adapting to the heat dissipation needs of sealed and narrow installation spaces.

4. Flexible configuration and adaptation, easy installation and maintenance

The module supports parameter configuration through a micro handheld terminal (such as Yokogawa JHT200), which needs to be connected with a dedicated adapter (model E9786WH). It can flexibly set signal type, range, alarm threshold and other parameters without disassembling the module, and can be configured and adjusted to meet the on-site maintenance needs of small devices. Adopting a micro pluggable terminal design, the wiring operation is convenient, and cables can be quickly plugged and unplugged during later maintenance, greatly improving maintenance efficiency. At the same time, the module supports two installation methods: DIN micro rail installation and embedded buckle installation, which can be flexibly selected according to the actual installation space, further enhancing the flexibility of system integration.

Detailed technical specifications

1. Input and output signal parameters

Analog input channel: 2 channels, supporting 0-10V DC voltage signal and 4-20mA current signal; Some models support K/J thermocouple (-270 ℃ to 1372 ℃) and PT100 thermistor (-200 ℃ to 850 ℃) input;

Analog input accuracy: Voltage signal ± 0.2% FS, current signal ± 0.1% FS, temperature measurement ± 0.3 ℃ (PT100, 0-100 ℃);

Digital input channel: 2 channels, supporting 12-24V DC signals, input impedance ≥ 10k Ω; when there is no voltage contact input, 1k Ω and below are in the "ON" state, and 50k Ω and above are in the "OFF" state;

Digital output channel: 1 channel, relay contact output, contact capacity 100V AC/1A, 24V DC/1A, contact life ≥ 600000 times;

Response time: maximum 30ms for analog signals and maximum 10ms for digital signals

2. Power and communication parameters

Power supply: 24V DC ± 20%, supports isolated power supply;

Power current consumption: maximum 20mA during normal operation, ≤ 5mA in standby mode

Configuration interface: Supports configuration through a micro handheld terminal (JHT200), requires adapter E9786WH; Some models support RS-485 micro bus communication, with a communication speed of 1200-9600bps;

Communication protocol: compatible with Yokogawa standard configuration protocol, supporting parameter upload and download;

Signal indication: equipped with miniature power supply, operation, alarm status LED indicator lights (front embedded design, does not occupy additional space).

3. Physical and environmental parameters

Dimensions: 22.5mm x 17.4mm x 10mm (length x width x height), designed with a miniaturized structure;

Weight: Approximately 0.05kg, extremely lightweight;

Working temperature: -10 ℃ to 60 ℃, suitable for most industrial indoor and equipment internal environments;

Storage environment: Temperature range of -20 ℃ to 70 ℃, relative humidity of 10% -90% (non condensing), no corrosive gas or conductive dust environment;

Protection level: IP20 (installed state), with basic dust protection;

Installation method: DIN micro rail installation, embedded buckle installation.

Installation and wiring specifications

1. Preparation before installation

Before installation, it is necessary to confirm that the module size matches the installation space, check that the module appearance is not damaged, the micro wiring terminals are not bent or deformed, and the embedded LED indicator lights are not damaged. Confirm that the installation environment meets the requirements of module environmental parameters, and stay away from strong electromagnetic interference sources (such as micro frequency converters, high-voltage micro components, etc.), high temperature heat sources, and humid areas; Due to the small size and limited heat dissipation space of the module, the installation position needs to ensure smooth ventilation and avoid excessive dense installation with other heating elements. Installation personnel need to have qualifications for installing small industrial control equipment, be familiar with module installation manuals, prepare micro installation tools (such as micro screwdrivers), compatible micro wiring terminals, and fine shielded cables in advance to avoid module damage caused by improper tools.
