TOSHIBA Unified Controller nv series™ Unified Controller nv series™

Water and sewage treatment: Build a flexible and scalable system architecture, utilizing wide area networks to achieve mutual monitoring and water quality assurance between pumping stations.

Oil and gas: To provide power and control for remote pumping stations, a fast and reliable fiber optic loop is used to achieve optical isolation and centralized parameter management of the drive.

Transportation infrastructure: used for wide area centralized monitoring of tunnel clusters, achieving efficient collaborative control of lighting dimming, emission ventilation, and emergency equipment.

Aviation system: applied to the ground lighting monitoring system of the terminal building, realizing high-speed light switching and collective intensity control, providing clear visual guidance for pilots.

Power generation (hydropower): used in dam management systems to ensure fault safety protection against gate misoperation through a dual data acquisition system, supporting manual or automatic motor drive control.

Material handling: Control the crane drive system to achieve sensitive control, efficient operation, and status visualization, relying on system reliability to ensure long-term stable use.

4、 Powerful engineering software support: nV Tool

A unified programming environment nV Tool is the key to unleashing the full potential of Type1 light.

Standardized programming: fully complies with IEC 61131-3, supports multi language mixed programming, and has an intuitive and easy-to-use graphical editor.

Advanced debugging features: online display of LD logic flow, FB values, SFC activation steps, providing synchronization trends, I/O forcing, data monitoring, and event logs, greatly simplifying troubleshooting.

Graphic customization: Custom graphic symbols (such as motor starters and valve controllers) can be created to replace standard functional blocks, making program logic clear at a glance.

Open Data Exchange: Supports importing/exporting projects that comply with the PLCopen XML standard, making it easy to port programs or split/merge projects between different controllers.

5、 Comprehensive specifications and environmental adaptability

The type1 light series strictly follows industrial environmental standards (IEC 61131-2, JIS B 3502):

Working temperature: 0~55 ° C.

Anti vibration/impact: meets the IEC 60068-2-6/27 standard.

Noise immunity: can resist pulse noise, static electricity, and radiation field interference.

Insulation and grounding: High insulation resistance, requiring Type D grounding (≤ 100 Ω).

Cooling method: Natural cooling, no need for fans, reducing failure points.
