WOODWARD 5466-425 Programmable Automation Controller (PAC)

WOODWARD 5466-425 Programmable Automation Controller (PAC)

Product Overview

WOODWARD 5466-425 is Woodward's next-generation programmable automation controller designed specifically for critical industrial control applications. As the core component of the MicroNet TMR (Triple Modular Redundancy) series, this controller provides highly reliable safety critical control in fields such as power generation, oil and gas, and ship propulsion. It is particularly suitable for the protection and control of gas turbines, steam turbines, and large rotating equipment.

Core features and technological advantages

Triple module redundant architecture

Complete TMR system: Three independent channels operate synchronously, with 2-out-of-3 voting to ensure that a single point of failure does not affect operation

Safety integrity: Compliant with IEC 61508 SIL 3 level, suitable for safety critical applications

Fault tolerance: online replacement of faulty modules without system shutdown

High performance processing capability

Multi core processor: using high-performance multi-core CPU with a clock speed of ≥ 1.5GHz

High speed execution: deterministic control loop, minimum scanning period ≤ 10ms

Large capacity memory: ≥ 4GB RAM, ≥ 64GB non-volatile storage

Advanced communication and networking

Diversified interfaces:

4 x Gigabit Ethernet ports (supporting ring network redundancy)

2 x USB 3.0 interface

2 x RS-485 serial ports

Industrial protocol support:

PROFINET IRT (isochronous real-time)

EtherNet/IP

Modbus TCP/RTU

OPC UA (built-in server)

Detailed technical specifications

Category specification parameters

Electrical characteristics Input voltage: 18-32 VDC, dual redundant power supply

Typical power consumption: ≤ 25W

Environmental adaptability working temperature: -20 ° C to+60 ° C

Storage temperature: -40 ° C to+85 ° C

Relative humidity: 5-95% without condensation

Physical characteristic dimensions: 320 × 125 × 150 mm (W × H × D)

Weight: ≤ 3.5 kg

Installation method: DIN rail or panel installation

I/O expansion capability supports local and remote I/O modules

Up to 2048 I/O points can be expanded

Safety certification SIL 3 (IEC 61508)

ATEX/IECEx explosion-proof certification

CE, UL, cULus

Compliant with IEEE 1613 Substation Standard

Main application areas

1. Power generation industry

Gas turbine control: start-up sequence, speed control, temperature management

Steam turbine control: speed regulation, extraction control, protection system

Power plant auxiliary systems: boiler control, feedwater pump, cooling system

2. Oil and gas and pipelines

Compressor control: centrifugal/reciprocating compressor anti surge control

Pump station control: monitoring and control of the main pipeline pumping station

Offshore platforms: power generation and critical process control

3. Ship and Ocean Engineering

Main propulsion control: Large vessel power management

Marine power generation: parallel connection of generator sets and load distribution

Dynamic positioning: Key control of DP system

4. Industrial Drive

Large motor drive

Key process control

Safety Instrumented System (SIS)

Software ecosystem

Woodward ToolKit ™  Software Suite

Integrated development environment: compliant with IEC 61131-3 standard

Programming language: Supports LD, FBD, SFC, ST, IL

Simulation function: Hardware in the Loop (HIL) testing support

Diagnostic tool: Comprehensive system health monitoring

Monitoring and Maintenance

Built in web server: accessed through a standard browser

Data recording: high-speed historical data recording

Predictive Maintenance: State based Monitoring and Alarm

Remote Access: Secure Encryption Remote Support

System architecture and reliability characteristics

Redundant design

Power redundancy: dual DC inputs, automatic switching

Processor synchronization: Three channel precise clock synchronization

Network redundancy: dual ring network topology, self-healing time<50ms

Diagnostic function

Online self diagnosis: continuous monitoring of hardware health status

Event sequence recording: timestamp accuracy ± 1ms

Fault prediction: prediction analysis based on parameters such as temperature and voltage

Maintain characteristics

Hot swappable module: All I/O and communication modules support online replacement

Firmware update: Online firmware upgrade without downtime

Configuration Management: Version Control and Audit Tracking

Ordering and Configuration Guide

Basic Configuration

5466-425-001: Basic controller unit, including TMR core

5466-425-002: Enhanced, increases memory and storage

Optional module

Communication Expansion: PROFIBUS, DeviceNet, Serial Interface Module

Specialized I/O: high-speed analog input, RTD input, thermocouple input

Security module: Hardwired safety shutdown channel

matching products

Cabinet system: Pre installed control cabinet

HMI solution: dedicated operator interface

Training Services: On site and Application Training
