  • ABB AZ20/112112221112E/STD Control Module
    ❤ Add to collection
  • ABB AZ20/112112221112E/STD Control Module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    The ABB AZ20/112112221112E/STD control module is an important component in the field of industrial safety and process control. Its core positioning is safety monitoring and logic control module, mainly used for equipment status monitoring, fault warning, and safety interlock control in industrial systems. It is not an ordinary power expansion or signal conversion module. In its model, "AZ20" is the product series identifier, representing that the module belongs to the ABB safety control series; 112112221112E "is the specific model code, which includes key information such as product version, functional configuration, etc; STD "indicates that the module complies with standard design specifications, is suitable for conventional industrial control scenarios, and belongs to the widely used basic safety control module in the AZ series.

    • ¥5685.00
      ¥5826.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:2.080KG
    • Quantity:
    • (Inventory: 99999)
Description

The ABB AZ20/112112221112E/STD control module is an important component in the field of industrial safety and process control. Its core positioning is safety monitoring and logic control module, mainly used for equipment status monitoring, fault warning, and safety interlock control in industrial systems. It is not an ordinary power expansion or signal conversion module. In its model, "AZ20" is the product series identifier, representing that the module belongs to the ABB safety control series; 112112221112E "is the specific model code, which includes key information such as product version, functional configuration, etc; STD "indicates that the module complies with standard design specifications, is suitable for conventional industrial control scenarios, and belongs to the widely used basic safety control module in the AZ series.




ABB AZ20/112112221112E/STD Control Module

Product core positioning

The ABB AZ20/112112221112E/STD control module is an important component in the field of industrial safety and process control. Its core positioning is safety monitoring and logic control module, mainly used for equipment status monitoring, fault warning, and safety interlock control in industrial systems. It is not an ordinary power expansion or signal conversion module. In its model, "AZ20" is the product series identifier, representing that the module belongs to the ABB safety control series; 112112221112E "is the specific model code, which includes key information such as product version, functional configuration, etc; STD "indicates that the module complies with standard design specifications, is suitable for conventional industrial control scenarios, and belongs to the widely used basic safety control module in the AZ series.

Key technical parameters

Power specifications

Input voltage: 24V DC ± 10%

Compatible with mainstream 24V DC power supply systems in the industrial field, stable operation within voltage fluctuation range

Rated working current: 1.5A

Low power design, reducing overall system energy consumption, suitable for small and medium-sized control circuits

Maximum output current: 5A

Can drive multiple peripheral execution components, such as relays, indicator lights, etc., to meet the control requirements of multiple devices

Input/output characteristics

Digital input channels: 8 channels

Supports both NPN and PNP input types, compatible with sensors of different signal types (such as proximity switches and photoelectric switches)

Digital output channels: 4 channels

Relay output form, contact capacity AC 250V/5A, DC 30V/5A, can directly control external loads

Input response time:<10ms

Quickly capture changes in input signals to ensure timely response to abnormal device status

Security performance

Safety level: SIL 2 (IEC 61508)

Meets industrial safety integrity requirements and can be used in control scenarios that require certain safety performance, such as emergency shutdown control of equipment

Fault diagnosis coverage rate:>95%

It can accurately detect faults in the module itself and connected circuits, such as wire breakage, short circuit, etc., reducing the risk of missed fault diagnosis

Environmental adaptability

Working temperature: -20 ° C~+60 ° C

Adapt to the temperature range of most industrial plant environments without the need for additional temperature control equipment

Protection level: IP20

Suitable for installation inside control cabinets to avoid direct erosion of module components by dust and water vapor

Anti electromagnetic interference: EN 61000-6-2

Has strong resistance to electromagnetic interference and can operate stably in strong interference environments such as frequency converters and motors

Physical specifications

Size: 120 × 80 × 60mm

Compact design, saving installation space for control cabinets and facilitating dense module layout

Weight: 300g

Lightweight, easy to install, reduces cabinet load pressure


Core functions and features

Safety monitoring and interlocking control

This module has multiple digital input channels and can collect real-time equipment operation status signals (such as sensor signals of equipment speed, temperature, pressure, etc.). When the signal exceeds the preset safety range, it can quickly trigger the preset interlocking logic and control the execution components (such as emergency stop relays and alarm devices) through digital output channels to achieve equipment safety protection. For example, in the motor control scenario, if the module detects a motor overload signal, it can immediately cut off the motor power supply to avoid motor damage.

Fault diagnosis and alarm

The module is equipped with a comprehensive fault diagnosis mechanism, which can continuously monitor the input and output circuits, power circuits, and internal circuits of the module. When a fault is detected (such as input signal disconnection, output relay adhesion, abnormal power supply voltage, etc.), an alarm signal will be sent through a dedicated alarm output channel, and the fault information will be stored in an internal register, making it easy for staff to query the fault type through the upper computer or on-site debugging tools, quickly locate and eliminate the fault, and reduce system downtime.

Flexible logic programming ability

Support logic configuration through dedicated programming software (such as ABB Control Builder software). Users can customize the associated logic of input and output signals according to their actual control needs, such as AND, OR, NOT, delay and other logical operations, without the need to replace hardware to adapt to different control scenarios. For example, in production line control, the logic of "the production line can only be started when all workstations are ready for signal input" can be set to improve the orderliness of the production process.

System compatibility and communication functionality

As a compatible component of ABB industrial control systems, it can seamlessly integrate with ABB PLCs (such as AC500 series) and HMI (human-machine interface), and achieve data exchange through RS485 communication interface (supporting Modbus RTU protocol). The device status data and fault information monitored by the module are uploaded to the upper computer, while receiving control instructions issued by the upper computer, realizing remote monitoring and control, and improving the intelligent management level of the system.


Typical application scenarios

Based on its core functions of security monitoring and logic control, this module is mainly applied in the following industrial fields:

Mechanical manufacturing industry: used in CNC machine tools and automated production lines to monitor the operating status of equipment (such as spindle speed, tool position, workpiece clamping status), trigger emergency shutdown when abnormalities occur, and protect the safety of equipment and workpieces; Simultaneously control the start stop and process switching logic of the production line to ensure a smooth production process.

Petrochemical industry: In chemical reaction vessels and pipeline transportation systems, key parameters such as pressure, temperature, and liquid level are monitored. If the parameters exceed the standard, the feed valve is immediately cut off or the pressure relief device is opened to prevent safety accidents; In addition, it can also be used for start stop control and fault protection of equipment such as pumps and fans.

Power equipment matching: In small and medium-sized generator sets and transformer cooling systems, monitor the operating current, temperature, oil level and other signals of the equipment. When overload, overtemperature and other situations occur, issue alarm signals and control auxiliary equipment (such as cooling fans and oil pumps) to start and stop, ensuring stable operation of power equipment.

Logistics and warehousing automation: In the conveyor system of intelligent warehousing, the position of goods and the speed of the conveyor belt are monitored, and the start stop and turning of the conveyor belt are controlled. At the same time, when there are abnormalities such as cargo congestion or conveyor belt deviation, the machine is stopped and an alarm is triggered in a timely manner to avoid damage to goods and equipment failure.
