  • GE DS200DCFBG2BNC MRP445970 DC Feedback Board
    ❤ Add to collection
  • GE DS200DCFBG2BNC MRP445970 DC Feedback Board

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    This feedback board belongs to the GE DS200 series DC speed control system accessories and serves as a bridge connecting DC motor detection components (such as speed generators and encoders) with the speed control controller. The "DS200" in the model is the identification of the core component series of GE DC speed regulation system, which specifies the system platform it is compatible with; DCFBG2BNC "precisely defines the product type - DC Feedback Board, and includes key information such as signal interface type (BNC interface) and channel configuration; MRP445970 "is the production batch and material code to ensure product traceability and compatibility with systems in the same series.

    • ¥16845.00
      ¥17483.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.540KG
    • Quantity:
    • (Inventory: 99999)
Description

This feedback board belongs to the GE DS200 series DC speed control system accessories and serves as a bridge connecting DC motor detection components (such as speed generators and encoders) with the speed control controller. The "DS200" in the model is the identification of the core component series of GE DC speed regulation system, which specifies the system platform it is compatible with; DCFBG2BNC "precisely defines the product type - DC Feedback Board, and includes key information such as signal interface type (BNC interface) and channel configuration; MRP445970 "is the production batch and material code to ensure product traceability and compatibility with systems in the same series.




GE DS200DCFBG2BNC MRP445970 DC Feedback Board

Overview of Feedback Board

This feedback board belongs to the GE DS200 series DC speed control system accessories and serves as a bridge connecting DC motor detection components (such as speed generators and encoders) with the speed control controller. The "DS200" in the model is the identification of the core component series of GE DC speed regulation system, which specifies the system platform it is compatible with; DCFBG2BNC "precisely defines the product type - DC Feedback Board, and includes key information such as signal interface type (BNC interface) and channel configuration; MRP445970 "is the production batch and material code to ensure product traceability and compatibility with systems in the same series.

In the DC speed regulation system, the feedback board plays the role of the "data acquisition and signal conversion center": on the one hand, it receives real-time raw feedback signals (such as analog voltage signals and pulse signals) from the motor speed measurement components; On the other hand, through internal signal conditioning, filtering, amplification, and conversion circuits, the original signal is processed into precise signals that meet the input standards of the speed controller, achieving dynamic matching between the motor operating status and controller instructions, ultimately ensuring stable operation of the motor at the preset speed or torque.


Core performance parameters

The performance parameters of the GE DS200DCFBG2BNC MRP445970 DC feedback board directly determine the control accuracy and stability of the DC speed regulation system. The following is a detailed explanation of the key technical indicators:

1. Adapt feedback component types and signal inputs

This feedback board has good adaptability and mainly supports two types of core feedback components: one is a DC tachometer generator, which can receive analog voltage feedback signals in the range of 0-10V, 0-24V, etc., corresponding to a motor speed range of 0-3000rpm (which can be adjusted to adapt to higher speed motors through resistance parameters); The second is an incremental encoder that supports A/B/Z phase signal input, with a pulse frequency range of 10Hz-100kHz, and can be adapted to encoders of different resolutions (typically supporting 1024 line to 4096 line encoders). At the same time, it supports differential signal and single ended signal input, meeting the signal output type requirements of different detection components.

2. Signal processing accuracy and response speed

-Signal acquisition accuracy: The analog voltage signal acquisition accuracy can reach ± 0.1% FS (full range), ensuring that the deviation between the speed signal and the actual value is controlled within a very small range; The counting accuracy of the pulse signal is 1 pulse, and when combined with a high-resolution encoder, the position detection accuracy can reach ± 0.01mm (depending on the accuracy of the transmission mechanism).

-Response speed: Signal processing delay ≤ 1ms, response time to sudden changes in motor speed ≤ 5ms, able to quickly capture changes in motor operating status, provide timely data support for real-time adjustment of the speed controller, and avoid speed fluctuations caused by feedback delay.

3. Signal output specifications and interface configuration

The output signal type is highly matched with the speed controller, mainly including: ① analog output, supporting three standard signals of 0-5V, 0-10V, 4-20mA, corresponding to linear output of motor speed 0-rated speed, which can be directly connected to the feedback signal input terminal of GE DS200 series speed controller; ② Digital output, including 2 speed status signals (such as "speed up to standard" and "speed abnormal") and 1 fault alarm signal, with an output level of TTL level (5V), which can be linked to control on-site indicator lights or auxiliary equipment.

In terms of interface configuration, a dedicated industrial interface design is adopted: the input interface includes 2 BNC interfaces (for speed generator analog signal input) and 1 DB9 interface (for encoder pulse signal input); The output interface includes 3 Phoenix terminals (for analog and digital signal output) and 1 signal ground interface. The interface connection is firm, with a contact resistance of ≤ 10m Ω, ensuring stable signal transmission.

4. Anti interference performance and working environment

For the complex electromagnetic environment in industrial sites, the feedback board is equipped with multiple anti-interference designs: the power input end is equipped with an EMC filter, which can suppress ± 2kV instantaneous pulse interference; The signal input circuit adopts optoelectronic isolation technology, with an isolation voltage of up to 2500V AC/1min, effectively blocking the influence of external interference signals on the internal circuit; The pulse signal channel is equipped with a Schmitt trigger, which can filter out high-frequency noise interference and ensure the accuracy of pulse counting.

Excellent adaptability to working environment: The working temperature range is -10 ℃~65 ℃, which can adapt to high and low temperature industrial scenarios; The relative humidity range is 5%~95% (no condensation), and it can operate stably in damp workshops or outdoor equipment rooms; Equipped with IP20 protection level, it can effectively prevent dust and accidental contact when installed in conjunction with the control cabinet.

5. Power supply and power consumption specifications

Powered by a DC regulated power supply, with an input voltage range of DC 12V ± 10% and a typical input current of 50mA-100mA, it has overvoltage (≥ 15V) and overcurrent (≥ 200mA) protection functions. When the power supply is abnormal, it can automatically cut off the power supply to avoid damage to the board. Under normal working conditions, the power consumption of the board is ≤ 1.2W, which belongs to low-power design and will not bring additional burden to the system power supply.


Functional features and advantages

1. Accurate signal conditioning and conversion capability

The feedback board integrates high-precision operational amplifiers and 16 bit A/D converters to accurately amplify and digitize the analog signal input from the speed generator, effectively suppressing errors caused by signal attenuation and temperature drift - within the temperature range of -10 ℃ to 65 ℃, the temperature drift error of the analog signal is ≤ 0.05%/℃. For the pulse signal input by the encoder, a combination of hardware counting and software stabilization is used to avoid pulse loss or false counting caused by motor vibration, ensuring the authenticity of feedback data.

2. Comprehensive self diagnosis and fault protection functions

Equipped with comprehensive self diagnostic function, it can monitor the power status, signal input integrity, and internal circuit working status of the board in real time. When problems such as power undervoltage, signal input interruption (such as encoder disconnection), and A/D conversion failure occur, the fault protection mechanism will be immediately triggered. On the one hand, the fault signal will be sent to the speed control controller through the digital output terminal, prompting the controller to perform shutdown or speed reduction protection; On the other hand, local alarms are triggered through the LED indicator lights (power lights, signal lights, fault lights) on the board, making it easier for maintenance personnel to quickly identify the type of fault.

3. Flexible parameter configuration and adaptability

The board has reserved parameter adjustment interfaces, which can be configured for key parameters through dedicated debugging software or onboard potentiometers, including analog signal input range (adapted to speed generators with different output ranges), pulse signal frequency division ratio (adapted to encoders with different resolutions), fault alarm threshold (such as signal loss determination time), etc. It can adapt to different specifications of DC motors and detection components without the need to replace hardware, greatly improving the versatility of the product.

4. Modular design and convenient maintenance

Adopting a standardized modular structure, the dimensions are compatible with the standard rack slots of the GE DS200 series speed control system. During installation, it is fixed with guide rail buckles without the need for additional drilling, making it easy to disassemble. The key components on the board, such as filters and isolation chips, adopt a plug-in design. When a local fault occurs, the components can be replaced separately without replacing the entire board, reducing maintenance costs and downtime.

5. Seamless compatibility with GE systems

As an original accessory of GE DC speed control system, this feedback board is seamlessly compatible with hardware and software of GE DS200DCSPG1A, DS200DCVAG1A and other series speed control controllers, without the need for complex signal matching and debugging. Once connected to the system, it can automatically recognize and work normally. At the same time, it supports communication with the GE Proficy monitoring platform and can upload the feedback motor operation data to the upper system, achieving full process status monitoring and data traceability.


Typical application scenarios

The GE DS200DCFBG2BNC MRP445970 DC feedback board, with its precise feedback capability and stable operating performance, is indispensable in industrial scenarios that rely on DC motors. Typical applications include:

1. Power industry: Used for DC speed control systems of feed pumps and induced draft fans in thermal power plants, collecting motor speed signals and feeding them back to the speed control controller to achieve precise adjustment of motor speed, ensuring stable boiler water supply and induced draft fans, and ensuring efficient operation of the unit.

2. Metallurgical industry: Applied to the DC drive system of steel rolling mills in steel plants, by collecting the speed of the rolling motor and the position signal of the roller, and cooperating with the speed controller to achieve synchronous control of the roll speed, ensuring uniform thickness of steel plate rolling and improving product quality.

3. Mining industry: In the DC speed control system of mining elevators and belt conveyors, the feedback board collects real-time motor speed signals. When the motor speed fluctuates abnormally, the signal is promptly fed back to the controller to trigger braking protection and avoid safety accidents caused by equipment overspeed.

4. Paper industry: Used for DC motor control systems in the web and press sections of paper machines, collecting motor speed signals to achieve multi roll synchronous speed regulation, ensuring stable tension of paper during production, and reducing problems such as paper breakage and wrinkles.

5. Chemical industry: In the speed control system of the mixing motor in the chemical reaction kettle, the feedback board accurately collects the speed signal of the mixing motor, allowing the controller to adjust the speed according to the reaction process requirements, ensuring sufficient and uniform reaction, and improving the qualification rate of chemical products.
