GE-FANUC IC697CMM742-KL Type 2 Ethernet Interface Module

Product Type:Ethernet Interface Network Ports:3 LEDs:4 Module Voltage:+5 VDC, +12 VDC Dimensions:WxHxD (mm) :127x51x147 Weight:0.44 lbs (200g) Experience unmatched performance with our GE Fanuc IC697CMM742-KL Ethernet Interface Module, a cornerstone of modern industrial automation.

Designed with cutting-edge technology, this module ensures reliable and efficient communication between various devices within your system. Featuring three network ports and four LED indicators, it offers a clear overview of operational status and connectivity at a glance. Its robust +5 VDC and +12 VDC module voltage supports a wide range of applications, ensuring compatibility and flexibility.

With dimensions of 94.3 x 111.8 x 47.5 mm and a lightweight structure of just 0.5 kg, this module is easy to integrate into existing systems without compromising on functionality or performance. Its compact size allows for optimal space utilization in your control panel. Our GE Fanuc IC697CMM742-KL Ethernet Interface Module is engineered to meet the stringent demands of industrial environments, delivering unparalleled reliability and durability.

It  an essential component for enhancing data transfer rates, improving system responsiveness, and achieving higher levels of automation in your operations. Don  settle for less when it comes to your industrial automation needs. Upgrade to our GE Fanuc IC697CMM742-KL Ethernet Interface Module today and unlock the full potential of your system. With its advanced features and superior build quality, you e guaranteed to experience increased efficiency, reduced downtime, and streamlined operations.

Engineered for industrial automation, the GE Fanuc IC697CMM742-KL is a robust Ethernet interface module designed to enhance network connectivity and data transfer efficiency in demanding industrial environments.

Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave

ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module
