GE N.P.0285A7104 ETM101 Cable Module Advanced Industrial Networking Solution

GE N.P.0285A7104 ETM101 Cable Module  Advanced Industrial Networking Solution

Module Type:Industrial Automation Connection Type:Cable Data Rate:101 kbps Communication Protocol:MODBUS RTU Operating Temperature Range:-40"C to +70"C Power Consumption:Max 2W Connector Type:M12 Engineered with robust materials, the GE N.P.0285A7104 ETM101 Cable Module ensures reliable performance in harsh industrial environments.

Its M12 connector design facilitates easy installation and maintenance. Featuring an IP67 rating, this cable module is dustproof and waterproof, making it ideal for outdoor applications or areas prone to moisture.

This ensures continuous operation without interruption due to environmental conditions.

With support for data rates up to 10 Mbps, the module enables high-speed data transfer essential for real-time control systems, ensuring efficient communication between different components of your automation system.

The use of twisted pair technology reduces electromagnetic interference (EMI), improving signal integrity and reducing errors during data transmission.

This is crucial for maintaining precision and accuracy in automated processes. Offered in standard lengths of 5m, 10m, and 20m, the GE N.P.0285A7104 ETM101 Cable Module provides flexibility in choosing the most suitable length for specific installation requirements, optimizing space utilization and reducing cable clutter.

The GE N.P.0285A7104 ETM101 Cable Module by GE-FANUC is designed for seamless integration into industrial automation systems, offering enhanced connectivity solutions for control and data transfer.

Compatibility

ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave

ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module
