ABB SK827005 SK827100-AS 480V 60HZ coil

ABB SK827005 SK827100-AS 480V 60HZ coil

Product Overview

ABB SK827005 and SK827100-AS are 480V 60Hz coil components designed specifically for industrial control scenarios, with the core positioning as electromagnetic drive core components for contactors. Among them, SK827100-AS belongs to the coil body of ABB's internal KE550 series, while SK827005 is a matching component compatible with EH550-30-11 contactor. Both products have passed international certifications such as CE and UL, comply with industrial safety regulations, and can adapt to North American and some industrial standard power grids. They can operate stably in various complex industrial environments and provide reliable driving support for the on/off control of high-power loads.

Specification parameters

Electrical specifications

Rated voltage: 480V

Rated frequency: 60Hz (suitable for specific industrial power grids in certain areas, non 50Hz applicable models)

Related host adaptation: mainly equipped with EH550-30-11 contactor (rated current of the contactor) 800A@690V ）

Physical specifications

Weight: Approximately 10lbs per module (equivalent to 4.5kg)

Protection level: IP65 (with dust-proof and low-pressure water spray resistance)

Size: Meets the installation size requirements of standard control cabinets and can seamlessly integrate into conventional industrial control cabinet layouts

Environmental specifications

Working temperature range: -40 ° C to+85 ° C, can work normally in extreme high and low temperature environments

Performance characteristics

Material advantages: Made of high-purity copper wire winding, combined with temperature resistant insulation materials, it can not only reduce losses during current transmission, improve energy utilization, but also enhance the high temperature resistance of the coil, effectively extending the product's service life.

Strong environmental adaptability: Combining IP65 protection level with a wide temperature working range of -40 ° C to+85 ° C, it can cope with various harsh industrial environments such as outdoor, dusty workshops, high and low temperature factories, and has outstanding anti-interference ability.

Stable compatibility: Seamless compatibility with ABB EH550-30-11 contactor and KE550-480V-60Hz coil of the same series, high matching degree of interface and performance parameters, no additional adjustment of equipment structure is required when replacing or upgrading.

Safety compliance: Through CE and UL international certification, it complies with mainstream industrial safety standards worldwide and can ensure the safety of electrical systems and operators during use.

Working principle

This coil works based on the principle of electromagnetic induction and is the core driving component of the contactor. When the coil is connected to a rated power supply of 480V 60Hz, an alternating magnetic field is generated in the high-purity copper wire winding, which acts on the iron core inside the contactor, causing the iron core to generate electromagnetic attraction. Under the action of electromagnetic attraction, the moving and stationary contacts of the contactor close, thereby achieving the conduction of the controlled circuit; When the coil is powered off, the magnetic field disappears and the iron core loses its suction force. Under the reset action of the spring inside the contactor, the dynamic and static contacts separate, and the controlled circuit is disconnected. The entire process precisely controls the on/off of the contactor contacts through the on/off of the coil, thereby achieving power supply and power-off control for high-power loads (such as industrial motors, high-voltage equipment, etc.), which is a key link in signal execution in industrial automation control systems.

Precautions

Voltage frequency matching: It is necessary to confirm that the power grid frequency of the usage scenario is 60Hz. If used in a 50Hz power grid environment, the coil model corresponding to the frequency needs to be replaced, otherwise it may cause abnormal coil performance or even burnout.

Load compatibility: The rated current of the driven contactor shall not exceed 800A to avoid excessive coil current caused by load overload, which may lead to coil burnout or equipment failure.

Environmental adaptation treatment: When used in damp and high concentration of corrosive gases, additional waterproof and anti-corrosion junction boxes need to be installed to further enhance protection capabilities and prevent the coil insulation layer from being corroded and damaged.

Installation specifications: During installation, it is necessary to strictly follow the standard control cabinet size requirements for positioning, ensuring that the distance between the coil and the contactor, other components of the cabinet is reasonable, and avoiding poor heat dissipation or mechanical interference caused by improper installation.

Procurement and substitution: When purchasing, priority can be given to suppliers with available stock (such as expertabb.com, Xiamen Xiongba, with a delivery cycle of 3-7 days); If SK827005 is out of stock, you can choose the same series KE550-480V-60Hz coil to ensure complete compatibility of interfaces and performance parameters before replacing it.

Application scenarios

In the field of power systems, it is used as a driving component for contactors in high-voltage control cabinets to achieve on/off control of loads in high-voltage circuits, ensuring stable and reliable power transmission and distribution processes.

In the field of heavy industry: Suitable for motor starting cabinets in steel mills, cement plants and other places, it can withstand harsh environments with high dust and strong vibration, provide stable drive for the starting and operation of large industrial motors, and ensure the continuous operation of production equipment.

In the field of automation equipment: integrated into DCS distributed control systems as signal execution units, it is linked with PLCs such as ABB AC800M and Siemens S7-400 through I/O modules to receive control signals and drive contactor actions, achieving precise control of automated production lines and intelligent devices, and improving production efficiency and control accuracy.
