ABB 1SBP260100R1001 XI16E1 Extension Module - Digital Input

ABB 1SBP260100R1001 XI16E1 Extension Module - Digital Input

Basic Information

Model Number and Naming: The complete model number is 1SBP260100R1001 XI16E1, where 1SBP260100R1001 is the specific model number of the product, and XI16E1 means that this expansion module belongs to the XI16E1 series of digital input expansion modules.

Place of origin: Sweden.

Dimensions and Weight: Net dimensions are 85mm long, 65mm wide, 93mm high, net weight is 0.19kg.

Characteristics

Number of Input Channels and Voltage: 16 digital input channels, rated input voltage of 24V DC, to meet the needs of a large number of digital signal inputs, can be connected to a number of 24V DC digital sensors, such as proximity switches, photoelectric sensors, etc., is widely used in a variety of industrial automation scenarios, to achieve the status of the equipment, position, signal monitoring.

Input Current: The typical input current of each input channel is 5mA, which is small enough not to overburden the external power supply, and at the same time ensure that the module receives the signals from the sensors stably.

Electrical isolation: The module adopts electrical isolation design between the internal input channels and other circuits, and the isolation voltage can reach a certain safety standard, which can effectively prevent the influence of external interference signals on the internal circuits, ensure the accuracy and stability of the input signals, and improve the module's anti-jamming ability in the complex electromagnetic environment, and guarantee the reliable operation of the system.

Status Indication: Each input channel is equipped with LED indicators, which are used to visually display the input status of the channel. When there is an input signal, the corresponding LED indicator lights up, which makes it convenient for the user to quickly understand the signal situation of each channel, discover the faults or abnormal signals in time, and reduce the difficulty and cost of system maintenance.

Bus compatibility: The module is based on ABB's unique FBP bus technology, compatible with a variety of bus protocols, such as Profibus DP or DeviceNet, etc. Users only need to replace the FBP bus adapters for different types of buses to change the bus protocol, and no special settings, all changes can be automatically recognised, which provides great convenience for the user to convert between different standard field buses. All changes are recognised automatically and provide a great convenience for the user to switch between different standard fieldbuses.

Fields of application

Industrial automation production line: In automation production line of automobile manufacturing, electronic manufacturing, food processing and other industries, it can be used to collect various equipment status signals, such as start-stop signals, fault alarm signals, material detection signals, etc., so as to realise real-time monitoring and automation control of the production line, and to ensure efficient and stable operation of the production line.

Process control system: In the chemical, petroleum, electric power, water treatment and other process industries, it can be used as the extension input module of distributed control system (DCS) or programmable logic controller (PLC) to monitor the digital signals of sensors such as temperature, pressure, flow rate, liquid level, etc., to provide accurate data support for the process control and to safeguard the safety, stability and high efficiency of the production process.

Intelligent Building System: It is applicable to HVAC system, lighting system, water supply and drainage system in intelligent buildings, etc. It can collect the operation status signals of various equipments and environmental parameter signals, such as the operation status of air-conditioning system, indoor and outdoor light intensity, water level signals, etc., so as to realise the intelligent management and control of the building equipments, and to improve the energy efficiency and comfort of the building.

Transportation system: In the field of transportation such as rail transportation, port terminal, etc., it can be used to collect signalling machine status, vehicle detection signals, equipment failure signals, etc., which provides data support for traffic signal control, equipment monitoring and safety protection, and ensures the normal operation and safety management of the transportation system.
