Product Description P/N: DS200DCVAG2A DESCRIPTION / SPECIFICATIONS Description The DS200DCVAG2A is a General Electric DC Power and Instrument Board designed for industrial control systems. It provides stable DC power and integrates critical instrumentation for reliable operation. The board ensures consistent performance, supporting various applications with its robust power management and measurement capabilities. Technical Specifications Part Number DS200DCVAG2A Manufacturer General Electric Series Mark V Product Type DC Power and Instrument Board Humidity 5-95% Vibration 1.0 G horizontal Number of Channels 12 Common Mode Voltage Range +5 V dc Maximum Lead Resistance 15惟 Analog Output Current 0-20 mA Operating Temperature -30 to 65 C Size 8.26 cm high x 4.18 cm Availability In Stock Weight 2 lbs Country of Origin United States Manual GEI-100460 Information About DS200DCVAG2A

 The DS200DCVAG2A from General Electric is a DC Power and Instrument Board designed for use in the Mark V series, tailored to meet the demands of industrial control systems. This board is engineered to deliver reliable power distribution and instrumentation functions, essential for maintaining operational efficiency and accuracy in various applications. The DS200DCVAG2A accommodates up to 12 channels, providing ample connectivity for multiple instruments and power sources within a control system. It supports a common mode voltage range of +5 V DC, which aligns with the needs of many industrial sensors and control devices.

The board features an analog output current range of 0-20 mA, allowing for precise signal transmission and measurement. Operating within a broad temperature range of -30 to 65 C, the DS200DCVAG2A is designed to perform reliably under diverse environmental conditions. Its tolerance to humidity levels from 5-95% and a vibration specification of 1.0 G horizontal further enhances its suitability for demanding industrial environments. The board is constructed to handle a maximum lead resistance of 15惟, ensuring effective signal integrity and minimal resistance-related losses. With dimensions of 8.26 cm in height and 4.18 cm in width, and a weight of 2 lbs, it is compact yet robust, designed for easy integration into existing setups without compromising on performance. Overall, the DS200DCVAG2A provides essential power and instrumentation functions for the Mark V control systems, featuring durable construction and versatile performance characteristics that make it a key component for maintaining system reliability and efficiency.

 Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor. QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
