Product characteristics

Model-specific: The model number 70970-4-0344432 is a unique number that identifies and distinguishes the cable so that it can be accurately matched to the product during procurement, installation and maintenance.

Compatibility: As part of the H&B Contronic range, compatibility with the same range of equipment and modules ensures seamless connection and co-operation between system components.

Functional role

Signal transmission: It is mainly used for the transmission of electrical signals, which enables the transmission of signals between different devices such as controllers, sensors, actuators, etc., and ensures communication between the devices, thus enabling the coordinated operation of the entire system.

Power transmission: it can provide the necessary power support for the connected devices to ensure the normal operation of the devices. In some automation control systems, providing a stable power supply for the devices is the basis for ensuring the normal operation of the system.

Application Fields

Industrial automation: In the automated production line of chemical, pharmaceutical, food and beverage industries, it connects all kinds of automation equipment, such as sensors for monitoring temperature, pressure, flow and other parameters, and controllers responsible for controlling the production process, in order to achieve precise control and monitoring of the production process.

Energy management system: applied in the field of power, heat and other energy, connecting the monitoring equipment and control equipment in the process of energy production, transmission and distribution, to achieve effective management and optimisation of the energy system, to ensure the efficient use of energy and stable supply.

Main features

· 24 digital inputs with LED displays

· 16 digital transistor outputs with LED displays

· 8 digital inputs/outputs with LED displays

· 8 individually configurable analog inputs 0...10 V, 0...5 V, ±10 V, ±5 V, 0...20 mA, 4...20 mA, differential inputs, Pt100 (2-wire or 3-wire), the analog inputs are also individually configurable as digital inputs

· 4 individually configurable analog outputs ±10 V, 0...20 mA, 4...20 mA

· 2 counters for counting frequencies up to 50 kHz, configurable in 7 different operating modes · 1 CS31 system bus interface for system expansion

· 1 interface for connecting communication modules (e.g. 07 KP 90)

· 2 serial interfaces COM1, COM2

– as MODBUS interfaces and

– for programming and test functions

· Real-time clock

· LEDs for displaying operating conditions and error messages

· Detachable screw-type terminal blocks

· Fastening by screws or by snapping the device onto a DIN rail

· The lithium battery 07 LE 90 can be put into the battery compartment in order to

– store and backup the user program in the RAM

– store and backup data which is additionally contained in the RAM, e.g. the status of flags

– backup the time and date (real-time clock)

· RUN/STOP switch for starting and aborting the program execution

· Extensive diagnosis functions

– self-diagnosis of the basic unit

– diagnosis of the CS31 system bus and the connected modules
