  • Alstom BCSR1 TERMINAL BOARD OF 8 LOGIC OUTPUT SIGNALS
    ❤ Add to collection
  • Alstom BCSR1 TERMINAL BOARD OF 8 LOGIC OUTPUT SIGNALS

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    The Alstom BCSR1 terminal board is an 8-channel logic output signal conversion and drive adaptation core component designed by Alstom specifically for industrial automation control systems. Its core function is to provide safe conversion, load adaptation, and stable drive transmission for logic control signals output by upper level controllers (such as PLC/DCS). This terminal board serves as a key signal bridge between the control system and the on-site execution mechanism, capable of centralized conversion and standardized wiring of 8 discrete logic output signals. Through standardized terminal interfaces, it achieves precise docking with various execution components (such as relays, contactors, solenoid valves). At the same time, it has core features such as output short-circuit protection, reverse connection protection, and enhanced anti-interference, ensuring the reliability of logic output signal transmission and the safe operation of the execution mechanism. It adopts industrial grade high load terminals and reinforced insulation design, with a compact structure and easy installation. It is widely integrated into the execution end of automation control scenarios such as industrial manufacturing, rail transit, and energy monitoring, providing a basic guarantee for the orderly output of system logic control signals and the precise driving of execution mechanisms.

    • ¥15834.00
      ¥16834.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.440KG
    • Quantity:
    • (Inventory: 99999)
Description

The Alstom BCSR1 terminal board is an 8-channel logic output signal conversion and drive adaptation core component designed by Alstom specifically for industrial automation control systems. Its core function is to provide safe conversion, load adaptation, and stable drive transmission for logic control signals output by upper level controllers (such as PLC/DCS). This terminal board serves as a key signal bridge between the control system and the on-site execution mechanism, capable of centralized conversion and standardized wiring of 8 discrete logic output signals. Through standardized terminal interfaces, it achieves precise docking with various execution components (such as relays, contactors, solenoid valves). At the same time, it has core features such as output short-circuit protection, reverse connection protection, and enhanced anti-interference, ensuring the reliability of logic output signal transmission and the safe operation of the execution mechanism. It adopts industrial grade high load terminals and reinforced insulation design, with a compact structure and easy installation. It is widely integrated into the execution end of automation control scenarios such as industrial manufacturing, rail transit, and energy monitoring, providing a basic guarantee for the orderly output of system logic control signals and the precise driving of execution mechanisms.


Alstom BCSR1 TERMINAL BOARD OF 8 LOGIC OUTPUT SIGNALS

Product Overview

The Alstom BCSR1 terminal board is an 8-channel logic output signal conversion and drive adaptation core component designed by Alstom specifically for industrial automation control systems. Its core function is to provide safe conversion, load adaptation, and stable drive transmission for logic control signals output by upper level controllers (such as PLC/DCS). This terminal board serves as a key signal bridge between the control system and the on-site execution mechanism, capable of centralized conversion and standardized wiring of 8 discrete logic output signals. Through standardized terminal interfaces, it achieves precise docking with various execution components (such as relays, contactors, solenoid valves). At the same time, it has core features such as output short-circuit protection, reverse connection protection, and enhanced anti-interference, ensuring the reliability of logic output signal transmission and the safe operation of the execution mechanism. It adopts industrial grade high load terminals and reinforced insulation design, with a compact structure and easy installation. It is widely integrated into the execution end of automation control scenarios such as industrial manufacturing, rail transit, and energy monitoring, providing a basic guarantee for the orderly output of system logic control signals and the precise driving of execution mechanisms.


Specification parameters

Based on the technical standards of Alstom Industrial Automation series products and the general specifications for logic output signal conversion, the core specification parameters of Alstom BCSR1 8-channel logic output signal terminal board are as follows:

-Job Description: 8-channel logic output signal dedicated terminal board, responsible for signal conversion, load adaptation, and drive transmission, without signal processing function

-Adaptive signal type: Supports PNP/NPN logic output signals, which can drive actuators such as relays, contactors, solenoid valves, etc

-Terminal quantity: 8 output terminals+2 common terminals (adapted for PNP/NPN respectively)+2 power adapter terminals, totaling 12 standardized terminals

-Protection level: IP65, with dustproof and anti spray water capabilities, suitable for harsh industrial site environments

-Physical dimensions: 90mm x 70mm x 38mm (length x width x height), standard rail mounted, compatible with general control cabinets

-Terminal type: High load spring type terminal block, rated wire diameter of 0.5~2.5mm ², firmly connected and with low contact impedance

-Compatible with Alstom's full range of PLCs and mainstream industrial controller digital output modules, with excellent compatibility

-Working environment: temperature -20 ℃~60 ℃, relative humidity ≤ 90% RH (no condensation); Storage temperature -30 ℃~70 ℃

-Insulation level: The insulation voltage between terminals and between terminals and the shell is ≥ 2500VAC, the insulation resistance is ≥ 100M Ω (500V DC), and the isolation voltage between channels is ≥ 1500VDC

-Rated parameters: Single terminal rated carrying current ≤ 5A, supporting DC 18~30V external power supply; Equipped with short-circuit protection function, short-circuit withstand current ≥ 10A (instantaneous)

-Electromagnetic compatibility: Compliant with IEC 61000-4 series standards, with strong resistance to electromagnetic interference, output signal response delay ≤ 10ms

-Mechanical strength: Terminal insertion and extraction life ≥ 100 times, tightening torque 0.5~0.8N · m, with excellent mechanical stability

-Protection features: Equipped with output short-circuit protection and power reverse protection functions, it can effectively prevent equipment damage caused by load faults or wiring errors


Performance characteristics

-8-channel precise logic output conversion: specially designed for 8-channel logic output signals, with neat terminal layout, each signal is independently converted and isolated between channels, which can effectively avoid output signal crosstalk and ensure the accuracy and timeliness of control instruction transmission.

-Enhanced protection and safety drive: Built in short-circuit protection and power reverse connection protection circuit, which can quickly cut off the circuit when the load is short circuited or the positive and negative poles of the power supply are reversed, protecting the upper controller and core components of the terminal board; The single terminal has a rated carrying current of 5A and can directly drive low to medium power actuators without the need for additional driver modules.

-High reliability and environmental adaptability: Industrial grade high load terminal and housing materials are selected, with excellent temperature and humidity resistance, and can work stably for a long time in a wide temperature range of -20 ℃~60 ℃ and high humidity environment, adapting to various harsh industrial scenarios; Output signal response delay ≤ 10ms, ensuring fast response of the executing mechanism to control instructions.

-Flexible adaptation and convenient integration: compatible with PNP/NPN logic output signals, it can adapt to controllers of different output types without additional configuration; Standardized guide rail installation design allows for quick integration into existing control cabinet layouts, resulting in high installation efficiency; Equipped with dedicated public terminals to simplify wiring logic.

-Standardized wiring and convenient operation and maintenance: Centralized terminal layout enables regular wiring of 8 output signals, simplifying the complexity of on-site wiring; Clear terminal identification (distinguishing between PNP/NPN common terminal and output terminal) facilitates signal troubleshooting and maintenance in the later stage; Adopting anti misoperation terminal design to reduce the probability of wiring errors.

-Strong anti-interference and insulation performance: using high-grade insulation materials and fully isolated terminal design, insulation voltage ≥ 2500VAC, can effectively block electromagnetic interference and ground potential difference in industrial sites; Compliant with the IEC 61000-4 electromagnetic compatibility standard, ensuring stable transmission of output signals even in strong interference environments.


Working principle

The core of Alstom BCSR1 terminal board is based on the working logic of "logic signal centralized conversion load adaptation safe drive transmission". As a pure passive signal conversion and drive adaptation component, it does not have signal processing function. Its core function is to build a reliable control link between the upper controller and the on-site execution mechanism. By strengthening protection, channel isolation, and standardizing terminal interface design, it ensures the safe transmission of logic output signals and precise driving of the execution mechanism.

The specific workflow is as follows: Firstly, the 8-channel logic control signals of the digital output module of the upper controller (such as PLC/DCS) are connected to the 8-channel independent output terminals of the terminal board through cables. According to the controller output type (PNP/NPN), they are connected to the dedicated common terminal. At the same time, they are connected to the DC 18-30V external power supply through the power adapter terminal to provide power support for the actuator drive; The terminal board independently transfers each output signal through internal reinforced insulation isolation lines to avoid crosstalk between signals from different channels. At the same time, real-time monitoring of each output is carried out through built-in protection circuits; Subsequently, the standardized output terminals and connecting cables are used to synchronously transmit the organized 8-channel logic output signals to the on-site execution mechanism (such as relay coils, solenoid valves, contactor coils, etc.), completing the transfer of control signals and the driving of the execution mechanism; Throughout the entire signal transmission and driving process, the high-level insulation structure, channel isolation design, and high load terminals of the terminal board continue to function, ensuring stable transmission of logic control signals in harsh industrial environments. At the same time, the built-in short-circuit protection and reverse connection protection circuits respond to fault states in real time, quickly cutting off the circuit when a load short circuit or power supply reverse connection is detected, protecting the safety of the controller and terminal board; The standardized terminal layout facilitates signal identification, wiring inspection, and troubleshooting for operation and maintenance personnel, improving system operation and maintenance efficiency.
