  • GE IC3600SVDE1 General Electric Vibration Alarm Card
    ❤ Add to collection
  • GE IC3600SVDE1 General Electric Vibration Alarm Card

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    GE IC3600SVDE1 General Electric Vibration Alarm Card

    • ¥23865.00
      ¥25630.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:4.400KG
    • Quantity:
    • (Inventory: 33)
Description

GE IC3600SVDE1 General Electric Vibration Alarm Card


GE IC3600SVDE1 General Electric Vibration Alarm Card

Part Number IC3600SVDE1 Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark VI/VIe Function Module Availability In StockThe IC3600SVDE1 is a Vibration Alarm Card and is part of the Speedtronic mark II control system which is used in the HYDROGEN PURITY DETECTION AREA. Since their first shipments in 1969, General Electric gas turbines with Speedtronic control systems have accumulated millions of hours of operating experience all around the world.

In temperatures ranging from - 50 degrees Celsius to plus 50 degrees Celsius, these units are employed in a variety of applications, including utility, maritime, pipeline, process, and combined cycles. Off the coasts of Russia, the Middle East, Africa, Australia, South America, and Asia, there are hundreds of these units.

In this case, the Speedtronic control has proven to be quite successful. The SVDE card has three-level detector and alarm channels, two are used for Hydrogen purity detection. For each channel, the positive input voltage is compared to an adjustable reference voltage. When the input exceeds its reference, the logic output will indicate an alarm condition, and a light on the card will go on. If the alarm output is tied to the latch signal for that channel, then the alarm signal will latch and can only be reset by the push button on the card or by an external push-button when the input goes below the alarm level. (There is one reset push button for all three channels).

If the latch input is not connected, the alarm output will return to the unalarmed state when the input is reduced to below the alarm level.

Features

 Single-Slot Module

 SNP/SNP-X Protocol (master, slave)

 CCM Protocol (master, slave, peer)

 RTU Modbus Protocol (slave only)

 Supports connection to MS-DOS or Windows

 programming and configuration software package (monitor only)

 12 Mhz, 80C186 Microprocessor

 Two RS-422/RS-485 or RS-232 Serial Ports

 CCM, RTU and SNP/SNP-X Available on Either or Both Ports

 Simultaneous Communications on Both Ports (up to 9.6 Kbps, or 19.2 Kbps individually)

 High Performance Access to PLC Memory

 Three Status LEDs

 Reset pushbutton

 Soft Switch Configuration (no switches or jumpers)

 No Battery Required

Ease of Use

• Simple and powerful instruction set

• One-axis or two-axis motion programs with synchronized block start

• Program support for a short motion program (called Program Zero) which can be created in the MS-DOS programming software configuration function

• Nonvolatile (flash) storage for 10 programs and 40 subroutines

• User scaling of programming units (in Standard mode only)

• Generic programming using command parameters as operands for Acceleration, Velocity, Move and Dwell commands

• Configured with MS-DOS configuration software

Instructions and warnings related to the operation of the product:

The following specifications must be strictly observed:

 The technical specifications and typical applications of the product system must be strictly observed.

 PERSONNEL TRAINING: Only trained personnel may install, operate, maintain or repair the product system. These personnel must be instructed on the

These personnel must be instructed and briefed on the conditions in the hazardous area.

 Unauthorised modifications: No modifications or structural changes may be made to the product system.

 Maintenance Responsibility: It must be ensured that the product system is used only under appropriate conditions and in a condition fully suitable for use.

 Working environment: The user must fulfil the specified environmental conditions:

Safety regulations

The following safety regulations must be fully observed when (maintenance) work is carried out on the product system:

1 Disconnect completely.

2 Secure to prevent reconnection.

3 Confirm that the installation has been completed.

4 Perform grounding and short-circuiting.
