GE IS200BPIHH1AAA A Critical Component for Speedtronic Turbine Control Systems

IS200BPIHH1AAA  A Critical Component for Speedtronic Turbine Control Systems

Model Type:Speedtronic Turbine Control Product ID:IS200BPIHH1AAA Type Designation:Bridge Personality Interface Board Series:Mark VI Application Category:Turbine Control Functionality:High-precision control signals for interfacing with other boards Buffering Capability:Enhances signal integrity for seamless integration Compatibility:Designed for Innovation Series drives The GE IS200BPIHH1AAA is an advanced module specifically engineered for integration into the GE Mark VI Speedtronic system. This state-of-the-art design ensures seamless operation within industrial gas and steam turbine control systems, enhancing performance and reliability.

 Engineered with cutting-edge PCB technology, this interface board seamlessly connects into the CABP board, facilitating communication across the system. It acts as a crucial signal buffer for the BICH board, ensuring efficient and accurate signal transmission. Designed for compatibility with Innovation Series drives, the IS200BPIHH1AAA enables optimized control within complex industrial environments. Its robust construction and high-performance capabilities make it an indispensable part of modern turbine control systems. Not only does the GE IS200BPIHH1AAA offer exceptional performance and reliability, but it also stands out for its durability and longevity.

Its integration into the GE Mark VI system guarantees a seamless and efficient operation cycle, minimizing downtime and maximizing productivity. For operators seeking to enhance the efficiency and reliability of their industrial turbine systems, the GE IS200BPIHH1AAA provides a superior solution. With its advanced design and compatibility, it is the ideal choice for achieving optimal control and performance in gas and steam turbine operations. The GE IS200BPIHH1AAA is a high-performance Speedtronic Turbine Control PCB board designed for seamless integration into complex industrial control systems, ensuring reliable operation and enhanced efficiency.

Compatibility

ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave

ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module
