  • YASKAWA JRMSI-B1026 Relay
    ❤ Add to collection
  • YASKAWA JRMSI-B1026 Relay

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    YASKAWA JRMSI-B1026 is an industrial grade electromagnetic relay launched by Yaskawa (YASKAWA) brand. Its core positioning is circuit on/off control and signal isolation transmission in industrial automation systems. It has reliable electromagnetic induction drive, low current control, high current control, and electrical isolation protection capabilities, and can achieve safe interconnection between control equipment such as PLC and controller and high-power actuators (such as motors and solenoid valves), accurately completing control signal conversion and power amplification. This relay adopts a modular structure design and is compatible with the entire range of Yaskawa industrial control systems and mainstream automation equipment. It supports plug-in installation and guide rail fixation, and has excellent anti-interference and environmental adaptability. It is a core electrical component that ensures the safe and stable operation of industrial control circuits, improves system anti-interference ability, and prevents mutual interference between control circuits and controlled circuits. At present, there is sufficient stock supply of this type of relay, which can meet diverse needs such as new system construction, maintenance of existing industrial equipment, and upgrading of control systems.

    • ¥22153.00
      ¥23146.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.640KG
    • Quantity:
    • (Inventory: 99999)
Description

YASKAWA JRMSI-B1026 is an industrial grade electromagnetic relay launched by Yaskawa (YASKAWA) brand. Its core positioning is circuit on/off control and signal isolation transmission in industrial automation systems. It has reliable electromagnetic induction drive, low current control, high current control, and electrical isolation protection capabilities, and can achieve safe interconnection between control equipment such as PLC and controller and high-power actuators (such as motors and solenoid valves), accurately completing control signal conversion and power amplification. This relay adopts a modular structure design and is compatible with the entire range of Yaskawa industrial control systems and mainstream automation equipment. It supports plug-in installation and guide rail fixation, and has excellent anti-interference and environmental adaptability. It is a core electrical component that ensures the safe and stable operation of industrial control circuits, improves system anti-interference ability, and prevents mutual interference between control circuits and controlled circuits. At present, there is sufficient stock supply of this type of relay, which can meet diverse needs such as new system construction, maintenance of existing industrial equipment, and upgrading of control systems.


YASKAWA JRMSI-B1026 Relay

Product Overview

YASKAWA JRMSI-B1026 is an industrial grade electromagnetic relay launched by Yaskawa (YASKAWA) brand. Its core positioning is circuit on/off control and signal isolation transmission in industrial automation systems. It has reliable electromagnetic induction drive, low current control, high current control, and electrical isolation protection capabilities, and can achieve safe interconnection between control equipment such as PLC and controller and high-power actuators (such as motors and solenoid valves), accurately completing control signal conversion and power amplification. This relay adopts a modular structure design and is compatible with the entire range of Yaskawa industrial control systems and mainstream automation equipment. It supports plug-in installation and guide rail fixation, and has excellent anti-interference and environmental adaptability. It is a core electrical component that ensures the safe and stable operation of industrial control circuits, improves system anti-interference ability, and prevents mutual interference between control circuits and controlled circuits. At present, there is sufficient stock supply of this type of relay, which can meet diverse needs such as new system construction, maintenance of existing industrial equipment, and upgrading of control systems.


Specification parameters

-Core electrical parameters: coil rated voltage DC 24V, contact rated voltage 0-250V (AC/DC universal), contact rated current 10A; coil power consumption ≤ 2W, action time ≤ 10ms, release time ≤ 10ms, rapid response; Working temperature range -10 ℃~60 ℃, relative humidity ≤ 90% RH (no condensation), suitable for complex electromagnetic environments in various industrial workshops, ensuring stable operation; Mechanical life ≥ 20 million cycles, electrical life ≥ 100000 cycles (AC load), with long-term stable working ability.

-Contact and interface characteristics: Adopting a two open and two closed conversion contact form, including common terminal (COM), normally open contact (NO), and normally closed contact (NC), it can flexibly adapt to different circuit on-off control requirements; The coil and contact are designed with full electrical isolation, with an isolation voltage of ≥ 2500V AC, effectively blocking interference between the control circuit and the controlled circuit; The wiring terminal adopts M3 screw fastening design, suitable for wire diameter of 0.2~2.5mm ², stripping length of 6~8mm, and reliable connection.

-Control and protection performance: It has excellent electromagnetic interference suppression capability and can work stably in industrial strong electromagnetic environments through electromagnetic compatibility (EMC) testing; The coil is equipped with a back electromotive force suppression diode, which effectively protects the electronic components at the control end from voltage surges; The contacts are made of silver alloy material, which has good conductivity and resistance to arc corrosion, reducing the risk of contact adhesion; Equipped with LED input indicator lights, it can intuitively display the on/off status of the coil for easy troubleshooting.

-Certification standards: Passed CE and UL international safety certifications, in compliance with industrial equipment safety operation standards.

-Physical parameters: Weight approximately 200g, size in accordance with DIN standard rail mounting specifications (85 × 88 × 63mm, with housing); The protection level reaches IP20, suitable for installation environment inside industrial control cabinets, effectively preventing dust and foreign objects from entering; The installation method supports 35mm U-shaped/E-shaped guide rail installation and screw fixation, suitable for various industrial scenarios such as general mechanical processing, electronic manufacturing, municipal engineering, etc.


Performance characteristics

-Efficient signal conversion and electrical isolation: Based on the principle of electromagnetic induction, small current control and large current signal conversion can be achieved. The weak current control signal of PLC and other controllers can be amplified into a strong current signal to drive high-power equipment, adapting to the interconnection requirements of circuits of different power levels; The fully electrical isolation design between the coil and the contact effectively blocks electrical interference between the control circuit and the controlled circuit, prevents high voltage from entering the control terminal and damaging precision components, and improves the safety of system operation.

-Strong environmental adaptability and high reliability: using industrial grade high stability electromagnetic components and anti-interference circuit design, it has good temperature adaptability and anti vibration ability, and can operate stably in complex industrial workshop environments; Silver alloy contacts and back electromotive force suppression design extend the service life of components and reduce the probability of failure; A comprehensive mechanical structure design ensures reliable contact between contacts and reduces the impact of arc corrosion during the on-off process.

-Convenient installation and maintenance: Supports dual installation methods of rail and screw, with a simple and efficient installation process, suitable for the rapid integration needs of new system construction and old system renovation; The plug-in design is convenient for later replacement and maintenance, with LED indicator lights displaying the working status intuitively. Combined with clear terminal markings, it greatly reduces the difficulty of troubleshooting and maintenance.

-Comprehensive status monitoring and fault warning: Real time feedback of coil on/off status through LED indicator lights can quickly determine whether the relay is working properly; Abnormal states such as contact wear and coil failure can be indirectly fed back through abnormal operation of the controlled equipment, and fault location can be achieved by cooperating with the control system; Support online replacement, maintenance can be completed without overall shutdown, significantly reducing downtime losses; The contact on/off log can be recorded through the supporting control system, providing data support for system maintenance and optimization.

-Safety compliance: Complies with international safety standards and electromagnetic compatibility requirements, comes with a comprehensive electrical protection design, and reduces equipment operational risks.


Working principle

The YASKAWA JRMSI-B1026 relay, as the core conversion and isolation component of industrial control circuits, works based on the contact on/off control logic driven by electromagnetic induction. This relay is mainly composed of a coil, an iron core, an armature, contacts, and a reaction spring. It is divided into two parts: the control circuit (coil side) and the controlled circuit (contact side), achieving complete electrical isolation. Firstly, when the rated control voltage (DC 24V) is applied to the coil by devices such as PLC and controller, the coil is energized to generate electromagnetic attraction, which attracts the armature to overcome the tension of the reaction spring and move towards the iron core; Subsequently, the armature drives the moving contact (common terminal COM) to move, first disconnecting from the normally closed contact (NC), and then closing with the normally open contact (NO), thereby connecting the high-power equipment power supply of the controlled circuit, achieving equipment startup or state switching; When the coil is powered off, the electromagnetic attraction disappears, and the armature resets under the action of the reaction spring. The moving contact is disconnected from the normally open contact (NO) and reconnected with the normally closed contact (NC). The controlled circuit is powered off and the equipment stops working. The entire work process achieves safe control of small current to large current through electromagnetic signal conversion, while using electrical isolation characteristics to block interference between circuits, ensuring the safe and stable operation of the control system and controlled equipment.


Precautions

-Voltage matching and coil protection: Before installation, it is necessary to confirm that the control voltage is consistent with the rated voltage of the coil (DC 24V). It is strictly prohibited to apply voltage beyond the rated range to prevent the coil from burning out; Suggest connecting fuses in series in the control circuit of the coil to avoid damage to the coil due to overload current; When not in use for a long time, it is necessary to disconnect the control power supply to avoid aging of the coil caused by long-term electrification and extend its service life.

-Safety operation regulations: When wiring, repairing or replacing components, the power must be disconnected first, and touching the terminals while powered on is strictly prohibited to prevent electric shock accidents.

-Correct wiring and contact matching: Strictly distinguish between coil terminals and contact terminals (COM, NO, NC) according to the wiring manual, strictly prohibit misconnection or mixing, and avoid control logic errors or equipment damage; When wiring, ensure that the terminal screws are tightened and the torque is controlled at 5.0 lb inch to prevent loose connections that may cause poor contact or arcing; Select matching wires based on the power of the controlled equipment to avoid wire overload and heating; The controlled load power shall not exceed the rated capacity of the contacts (10A/250V), and if exceeded, it shall be used in conjunction with a contactor to protect the contacts.

-Standardized installation and environmental protection: The installation location should be far away from strong electromagnetic interference equipment such as welding machines and high-power motors to avoid electromagnetic interference causing contact misoperation; When multiple relays are installed side by side, appropriate spacing should be maintained to ensure good heat dissipation; Strictly follow local electrical regulations for installation, avoid sharing installation brackets with high-voltage equipment, and prevent the risk of electric shock or short circuit.

-Professional operation: The parameter setting, system integration, and fault maintenance of modules need to be completed by professional technicians to avoid system failures or equipment damage caused by non professional operations.
