  • FOXBORO P0926TM Modular I/O PLC Module
    ❤ Add to collection
  • FOXBORO P0926TM Modular I/O PLC Module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    The parameter design of P0926TM module fully meets the requirements of industrial grade PLC control, and performs outstandingly in signal processing accuracy, environmental tolerance, and communication capability. Combined with the characteristics of this series of products and industrial standard specifications

    • ¥15457.00
      ¥16322.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:1.430KG
    • Quantity:
    • (Inventory: 99999)
Description

The parameter design of P0926TM module fully meets the requirements of industrial grade PLC control, and performs outstandingly in signal processing accuracy, environmental tolerance, and communication capability. Combined with the characteristics of this series of products and industrial standard specifications


FOXBORO P0926TM Modular I/O PLC Module

Core technical parameters

The parameter design of P0926TM module fully meets the requirements of industrial grade PLC control, and performs outstandingly in signal processing accuracy, environmental tolerance, and communication capability. Combined with the characteristics of this series of products and industrial standard specifications, the core technical specifications are as follows:

1. Electrical parameters

-Power supply specifications: Suitable for industrial site universal 24V DC power supply, supports redundant power supply access, power supply polarity anti reverse design, effectively reduces the risk of installation misoperation, compatibility and safety;

-Power consumption characteristics: maximum power consumption ≤ 10W, rated working current ≤ 1.2A, optimized energy consumption control, can reduce the overall power supply load of the system, suitable for dense module installation scenarios;

-I/O channel configuration: Standard configuration includes 8 analog output channels, supporting 0-20mA DC standard signal output. Each channel independently drives external loads with a capacity of ≥ 500 Ω; Partial versions can expand digital I/O channels to achieve mixed processing of analog and digital signals, meeting complex control requirements.

2. Environmental adaptability parameters

-Temperature range: working temperature -25 ℃ to 60 ℃, meeting the needs of outdoor control cabinets and high-temperature workshops in extremely cold regions; Storage temperature ranges from -40 ℃ to 85 ℃ to ensure equipment stability during transportation and inventory processes;

-Humidity and Protection: The relative humidity tolerance range is 5% to 95% (non condensing), with a protection level of IP66. It adopts a pressed aluminum enclosed shell design, which can effectively isolate dust, moisture, and slight mechanical impact, meeting the requirements of harsh environmental protection defined in ISA standard S71.04;

-Anti interference and isolation performance: Channel isolation voltage ≥ 2kV CAT III, with strong electromagnetic anti-interference ability, can resist electromagnetic interference generated by industrial field frequency converters, large motors and other equipment, ensuring signal transmission accuracy; Support independent isolation between signal ground and power ground to further enhance anti-interference level.

3. Physical and Communication Parameters

-Physical dimensions: Adopting a compact structural design, the conventional dimensions are 90 × 70 × 25mm (length × width × height), with a weight of approximately 0.2kg. The compact size facilitates dense installation of DIN rails, saving internal space in the control cabinet;

-Communication protocol and interface: Supports FOXBORO dedicated 2Mbps fieldbus protocol, equipped with redundant Ethernet interface (10/100Mbps), and can achieve protocol conversion with 10Mbps Ethernet fieldbus through FCM communication components; Compatible with Modbus RTU industrial universal protocol, it can seamlessly integrate with mainstream PLC and DCS systems to achieve high-speed data transmission and remote monitoring.


Core functions and product features

The P0926TM module relies on the technical advantages of the FOXBORO I/A Series system, and revolves around the core requirements of "reliability, efficiency, and ease of maintenance" in industrial control, forming the following significant functional features:

1. High precision signal processing and intelligent configuration

Each channel of the module adopts Sigma Delta high-precision data conversion technology, with a signal conversion accuracy of ≤± 0.1% FS and a scanning cycle as low as 25ms, ensuring fast response of control instructions; Support channel level intelligent configuration, which can set parameters such as conversion time, fault safety mode (hold/return), and fault return value for different process requirements, and adapt to multi scenario control needs. Built in configurable moving average filter can effectively filter out process noise and power line frequency interference, further improving signal stability.

2. Redundant design and high reliability operation

Adopting a fully redundant architecture design, including power redundancy, communication redundancy, and channel redundancy, paired redundant components can effectively reduce system failure rates and extend equipment effective operating time. The communication link supports dual path (A/B) automatic switching. When one path fails, the module can instantly switch to the normal path to continue working, ensuring uninterrupted control process. The sturdy aluminum casing not only provides physical protection, but also has good heat dissipation performance, suitable for long-term continuous operation scenarios.

3. Modular expansion and convenient maintenance

Following the standardized modular design concept, modules can be directly installed on DIN rail type substrates. One substrate can accommodate up to 8 fieldbus components of the same series, supporting rapid expansion of I/O points through the addition of new modules, without the need to reconstruct the system architecture, reducing the cost of enterprise upgrades. Adopting a "hot swappable" design, the module can be plugged and replaced without disassembling the on-site wiring, disconnecting the power supply and communication cables, greatly reducing fault handling time and improving maintenance efficiency. The panel is equipped with multi-color LED indicator lights, which can intuitively display the power status, communication status, and channel operation status, making it easy to quickly locate faults.

4. Wide compatibility and system integration capability

As a dedicated module for the FOXBORO I/A Series system, it can seamlessly integrate with devices such as the FCP270 controller and FEM100 expansion module to form a complete control solution. Simultaneously compatible with other brands of PLCs (such as Siemens, Rockwell) and DCS systems, achieving cross brand device data exchange through Modbus RTU protocol. Support direct connection with on-site devices such as smart transmitters and regulating valves, reducing signal conversion steps and improving system integration efficiency.


Typical application scenarios

The P0926TM module is widely used in various process industries and discrete manufacturing fields due to its high precision, high redundancy, and easy integration characteristics. The core application scenarios are as follows:

1. Petrochemical and chemical industry

In the process of petroleum refining and chemical synthesis, modules are used to convert control instructions from DCS systems into 0-20mA standard signals, drive actuators such as reaction kettle temperature regulating valves and feed flow control valves, and achieve precise control of key process parameters such as reaction temperature, pressure, and material ratio. Its redundant design can effectively avoid production interruptions caused by equipment failures and ensure production safety in flammable and explosive environments.

2. Power and energy industry

The PLC monitoring system suitable for thermal power plants and hydropower stations, on the one hand, transmits the control signals of the controller to the actuators of auxiliary equipment such as feed pumps and blowers, and adjusts the operating status of the equipment; On the other hand, feedback signals from the actuator can be collected to achieve closed-loop control. In the substation scenario, it can be used to control isolation switches, grounding switches and other equipment, and with redundant communication design to ensure the continuity of power supply.

3. Intelligent manufacturing and metallurgical fields

In automobile manufacturing and mechanical processing production lines, modules are used to control the actions of robotic arms, conveyor belt speeds, and other actuators, achieving automated control of the production process. In the process of steel smelting and non-ferrous metal processing, large equipment such as temperature control devices for smelting furnaces and pressure regulation mechanisms for rolling mills can be driven to accurately adjust operating parameters based on sensor feedback signals, thereby improving product quality stability.

4. Municipal and environmental protection fields

In urban sewage treatment systems, modules are used to control the operation of equipment such as dosing pumps and aeration fans, automatically adjusting the dosage and aeration amount based on water quality monitoring data to achieve standard discharge. In the centralized heating system, the flow control valve of the heating network can be driven to dynamically adjust the heating amount according to the ambient temperature, thereby improving energy utilization efficiency. Its IP66 protection level can adapt to humid and dusty environments such as outdoor pump stations and underground computer rooms.


Key points for installation and maintenance

1. Installation specifications

-The module needs to be installed on a DIN rail or dedicated substrate, and the installation position should be away from strong electromagnetic interference sources (such as large transformers, frequency converters) and high-temperature heat sources (such as steam pipelines). It is recommended to maintain a distance of ≥ 10cm from other heating equipment to ensure good heat dissipation;

-When wiring, it is necessary to strictly distinguish between the power supply end, signal output end, and communication interface. Redundant power supplies need to be connected to different circuits separately to ensure power supply reliability; It is recommended to use shielded twisted pair cables for analog output lines, with the shielding layer grounded at one end to reduce signal interference;

-When installing outdoors, it is necessary to use a sealed control cabinet to ensure that the environmental humidity does not exceed 95% and to avoid direct contact of condensed water with the module; In high-altitude areas (≥ 3000m), the impact of air pressure on insulation performance needs to be considered, and if necessary, measures to strengthen insulation should be taken.

2. Daily maintenance and troubleshooting

-Regularly (recommended monthly) check the status of module indicator lights. If there are flashing power lights, constant communication lights, or channel fault lights, it is necessary to promptly identify the corresponding fault points;

-For scenarios with high levels of dust (such as metallurgical workshops), it is necessary to clean the module casing and wiring terminals of accumulated dust every quarter. Dry compressed air can be used for blowing to avoid poor contact or decreased insulation performance caused by dust;

-When the signal output deviation is too large, the channel parameters can be calibrated through configuration software; If the module cannot communicate, priority should be given to checking the connection of communication cables and the switching status of redundant links. If necessary, specialized debugging tools should be used to check the compatibility of communication protocols;

-When replacing the module, genuine accessories of the same model should be used. Before replacement, the corresponding power circuit should be cut off to avoid module damage caused by improper hot plugging operations.
