  • YOKOGAWA 16137-222 Process Controller
    ❤ Add to collection
  • YOKOGAWA 16137-222 Process Controller

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    YOKOGAWA 16137-222 is a high-precision digital process control module developed by Yokogawa Electric in Japan specifically for the field of industrial automation. Its core positioning is precise measurement and closed-loop control of process parameters, and it is widely applicable to the integration needs of various industrial automation systems. This module relies on Yokogawa Electric's profound technical accumulation in the field of industrial control, using high stability components and precision signal processing circuits. It can continuously output reliable measurement data and control instructions in complex and harsh industrial environments, providing core guarantees for the stability, efficiency, and safety of the production process. Its design philosophy takes into account measurement accuracy, environmental adaptability, and system compatibility, and can quickly integrate into existing automation architectures such as DCS (distributed control system) and PLC (programmable logic controller), effectively reducing the cycle and cost of system upgrades and renovations.

    • ¥17348.00
      ¥18045.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.390KG
    • Quantity:
    • (Inventory: 99999)
Description

YOKOGAWA 16137-222 is a high-precision digital process control module developed by Yokogawa Electric in Japan specifically for the field of industrial automation. Its core positioning is precise measurement and closed-loop control of process parameters, and it is widely applicable to the integration needs of various industrial automation systems. This module relies on Yokogawa Electric's profound technical accumulation in the field of industrial control, using high stability components and precision signal processing circuits. It can continuously output reliable measurement data and control instructions in complex and harsh industrial environments, providing core guarantees for the stability, efficiency, and safety of the production process. Its design philosophy takes into account measurement accuracy, environmental adaptability, and system compatibility, and can quickly integrate into existing automation architectures such as DCS (distributed control system) and PLC (programmable logic controller), effectively reducing the cycle and cost of system upgrades and renovations.


YOKOGAWA 16137-222 Process Controller

Product Overview

YOKOGAWA 16137-222 is a high-precision digital process control module developed by Yokogawa Electric in Japan specifically for the field of industrial automation. Its core positioning is precise measurement and closed-loop control of process parameters, and it is widely applicable to the integration needs of various industrial automation systems. This module relies on Yokogawa Electric's profound technical accumulation in the field of industrial control, using high stability components and precision signal processing circuits. It can continuously output reliable measurement data and control instructions in complex and harsh industrial environments, providing core guarantees for the stability, efficiency, and safety of the production process. Its design philosophy takes into account measurement accuracy, environmental adaptability, and system compatibility, and can quickly integrate into existing automation architectures such as DCS (distributed control system) and PLC (programmable logic controller), effectively reducing the cycle and cost of system upgrades and renovations.


Core technical parameters

The technical parameters of this module have undergone strict industrial level verification to ensure performance stability under full working conditions. The specific parameters are as follows:

2.1 Basic specifications

-Brand and Model: YOKOGAWA (Yokogawa Electric) 16137-222

-Module type: high-precision analog measurement and control module

-Power parameters: The power supply voltage is 24V DC (direct current), with a wide voltage compatibility range of ± 10% and a power consumption of ≤ 13W. It supports reverse connection protection design to avoid module damage caused by wiring errors

-Protection level: IP67 protection, completely dust-proof and can be immersed in 1 meter deep water for 30 minutes without affecting performance. It can effectively resist the erosion of dust, water vapor, oil stains, etc. in industrial sites

-Appearance and Installation: Adopting standard rail installation design, compatible with DIN rail specifications, compact in size (specific dimensions can refer to the product nameplate), easy to densely layout inside the control cabinet; The installation direction can be flexibly adjusted without affecting the measurement accuracy

2.2 Measurement of Performance Parameters

-Measurement accuracy: ± 0.02% full scale (F.S.), industry-leading error control accuracy within the full measurement range, ensuring the accuracy of process parameter measurement; Reading error ≤ ± 0.1%, further improving data reliability

-Input range: Supports multiple types of analog inputs (specific input signal types can be configured), compatible with commonly used industrial 4-20mA current signals, 0-10V voltage signals, etc. Input impedance ≥ 1M Ω (voltage input), ≤ 50 Ω (current input)

-Response time: ≤ 1 millisecond (ms), capable of quickly capturing instantaneous changes in process parameters, suitable for process scenarios with high dynamic response requirements (such as rapid pressure regulation, flow closed-loop control, etc.)

-Resolution: 16 bit A/D conversion accuracy, able to accurately distinguish small parameter changes, providing data support for fine control

2.3 Environmental adaptability parameters

-Working temperature range: -40 ℃ to+85 ℃, can work stably in extremely cold (such as outdoor industrial scenes in the north) and high temperature (such as around metallurgical and chemical kilns) environments; The core circuit has temperature compensation function, and the accuracy drift can be ignored within the commonly used temperature range of -20 ℃ to+70 ℃

-Storage temperature range: -50 ℃ to+90 ℃, convenient for storage and long-distance transportation, no special temperature control measures required

-Humidity adaptation range: 5% RH to 95% RH (non condensing), suitable for high humidity environments (such as paper and food processing workshops) and dry environments (such as electronic component production workshops)

-Anti interference performance: With EMC (Electromagnetic Compatibility) industrial certification, the ability to resist electromagnetic radiation (EMI) and electromagnetic conduction (EMS) meets the IEC 61000 standard, and can resist electromagnetic interference generated by industrial field frequency converters, motors, and other equipment

2.4 Communication Parameters

-Supporting Protocol: Standard Modbus RTU communication protocol, using RS-485 bus interface, data transmission rate can be flexibly configured between 9600bps and 115200bps

-Communication distance: Maximum communication distance of 1200 meters (shielded twisted pair), supports multiple module cascading, and can connect up to 32 slave devices

-Data format: configurable 8-bit/7-bit data bits, 1-bit/2-digit stop bits, supports odd parity, even parity, or no parity, suitable for communication needs of different systems


Key performance characteristics

3.1 Ultra high measurement accuracy to ensure process control precision

The module adopts precise signal conditioning circuits and temperature compensation algorithms to control the measurement accuracy within ± 0.02% of the full range, with a reading error of ≤± 0.1%, far superior to conventional control modules in the industry. This high-precision performance enables the module to accurately capture subtle changes in process parameters such as pressure, temperature, flow rate, liquid level, etc., providing accurate feedback signals for closed-loop control, effectively avoiding control deviations caused by measurement errors, and thereby improving the consistency of product quality. For example, in the temperature control scenario of chemical reaction vessels, the temperature fluctuation range can be controlled within ± 0.1 ℃ to ensure the stability of the reaction process.

3.2 Wide range environment adaptation, suitable for harsh industrial scenarios

With an IP67 protection design and a wide operating temperature range of -40 ℃ to+85 ℃, this module can handle various harsh industrial environments with ease. In scenarios such as dust intensive metallurgical workshops, water vapor rich paper-making workshops, and low-temperature outdoor pumping stations, stable operation can be achieved without the need for additional protective devices. Its shell is made of high-strength engineering plastic, which has impact resistance and corrosion resistance characteristics, and can resist mechanical collisions and chemical media erosion in industrial sites, significantly improving the service life and operation efficiency of the equipment.

3.3 Flexible communication compatibility, simplifying system integration

The module comes standard with Modbus RTU industrial universal communication protocol, which can seamlessly interface with mainstream PLC, DCS, SCADA (data acquisition and monitoring system) and other devices without the need for additional dedicated communication modules or protocol converters. Through simple parameter configuration, data exchange with the upper system can be completed, enabling the upload of measurement data and the issuance of control instructions. At the same time, its wide communication speed and flexible data format configuration further enhance compatibility with automation systems of different brands and eras, reducing the technical difficulty and cost of system integration.

3.4 High reliability design to reduce operation and maintenance costs

The module adopts high-quality components and redundant design, and the key circuits have overvoltage, overcurrent, and reverse connection protection functions, which can effectively avoid equipment damage caused by power supply abnormalities, wiring errors, etc. At the same time, the product has undergone rigorous aging testing and environmental reliability testing, with an average time between failures (MTBF) of ≥ 100000 hours, significantly reducing equipment failure rates and downtime maintenance costs. In addition, the self diagnostic function of the module can monitor its own working status in real time, and output alarm signals in a timely manner when faults occur, which is convenient for operation and maintenance personnel to quickly locate and handle problems.

3.5 Convenient installation and debugging to improve deployment efficiency

Adopting standard DIN rail installation method, the installation process is simple and fast, without the need for professional tools; The wiring terminals of the module adopt a plug-in design, which is convenient for on-site wiring and later maintenance. During the debugging process, the measurement range, communication parameters, alarm thresholds, etc. of the module can be remotely configured through the upper system or specialized debugging tools, without the need for on-site disassembly of equipment, greatly reducing the installation and debugging cycle. At the same time, the indicator lights of the module can intuitively reflect the power supply status, communication status, and fault status, making it easy for on-site personnel to quickly judge the operation status of the equipment.
