ABB 560RCR01 Remote Terminal Units
ABB 560RCR01 Remote Terminal Units
Product Overview
The ABB 560RCR01 is a real-time clock GPS module designed specifically for the RTU560 series, which is capable of synchronising the RTU560 with the standard time of GPS satellites. This remote terminal unit is not only equipped with accurate time synchronisation, but also with powerful communication and data processing capabilities, suitable for a variety of industrial automation and remote monitoring applications.
Main Functions
Time synchronisation:
Receive standard time information through GPS satellite and synchronise the internal time of RTU560 with the standard time.
The use of high-precision quartz clocks continues to provide time service when the GPS signal is interrupted, ensuring time continuity.
Communication Interface:
Provides serial data interface RS232 for reading time, date and status information.
Supports connection to the RTU560 system bus for transmission and synchronisation of time information.
Status Indication:
Four light-emitting diodes (LEDs) are provided on the front panel to indicate the status of board alarms, free running (not synchronised with GPS), minute pulses and position lock.
Minute Pulse Output:
In addition to the minute pulse output for RTU560 synchronisation, an additional minute pulse output is provided, which is connected to the module via an optocoupler.
Technical specifications
Input Voltage: Typically matched to the power supply unit of the RTU560 rack.
Output Voltage: Provides the voltage used to drive the internal circuitry and LED indicators.
Size: Compact design allows for easy mounting in the RTU560 rack.
Weight: Lightweight design for easy installation and maintenance.
Operating Temperature: Suitable for a variety of harsh industrial environments with a wide operating temperature range.
Application Scenarios
ABB 560RCR01 Remote Terminal Unit is widely used in industrial automation fields that require precise time synchronisation and remote monitoring. For example, in the power system, water conservancy system, municipal dispatching and other industries, it can provide reliable time synchronisation and data processing support for a variety of remote monitoring and data acquisition systems.
Installation and Maintenance
Installation: Install the ABB 560RCR01 module on the RTU560 rack and connect the corresponding power supply and communication interface. Ensure that the antenna can receive signals from at least one GPS satellite for time synchronisation.
Maintenance: Regularly check the module's operating status and the status of the LED indicators. In case of GPS signal interruption, pay attention to check the antenna connection and the surrounding environment for interference. Clean and maintain the module regularly to ensure its long-term stable operation.
Technical features
Programmability: Users can program and customise the module according to specific application requirements to achieve precise control of industrial processes and improve productivity and product quality.
Integration and compatibility: The module can be seamlessly integrated with other ABB products and solutions to form a unified automation platform. It also has excellent compatibility with other manufacturers' equipment and systems.
High performance and reliability: High-performance hardware and software are used to ensure stable operation and efficient control in industrial environments. With advanced fault detection and diagnostic functions, potential problems can be detected and dealt with in a timely manner, improving the reliability of the system.
Flexibility and expandability: with modular design, it can be flexibly configured and expanded according to actual needs. Whether it is a small or large project, it can be easily integrated into the existing automation system.
Easy to use and maintain: Provides an intuitive user interface and powerful diagnostic tools, enabling users to operate and maintain with ease.
Application Functions
Multi-functional control: The module can perform a variety of control functions, including logic control, motion control, temperature control, etc., to meet the needs of different application scenarios.
Digital control: Provides digital control functions that allow users to programmatically define and execute control logic to achieve precise control of complex industrial processes.
Communication Capability: Supports a variety of digital communication protocols, such as Ethernet, Profibus, Modbus, etc., in order to communicate with other devices, monitoring systems, or upper level control systems, and to achieve centralised management and monitoring of all parts of the system.
PLC Integration: Compatible and able to be integrated into ABB or other manufacturers' PLC systems to achieve seamless integration and overall synergy with other automation equipment and control systems.
