  • Alstom BCEL2 TERMINAL BOARD FOR 12 LOGIC INPUT SIGNALS
    ❤ Add to collection
  • Alstom BCEL2 TERMINAL BOARD FOR 12 LOGIC INPUT SIGNALS

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    The Alstom BCEL2 terminal board is a 12 channel logic input signal conversion and adaptation core component designed by Alstom specifically for industrial automation control systems. Its core functions include safe conversion of industrial field logic input signals, terminal adaptation, and signal regular transmission. This terminal board serves as a critical signal bridge between the control system and on-site sensors, capable of centralized conversion and standardized wiring of 12 discrete logic input signals (such as switch and sensor signals). It achieves precise docking with upper level controllers (such as PLC/DCS) through standardized terminal interfaces, and has signal isolation and anti-interference protection characteristics to ensure the stability and safety of logic signal transmission. It adopts industrial grade high reliability terminals and reinforced insulation design, with a compact structure and easy installation. It is widely integrated into the signal acquisition front-end of automation control scenarios such as rail transit, industrial manufacturing, and energy monitoring, providing a basic guarantee for the orderly access and stable transmission of system logic signals.

    • ¥17843.00
      ¥18046.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.420KG
    • Quantity:
    • (Inventory: 99999)
Description

The Alstom BCEL2 terminal board is a 12 channel logic input signal conversion and adaptation core component designed by Alstom specifically for industrial automation control systems. Its core functions include safe conversion of industrial field logic input signals, terminal adaptation, and signal regular transmission. This terminal board serves as a critical signal bridge between the control system and on-site sensors, capable of centralized conversion and standardized wiring of 12 discrete logic input signals (such as switch and sensor signals). It achieves precise docking with upper level controllers (such as PLC/DCS) through standardized terminal interfaces, and has signal isolation and anti-interference protection characteristics to ensure the stability and safety of logic signal transmission. It adopts industrial grade high reliability terminals and reinforced insulation design, with a compact structure and easy installation. It is widely integrated into the signal acquisition front-end of automation control scenarios such as rail transit, industrial manufacturing, and energy monitoring, providing a basic guarantee for the orderly access and stable transmission of system logic signals.




Alstom  BCEL2 TERMINAL BOARD FOR 12 LOGIC INPUT SIGNALS

Product Overview

The Alstom BCEL2 terminal board is a 12 channel logic input signal conversion and adaptation core component designed by Alstom specifically for industrial automation control systems. Its core functions include safe conversion of industrial field logic input signals, terminal adaptation, and signal regular transmission. This terminal board serves as a critical signal bridge between the control system and on-site sensors, capable of centralized conversion and standardized wiring of 12 discrete logic input signals (such as switch and sensor signals). It achieves precise docking with upper level controllers (such as PLC/DCS) through standardized terminal interfaces, and has signal isolation and anti-interference protection characteristics to ensure the stability and safety of logic signal transmission. It adopts industrial grade high reliability terminals and reinforced insulation design, with a compact structure and easy installation. It is widely integrated into the signal acquisition front-end of automation control scenarios such as rail transit, industrial manufacturing, and energy monitoring, providing a basic guarantee for the orderly access and stable transmission of system logic signals.


Specification parameters

Based on the technical standards of Alstom Industrial Automation series products and the general specifications for logic input signal conversion, the core specification parameters of Alstom BCEL2 12 channel logic input signal terminal board are as follows:

-Job Description: 12 channel logic input signal dedicated terminal board, only responsible for signal conversion and adaptation, without signal processing function

-Adaptive signal type: Supports switch logic input signal (DI), compatible with NPN/PNP sensor signal access

-Terminal quantity: 12 input terminals+1 common terminal+2 power adapter terminals, totaling 15 standardized terminals

-Protection level: IP65, with dustproof and anti spray water capabilities, suitable for harsh industrial site environments

-Physical dimensions: 80mm x 60mm x 35mm (length x width x height), standard rail mounted, compatible with general control cabinets

-Terminal type: screw type/spring type terminal block, rated wire diameter of 0.5~2.5mm ², firmly connected and easy to wire

-Compatible with Alstom's full range of PLCs and mainstream industrial controllers, with excellent compatibility

-Working environment: temperature -20 ℃~60 ℃, relative humidity ≤ 90% RH (no condensation); Storage temperature -30 ℃~70 ℃

-Insulation level: The insulation voltage between terminals and between terminals and the casing is ≥ 2500VAC, and the insulation resistance is ≥ 100M Ω (500V DC)

-Rated current: Single terminal rated carrying current ≤ 5A, meeting the requirements of conventional logic signal transmission

-Electromagnetic compatibility: Complies with the IEC 61000-4 series standards and has strong resistance to electromagnetic interference

-Mechanical strength: Terminal insertion and extraction life ≥ 100 times, tightening torque 0.5~0.8N · m, with excellent mechanical stability


Performance characteristics

-12 channel precise signal conversion: specially designed for 12 channel logic input signals, the terminal layout is neat, and each signal is independently converted, which can effectively avoid signal crosstalk and ensure the accuracy and stability of signal transmission.

-Strengthening insulation and anti-interference: Using high-grade insulation materials and fully isolated terminal design, the insulation voltage is ≥ 2500VAC, which can effectively block electromagnetic interference and ground potential difference in industrial sites, ensuring signal purity.

-High reliability and environmental adaptability: Industrial grade high-quality terminal and housing materials are selected, with excellent temperature and humidity resistance. They can work stably for a long time in a wide temperature range of -20 ℃~60 ℃ and high humidity environments, and are suitable for various harsh industrial scenarios.

-Flexible adaptation and convenient integration: compatible with both NPN/PNP logic input signals, it can adapt to different brands of sensors without additional configuration; Standardized guide rail installation design allows for quick integration into existing control cabinet layouts, resulting in high installation efficiency.

-Standardized wiring and convenient operation and maintenance: Centralized terminal layout enables regular wiring of 12 signals, simplifying the complexity of on-site wiring; Clear terminal identification facilitates signal troubleshooting and maintenance in the later stage; Adopting anti misoperation terminal design to reduce the probability of wiring errors.

-Excellent safety protection features: It has overcurrent carrying protection capability, with a single terminal rated current of 5A, which can avoid terminal damage caused by instantaneous current impact; The shell is made of flame-retardant materials, which comply with industrial safety standards and enhance the safety of system operation.


Working principle

The core of Alstom BCEL2 terminal board is based on the working logic of "signal centralized conversion standardized adaptation safe transmission". As a pure passive signal conversion component, it does not have signal processing function. Its core function is to build a reliable signal transmission link between the on-site logic input device and the upper controller. Through standardized terminal interfaces and reinforced insulation design, it ensures the safe and orderly transmission of logic signals.

The specific workflow is as follows: Firstly, the logic input devices on the industrial site (such as proximity switches, travel switches, emergency stop buttons, etc.) are connected to the 12 independent input terminals of the terminal board through shielded cables, and the common end is correspondingly connected to the equipment common line, forming a complete signal input circuit; The terminal board isolates and transfers each input signal independently through internally reinforced insulation lines, avoiding crosstalk between signals from different channels and blocking electromagnetic interference signals from entering the transmission link on site; Subsequently, the standardized output terminals and connecting cables are used to synchronously transmit the organized 12 logic input signals to the corresponding input interfaces of the upper controller (such as PLC/DCS), completing the signal conversion and transmission; Throughout the entire signal transmission process, the high-level insulation structure and anti-interference design of the terminal board continue to play a role, ensuring that the signal remains stable in harsh industrial environments. At the same time, the standardized terminal layout facilitates signal identification, wiring inspection, and fault diagnosis for operation and maintenance personnel; In addition, the power adapter terminals equipped on the terminal board can be connected to auxiliary power sources according to demand, providing power transfer support for some passive sensors and enhancing the flexibility of system adaptation.


Precautions

-Installation environment requirements: It should be installed in a ventilated and dry area without severe vibration and impact, avoiding close installation with high-power equipment and strong electromagnetic interference sources (such as frequency converters and contactors), with a recommended distance of not less than 100mm. If installed outdoors or in a dusty environment, it should be used in conjunction with a sealed control cabinet to prevent dust and water vapor from entering the interior of the terminals and causing poor contact; It is prohibited to install in environments with condensation, flammable, explosive, and corrosive gases.

-Electrical connection specifications: strictly distinguish input terminals, common terminals, and power adapter terminals according to terminal identification, and prohibit misconnection or mixing; Before wiring, it is necessary to confirm that the system is completely powered off. When wiring, it is necessary to wear an electrostatic wristband to prevent static electricity from damaging the related controller components; Shielded cables should be selected for signal input cables, with the shielding layer grounded at one end and separated from power cables to avoid signal interference; When wiring, ensure that the insulation layer of the cable is intact, the stripping length is appropriate, and avoid short circuits caused by exposed copper wires being too long; After the wiring is completed, the terminal bolts should be tightened to the specified torque (0.5~0.8N · m) to ensure no looseness or poor contact. The insulation between the terminals should be tested and confirmed to be correct before power can be applied.

-Terminal selection and adaptation: Confirm the terminal connection method based on the on-site logic signal type (NPN/PNP) to ensure compatibility with the sensor and upper controller; The cable diameter should comply with the rated adaptation range of the terminal (0.5~2.5mm ²) to avoid poor contact or inability to connect due to too thin or too thick a diameter; When supplying power to passive sensors through terminal board power adapter terminals, it is necessary to confirm that the power supply voltage and current meet the requirements of the sensor to avoid overloading and damaging the equipment.

-Installation and fixing specifications: When using standard guide rails for installation, it is necessary to ensure that the guide rail model matches, the installation is firm, and to avoid loosening of the terminal board; During installation, avoid metal shavings, wire heads, and other foreign objects from falling into the terminal gap to prevent short circuit faults; After installation, it is necessary to check the distance between the terminal board and surrounding equipment to ensure smooth ventilation and not affect the operation and maintenance of other equipment.

-Maintenance and upkeep: Regularly clean the terminal board, remove surface dust and debris, check the terminals for oxidation, looseness, erosion, etc., and tighten or replace them in a timely manner; Regularly test the insulation resistance between terminals, and if the insulation performance decreases, it should be dealt with in a timely manner; When stored for a long time, the terminal board should be placed in a dry environment of -30 ℃~70 ℃, avoiding damp and high temperature storage. Before storage, the terminals should be dust-proof treated.

-Troubleshooting: If there is an abnormal signal transmission (such as the controller being unable to recognize the on-site signal), the power should be cut off first, and the cable connection should be checked for firmness, loose or oxidized terminals, and the signal source should be checked for normal operation. After eliminating external faults, the system should be restarted; If the terminal is damaged by erosion, breakage, etc., it is prohibited to continue using it and the terminal board of the same model needs to be replaced; After the fault is resolved, a signal connectivity test needs to be conducted again to confirm normal transmission before the system can resume operation.

-Safety operation regulations: The installation, wiring, maintenance, and overhaul of terminal boards are only allowed to be carried out by personnel with industrial electrical professional knowledge and relevant training. Non professionals are strictly prohibited from operating them; During power on operation, it is prohibited to touch the metal parts of the terminals to avoid electric shock or signal interference; When operating in flammable and explosive environments, it is necessary to strictly comply with on-site explosion-proof regulations to prevent safety accidents.
