GE DS200TCDAG1AEA Advanced Digital I/O Board for Industrial Automation

GE DS200TCDAG1AEA Advanced Digital I/O Board for Industrial Automation

Product Type:Digital IO Board Series:Mark V Model Number:DS200TCDAG1AEA Module Size:1U Input/Output Channels:48 Bit Depth:16 Operating Temperature:-40"C to 70"C Power Supply Range:90VAC to 264VAC Dimensions (WxHxD):17.5cm x 4.4cm x 3.4cm Weight:0.6kg The GE-FANUC DS200TCDAG1AEA Digital Input/Output Board is specifically engineered to enhance operational efficiency in industrial settings by facilitating precise control over digital signals. Its robust design ensures reliable performance even under harsh environmental conditions, making it suitable for applications where durability and reliability are paramount.

 Equipped with 16 digital inputs and 16 outputs, this board supports a wide range of functions, enabling complex system interactions and data processing. Each channel is capable of handling up to 50mA current, ensuring compatibility with various devices and peripherals. With a response time of less than 1 millisecond, this board guarantees quick and accurate signal transmission, which is crucial for real-time control systems. It operates within a temperature range of -20"C to +60"C, allowing seamless integration into a variety of industrial environments.

 Designed with user-friendliness in mind, the GE-FANUC DS200TCDAG1AEA Digital Input/Output Board features a compact size of 24mm x 146mm, making it easy to fit into existing systems without compromising on functionality. Its CE, UL, CSA, and TUV compliance ensures safety and regulatory adherence across different jurisdictions. The use of high-quality materials and advanced manufacturing techniques ensures long-term reliability and minimal maintenance requirements, making it an ideal choice for demanding industrial applications. This board is a testament to GE-FANUC  commitment to delivering top-tier solutions that drive productivity and innovation in the manufacturing sector. Engineered for precision and reliability, the GE DS200TCDAG1AEA Digital Input/Output Board delivers robust control capabilities in industrial automation environments.

Compatibility

ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave

ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module
