DS3800HMHA | General Electric Microprocessor Controller Board Mark IV

DS3800HMHA | General Electric Microprocessor Controller Board Mark IV

Product Description P/N: DS3800HMHADESCRIPTION / SPECIFICATIONSDescriptionThe DS3800HMHA is a Microprocessor Controller Board for the Mark IV system by General Electric. It is designed to manage and control microprocessor operations within the system. The board integrates various components and circuits to facilitate precise control and processing tasks.

It is utilized in Mark IV systems to ensure reliable performance and operational integrity.Technical SpecificationsCondition New / Never Used SurplusPart Number DS3800HMHAManufacturer General ElectricSeries Mark IVProduct Type Microprocessor Controller BoardNumber of Channels 12Operating Temperature -30 to 55 degrees CelsiusSize 8.25 cm high x 4.18 cmInformation About DS3800HMHAThe DS3800HMHA is a board component designed by General Electric (GE) to be part of a Speedtronic turbine control system. This board is part of the Mark IV control system. The Mark IV was first introduced in 1984 as the first Speedtronic system offering triple modular redundant control, a significant improvement over previous Speedtronic systems.The DS3800HMHA functions as an MH controller.

The board weighs 0.63 pounds. It includes two extractor clips that have been inserted into the two front corners of the board. These extractor clips allow the board to be more easily pulled from its place within a rack system when it is time to replace or repair it. This board edge also includes two right-angled connectors that both include clips to hold cables secure. Additionally, this edge has three LED indicators. Two of these indicators are red while the other is yellow.Manufacturer informationGeneral Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power.

 GE is known for its innovations in technology, manufacturing, and infrastructure solutions.IQElectro is not an authorized distributor.QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
