GE DS3820EPSA1A1A Precision Engineered Circuit Board for Advanced Industrial Control Systems

DS3820EPSA1A1A Precision Engineered Circuit Board for Advanced Industrial Control Systems

Ports:Two ports, featuring a larger female terminal with five additional ports for versatile connection options Box Design:Features a robust, large black box on one edge of the circuit board, enhancing stability and durability Installation Method:Easy to install with four slide-in screw ports, ensuring secure attachment without compromising access Brand Support:Initially provided technical support by General Electric, ensuring compatibility and reliability Dimensions:Specific dimensions not provided, refer to original manufacturer  manual for accurate measurements Weight:Weight not specified, consult the manual for precise information The GE DS3820EPSA1A1A Circuit Board is a robust and reliable component designed to enhance the performance of speedtronics and turbine control systems.

It is equipped with an innovative black box design on the circuit board for efficient signal processing and management. Ease of installation is ensured with the use of four slide-in screw ports, making it a convenient solution for system integrators and maintenance personnel. This circuit board supports up to seven ports, providing flexibility in connecting various components of industrial systems. Its compatibility with a wide range of applications ensures seamless integration into existing infrastructure.

 Manufactured by General Electric, this product benefits from decades of experience in power generation and control systems. It adheres to strict quality standards and is backed by a comprehensive warranty for peace of mind. For optimal performance and longevity, we recommend following the original manufacturer  guidelines for installation and maintenance. Technical support for the DS3820EPSA1A1A is available through AX Control, ensuring quick assistance for any queries or issues. The GE DS3820EPSA1A1A Control Board is a critical component for industrial automation systems, ensuring precise control and efficient operation across a wide range of applications.

OTHER INFORMATION

• Up to 1.26 GHz Pentium® III processor with 256 KB advanced  transfer cache

• Up to 512 MB PC-133 SDRAM using a single SODIMM

• Internal AGP SVGA controller with 4 MB display cache

• 133 MHz system bus via Intel® 815E chipset

• Dual Ethernet controllers supporting 10BaseT and 100BaseTX  interfaces

• Optional PCI dual channel Ultra160 SCSI

• Up to three (two with rear I/O support) PMC expansion sites  (IEEE-P1386 common mezzanine card standard, 5 V)

• Up to 1 GB bootable flash on secondary IDE (optional)

• Two 16-bit and two 32-bit programmable timers

• 32 KB of nonvolatile SRAM

• Software-selectable watchdog timer with reset

• Remote Ethernet booting

• Optional IDE hard disk drive

• VME64 modes supported:  A32/A24/D32/D16/D08(EO)/MBLT64/BLT32

• VMEbus interrupt handler, interrupter and system controller

• Includes real time endian conversion hardware for littleendian and big-endian data interfacing (patent no. 6,032,212)

• Enhanced bus error handling

• Passive heat sink
