  • ABB DSTA131 2668180-48/2 Programmable Logic Controller
    ❤ Add to collection
  • ABB DSTA131 2668180-48/2 Programmable Logic Controller

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    ABB DSTA131 2668180-48/2 belongs to modular programmable logic controllers, and its model number "2668180-48/2" is a product exclusive identifier used to accurately distinguish derived models with different configurations. This product is developed based on ABB's mature PLC technology platform, with the core design concept of "compact structure+stable control". It can achieve the acquisition, processing, and output control of various digital and analog signals in industrial sites, providing a complete automation control solution for single equipment or small production lines.

    • ¥7848.00
      ¥8878.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:1.470KG
    • Quantity:
    • (Inventory: 99999)
Description

ABB DSTA131 2668180-48/2 belongs to modular programmable logic controllers, and its model number "2668180-48/2" is a product exclusive identifier used to accurately distinguish derived models with different configurations. This product is developed based on ABB's mature PLC technology platform, with the core design concept of "compact structure+stable control". It can achieve the acquisition, processing, and output control of various digital and analog signals in industrial sites, providing a complete automation control solution for single equipment or small production lines.


ABB DSTA131 2668180-48/2 Programmable Logic Controller

Product Overview

ABB DSTA131 2668180-48/2 belongs to modular programmable logic controllers, and its model number "2668180-48/2" is a product exclusive identifier used to accurately distinguish derived models with different configurations. This product is developed based on ABB's mature PLC technology platform, with the core design concept of "compact structure+stable control". It can achieve the acquisition, processing, and output control of various digital and analog signals in industrial sites, providing a complete automation control solution for single equipment or small production lines.

Compared with traditional relay control systems, this model of PLC not only greatly simplifies the wiring process and reduces equipment failure rates, but also supports rapid modification and upgrading of control logic through flexible program editing functions, greatly improving the flexibility and scalability of the production process.


Core performance parameters

Performance parameters are the core basis for PLC adaptation to industrial scenarios. DSTA131 2668180-48/2 exhibits balanced performance in key performance indicators and can meet most mid to low end control requirements. Specific parameters are as follows (subject to the latest official technical manual):

1. Core control unit

-Processor performance: Adopting ABB's dedicated embedded processor, it has fast computing speed, supports millisecond level instruction execution, can efficiently process complex control logic, and meets real-time control requirements.

-Memory configuration: Built in program memory and data memory, program storage capacity meets the needs of small and medium-sized control programs, and data memory supports real-time storage of a large number of intermediate variables and state parameters.

-Programming Language: Supports IEC 61131-3 standard programming languages, including ladder diagram (LD), functional block diagram (FBD), structured text (ST), etc., adapted to the programming habits of different engineers, facilitating program development and maintenance.

2. Input/Output (I/O) Configuration

As a core functional module, its I/O configuration directly determines the control range, and "48/2" usually represents the characteristics of key I/O nodes (as defined by the official definition):

-Digital input: Supports multiple DC digital inputs, compatible with common sensor signals in industrial fields (such as photoelectric sensors, proximity switches, etc.), input voltage range compatible with standard industrial levels such as 24V DC, with anti surge and anti-interference design.

-Digital output: Provides multiple relay or transistor outputs, which can directly drive actuators such as contactors and solenoid valves. The output capacity meets the requirements of conventional industrial loads, and some output channels support overload protection function.

-Analog Expansion: Supports the integration of analog signals (such as temperature, pressure, flow, etc.) through expansion modules, adapting to standard analog signal types such as 4-20mA and 0-10V, to meet the acquisition and control requirements of continuous parameter in process control.

3. Communication and expansion capabilities

-Communication interface: Equipped with standard communication interfaces (such as RS485, Ethernet, etc.), supporting mainstream industrial communication protocols such as MODBUS and PROFINET, it can achieve interconnection and intercommunication with HMI (human-machine interface), frequency converter, sensors and other peripheral devices, facilitating the construction of distributed control systems.

-Scalability: Supports connecting I/O modules, communication modules, etc. through a dedicated expansion bus, which can flexibly expand the system scale according to actual control needs, break through the functional limitations of basic units, and improve the adaptability of the system.

4. Environmental adaptability

The industrial site environment is complex, and this model of PLC has been specifically designed for environmental adaptability:

-Working temperature: Supports a wide range of working temperatures (usually 0-60 ℃) and can adapt to the temperature environment of most industrial workshops.

-Anti interference performance: It has good electromagnetic compatibility (EMC) and has been certified by relevant industrial electromagnetic compatibility standards, which can effectively resist electromagnetic interference in industrial sites and ensure stable operation of equipment.

-Protection level: The protection level of the module casing meets industrial standards (such as IP20) and is suitable for installation inside control cabinets to avoid direct erosion by dust and water vapor.


Core functional features

1. High reliability and stability

ABB PLC has always been known for its high reliability. DSTA131 2668180-48/2 uses industrial grade components and has undergone strict environmental stress testing and life testing, with a long mean time between failures (MTBF). At the same time, it has a comprehensive self diagnostic function that can monitor module status, I/O channel faults, etc. in real time, making it easy for engineers to quickly locate problems and reduce downtime losses.

2. Strong usability

This model of PLC is equipped with ABB specific programming software (such as ABB Automation Builder), which has a friendly software interface and integrates functions such as program editing, compilation, download, and monitoring. It supports online debugging and parameter modification, greatly improving development efficiency. In addition, the software has a rich library of built-in functional blocks (such as timers, counters, PID control blocks, etc.) that can be directly called, simplifying the development process of complex control logic.

3. Flexible control functions

In addition to basic logic control functions, this model of PLC also supports various special control functions, such as PID process control, sequence control, pulse output control, etc. It can be widely used in temperature regulation, pressure stability, equipment start stop sequence control and other scenarios to meet the control needs of different industrial processes.

4. Cost economy

For the mid to low end automation market, DSTA131 2668180-48/2 effectively controls product costs while ensuring core performance. Its modular design facilitates on-demand configuration and avoids cost waste caused by functional redundancy, providing a cost-effective solution for small and medium-sized enterprises or single device automation upgrades.


Applicable scenarios

Based on its performance characteristics, DSTA131 2668180-48/2 is widely used in various mid to low end industrial automation scenarios, mainly including:

1. Control of manufacturing production lines: such as food and beverage production lines, packaging machinery, electronic component assembly lines, etc., to achieve control functions such as sequential start stop, action linkage, and quality inspection of equipment.

2. Automation of standalone equipment: such as injection molding machines, CNC machine tools, printing machinery, etc., by collecting equipment status parameters, automatic operation, parameter adjustment, and fault alarm of the equipment can be achieved.

3. In the field of process control, such as small-scale chemical reactors, water treatment equipment, HVAC systems, etc., PID control functions are used to achieve stable control of parameters such as temperature, pressure, and flow rate.

4. Warehousing and logistics equipment: such as conveyor belts, stackers, sorting equipment, etc., to achieve start stop control, position positioning, and coordinated linkage of the equipment.

5. Municipal and civil automation: such as sewage treatment plants, garbage transfer stations, building automation systems, etc., to meet the stable operation requirements of small-scale control systems.


Precautions for use

1. Installation specifications: It is necessary to strictly follow the requirements of the product manual for installation, ensure good ventilation inside the control cabinet, avoid close installation with strong electromagnetic interference equipment (such as frequency converters), and ensure that the module wiring is firm to prevent loosening and poor contact.

2. Power configuration: It is necessary to connect a power supply that meets the specifications. It is recommended to equip it with a regulated power supply or UPS (uninterruptible power supply) to avoid damage to the equipment caused by voltage fluctuations or sudden power outages, while ensuring that the power circuit has overload protection function.

3. Program management: During the programming process, it is necessary to follow standardized programming logic to avoid redundant code affecting running efficiency; Before downloading the program, sufficient testing must be conducted to prevent logical errors from causing device malfunctions; At the same time, regularly backup control programs for easy fault recovery.

4. Daily maintenance: Regularly inspect PLC and expansion modules, clean surface dust, and check whether the wiring terminals are loose; Regularly monitor the operating status of equipment using programming software, and promptly identify and address potential faults.
