    GE IC3600LINE1 Light Indicator Board

    • ¥22500.00
      ¥24520.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:4.300KG
    • Quantity:
    • (Inventory: 37)
Description

GE IC3600LINE1 Light Indicator Board


GE IC3600LINE1 Light Indicator Board

Part Number IC3600LINE1 Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark VI/VIe Function Module Availability In StockIC3600LINE1 is a Light Indicator Board manufactured and designed by General Electric as part of the Mark II Series used in GE Speedtronic Control Systems. A light indicator circuit board is an electronic circuit board designed to control and display information using light indicators, typically LEDs (Light Emitting Diodes). These boards are widely used in various applications to convey important information to users or operators in a visual and easily understandable manner.

 LIGHT INDICATOR CIRCUIT BOARD CONSISTS OF SEVERAL KEY COMPONENTS: LEDs: The primary components are the light-emitting diodes (LEDs) that emit light when an electric current passes through them. LEDs are available in various colors, such as red, green, yellow, and blue, allowing for different types of information to be displayed. Control Logic: The circuit board includes control logic, such as microcontrollers or integrated circuits, that process input data and determine the appropriate LEDs to illuminate based on the information received. Input Interface: The circuit board may have input interfaces, such as sensors, switches, or communication ports, to receive data or commands from external sources or systems. Power Supply: A power supply section provides the necessary electric current to illuminate the LEDs on the board.

 Output Drivers: Output drivers, such as transistors or shift registers, are used to control the current flow to the individual LEDs, allowing them to be turned on or off selectively. Protocols and Communication: In some cases, the circuit board may support communication protocols like UART, I2C, or SPI to interface with other devices or systems for data exchange. COMMON APPLICATIONS OF LIGHT INDICATOR CIRCUIT BOARDS INCLUDE: Electronic devices: Indicating power status, battery levels, network connectivity, and system errors in devices like smartphones, laptops, and routers. Automotive systems: Displaying warning lights for low fuel, engine issues, tire pressure, and other vehicle diagnostics. Industrial control systems: Monitoring machine status, process parameters, and safety warnings in manufacturing plants.

SPECIFICATIONS:

Part No: IC3600LINE1
Manufacturer: General Electric
Product Type: Light Indicator Board
Series: Mark II
Operating temperature: -30 to 55 ºC
Power Supply Voltage: 24 V dc
Board Size: 2.8 cm high x 8.6 cm
Weight: 0.45 kg
Availability: In Stock
Country of Origin: USA

Compatibility

ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

 Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module
