GE IC697CPX772 Single-Slot PLC CPU, Control Solutions for Industrial Automation

IC697CPX772 Single-Slot PLC CPU, Control Solutions for Industrial Automation

Product Type:CPU module RAM:512 kilobytes Processor:80486DX4 microprocessor Clock Speed:96 megahertz Voltage Input:5 Volts DC Analog I/O:8 K max Serial Ports:3 Current Input:3.1 Amps Communication Port:One (1) RS232; Two (2) RS485 interface The GE IC697CPX772 is engineered with a powerful 80486DX4 microprocessor clocked at 96 megahertz, providing exceptional processing speed and efficiency, ideal for complex industrial control applications. Equipped with 512 kilobytes of RAM, this CPU ensures ample memory for storing critical data and executing multiple tasks simultaneously, enhancing operational reliability.

 Supporting up to 8 K max of analog I/O, it offers flexible connectivity for a wide range of sensors and actuators, enabling precise control over industrial machinery and processes. With three serial ports including one RS232 and two RS485 interfaces, the IC697CPX772 facilitates seamless communication with various devices, ensuring efficient data exchange within your industrial network. Designed for easy integration, the IC697CPX772 features a compact yet robust form factor, making it suitable for space-constrained environments. It  backed by GE Automation and Controls, ensuring high-quality performance and longevity. The GE IC697CPX772 is a high-performance single-slot CPU module designed for seamless integration into industrial automation systems, providing real-time control and monitoring capabilities.

OTHER INFORMATION

• Celeron™ socket 370-based single-board computer (SBC) with operating  system support for Windows NT®/Windows® 2000, Linux, VxWorks, QNX,  and Solaris

• Special features for embedded applications

— Up to 512 Mbyte IDE CompactFlash (optional)

— Three programmable 16-bit timers

— 32 Kbyte of battery-backed SRAM

— Remote Ethernet booting supported

— Software-selectable watchdog timer with reset

— Supports VMEbus P2 connection to HD/floppy drive

— PMC expansion site with VMEbus P2 I/O

— PC•MIP expansion site supported

— VME64 modes supported: A32/A24/D32/D16/D08(EO)/MBLT64/BLT32

— VMEbus interrupt handler, interrupter, and system controller

— Includes byte-swapping hardware for little-endian and big-endian data  interfacing (patent no. 6,032,212)

— Enhanced bus error handling

— Passive heat sink design (no moving parts)

• Standard features include

— Celeron socket 370 processor

— Up to 256 Mbyte SDRAM using one 144-pin SODIMM

— 64-bit Intel® AGP SVGA controller with 2 Mbyte SGRAM

— On-board Fast Ethernet controller supporting 10BaseT and 100BaseTX  interfaces

— On-board Ultra DMA/33 hard drive and floppy drive controllers with  VMEbus P2 I/O

— Two high-performance 16550-compatible serial ports

— PS/2-style keyboard and mouse port on front panel

— Real-time clock and miniature speaker included
