  • ABB IW93-2 HESG440356R1 HESG216678/B I/O module
    ❤ Add to collection
  • ABB IW93-2 HESG440356R1 HESG216678/B I/O module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

     IW93-2 ("IW" stands for Input/Output Wireless/Wireless, representing wired distributed I/O); 93 "is the specification level, indicating channel configuration and communication capability; '2' represents dual communication port redundancy design), order numbers HESG440356R1 (main model), HESG216678/B (accessory code, including installation bracket and terminal block), compatible with ABB AC 800M, Advant OCS and other systems.

    • ¥15322.00
      ¥18577.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:2.850KG
    • Quantity:
    • (Inventory: 99999)
Description

 IW93-2 ("IW" stands for Input/Output Wireless/Wireless, representing wired distributed I/O); 93 "is the specification level, indicating channel configuration and communication capability; '2' represents dual communication port redundancy design), order numbers HESG440356R1 (main model), HESG216678/B (accessory code, including installation bracket and terminal block), compatible with ABB AC 800M, Advant OCS and other systems.


ABB IW93-2 HESG440356R1 HESG216678/B I/O module

Core positioning and basic parameters of the product

1. Core attributes and identification

Product type: Distributed intelligent I/O module (belonging to ABB Advant Fieldbus series, focusing on industrial field signal acquisition and control, adapted to distributed control systems (DCS) and programmable logic controllers (PLC), especially suitable for signal access of distributed devices in large industrial scenarios)

Model decoding: IW93-2 ("IW" stands for Input/Output Wireless/Wireless, representing wired distributed I/O); 93 "is the specification level, indicating channel configuration and communication capability; '2' represents dual communication port redundancy design), order numbers HESG440356R1 (main model), HESG216678/B (accessory code, including installation bracket and terminal block), compatible with ABB AC 800M, Advant OCS and other systems.

Physical specifications: Adopting a wall mounted and rail mounted dual installation design, with dimensions of 140mm (width) × 220mm (height) × 80mm (depth), net weight of 1.8kg, metal shell protection, suitable for industrial field distribution box installation, supports -25 ℃ low temperature start-up, can be directly deployed in the field area near sensors/actuators, reducing signal transmission loss.

2. Key technical parameters

I/O channel configuration

8 analog inputs (AI, 4-20mA/0-10V, 16 bit resolution), 4 analog outputs (AO, 4-20mA, 12 bit accuracy), 16 digital inputs (DI, 24V DC, optoelectronic isolation), 8 digital outputs (DO, 24V DC/2A, relay output)

Rich channel types, balancing high-precision analog acquisition and digital switch control, suitable for mixed signal scenarios (such as simultaneously collecting temperature and pressure signals and controlling valves and pump groups)

Communication capability

2 Profibus DP interfaces (master/slave mode optional, supporting DPV1 protocol, communication rate adaptive from 1.5Mbps to 12Mbps), 1 RS485 backup interface (supporting Modbus RTU)

Dual Profibus DP ports achieve communication redundancy, avoiding signal interruption caused by single link faults, and adapting to the distributed signal transmission requirements of large systems

Power supply demand

DC 24V ± 15%, rated power consumption 18W, maximum power consumption 25W (at DO full load output)

It can be powered from the on-site distribution box or centrally supplied through the ABB SR511 power module, supporting wide voltage input and adapting to voltage fluctuations in industrial sites

Measurement accuracy

AI: ± 0.1% FS (full range), AO: ± 0.2% FS, DI response time ≤ 1ms, DO output delay ≤ 2ms

The AI channel supports low-temperature drift (≤ 5ppm/℃) to ensure long-term operational accuracy; High speed DI/DO adaptation to high-frequency switch signals (such as motor start stop feedback, solenoid valve control)

Working environment

Temperature -30 ℃ to+70 ℃, humidity 5%~95% (no condensation, supports condensation environment operation), protection level IP65 (shell), IP20 (terminal block)

The shell is designed to be waterproof and dustproof, and can be directly installed outdoors or in damp areas of workshops (such as sewage treatment plants and metallurgical workshops). The wiring terminals need to be matched with waterproof junction boxes for use

Security and Certification

Compliant with IEC 61010-1 safety standard, with anti electromagnetic interference level IEC 61000-6-2 (level 4), CE and UL certification

It can resist strong electromagnetic interference in industrial sites (such as frequency converters and high-voltage equipment), ensure stable signal acquisition and output, and comply with global industrial scenarios for use


Core functions and technological advantages

1. High precision signal acquisition and control

Accurate analog processing: The AI channel adopts a 16 bit Delta Sigma analog-to-digital conversion chip, combined with hardware filtering (configurable 50Hz/60Hz power frequency filtering and 1-100Hz custom filtering), effectively suppressing power grid harmonics and on-site interference. For example, when collecting temperature signals from chemical reaction vessels, the measurement error can be controlled within ± 0.1 ℃; The AO channel supports current/voltage output switching and can directly drive actuators such as regulating valves and frequency converters, with an output accuracy of ± 0.2% FS, meeting the requirements of process regulation.

Digital high-speed response: The DI channel has 2500V AC photoelectric isolation, supports dry/wet contact input, response time ≤ 1ms, and can capture high-speed switch signals (such as product detection signals from production line photoelectric sensors); The DO channel adopts 2A relay output, supports normally open/normally closed contact switching, and can directly control small motors and solenoid valves. The output status is displayed in real time through LED indicator lights, which is convenient for on-site fault diagnosis.

Channel independent configuration: Through ABB Control Builder software, each I/O channel can be independently configured with parameters (such as AI signal type, DI stabilization time, DO output mode), supporting channel fault isolation. When one channel fails, it does not affect the normal operation of other channels, improving the system's fault tolerance.

2. Distributed deployment and redundant reliability

On site deployment: Compared to traditional centralized I/O, IW93-2 can be directly installed in the field area near sensors/actuators (such as workshop equipment, outdoor control cabinets), reducing signal transmission distance (supporting up to 1200m Profibus DP communication), reducing signal attenuation and interference, especially suitable for decentralized equipment signal access in large factories (such as automobile manufacturers and metallurgical plants).

Communication redundancy design: The dual Profibus DP ports support a "one primary, one backup" communication architecture. When the primary port fails, it automatically switches to the backup port with a switching time of ≤ 10ms to ensure uninterrupted signal transmission; The RS485 backup interface can serve as a third-party communication guarantee or be used for local debugging and data reading, further enhancing communication reliability.

Fault self diagnosis and alarm: It has dual diagnostic functions at the channel level and module level, and can monitor AI/AO signal over range, DI/DO open/short circuit, communication interruption, power supply abnormality and other faults in real time. The fault information is uploaded to the controller (such as PM861K01) through Profibus DP, and the module red fault indicator light alarm is triggered at the same time, supporting remote fault location and reducing on-site troubleshooting time.

3. Industrial environment adaptation and usability

Strict environmental protection: The IP65 shell can resist dust and rainwater invasion, suitable for outdoor environments (such as photovoltaic power plant inverter control), humid environments (such as sewage treatment plants), and high dust environments (such as cement plants); -The low-temperature start-up capability of 30 ℃ meets the winter operation needs of cold northern regions, and the high-temperature tolerance of+70 ℃ is suitable for high-temperature workshops such as metallurgy and glass manufacturing.

Convenient wiring and maintenance: using spring type terminal blocks, wire insertion and removal can be completed without tools, increasing wiring efficiency by 50%; The front of the module is equipped with I/O channel status LED indicator lights (green normal, red fault), and operation and maintenance personnel can intuitively judge the working status of the channel; Support hot plugging (requires enabling hot plugging function in the system), without shutting down when replacing modules, reducing system downtime.

Energy consumption optimization design: using low-power components, with a rated power consumption of only 18W, saving about 20% energy compared to similar distributed I/O modules; The DO channel supports "sleep mode" and automatically reduces power consumption when there is no output, making it suitable for battery powered or energy-saving scenarios (such as mobile monitoring devices).


Selection and maintenance precautions

1. Key indicators for selection

Matching of I/O channel requirements: Select based on the type and quantity of on-site signals (analog/digital). If you need AI with less than 8 channels, AO with less than 4 channels, DI with less than 16 channels, DO with less than 8 channels, and require distributed deployment, IW93-2 is preferred; When the number of channels exceeds the limit, multiple modules can be connected in parallel (up to 32 IW93-2 can be connected to the same PM861K01), or higher channel models can be selected (such as IW94-4, 16AI+8AO+32DI+16DO).

Communication and redundancy requirements: Profibus DP communication redundancy, distributed deployment (distance>100m) or harsh environment (IP65 protection, -30 ℃ low temperature) are required, and IW93-2 is the optimal choice; If only basic I/O functionality and centralized deployment are required, the AC 800M series centralized I/O modules (such as AI890, DO890) can be selected, reducing costs by about 30%.

Environmental adaptability assessment: IW93-2 (IP65 protection, wide temperature design) must be selected for outdoor, humid, high dust, and high/low temperature environments; Ordinary control room environments can choose models with lower protection levels (such as IP20), but they need to be used in conjunction with control cabinets.

2. Maintenance and troubleshooting

Regular maintenance procedure: Clean the dust on the module housing every month (wipe with a damp cloth, avoid using corrosive cleaning agents), check the tightness of the wiring terminals and the status of the LED indicator lights; Test communication redundancy switching every quarter (manually disconnect the main Profibus DP cable to verify if the backup port is working properly), calibrate AI channel accuracy (input standard 4mA and 20mA signals, deviation should be ≤ ± 0.1% FS); Inspect the sealing strip of the shell annually and replace it promptly when it ages to ensure IP65 protection performance.

Common troubleshooting

Abnormal AI signal acquisition (out of range/large fluctuations)

Signal cable interference, incorrect channel parameter configuration, sensor malfunction

1. Check if the AI cable is a shielded twisted pair, with the shielding layer grounded at one end (grounding resistance ≤ 1 Ω); 2. Confirm in the software that the AI signal type (4-20mA/0-10V) is configured correctly; 3. Replace the spare sensor for testing and eliminate sensor faults

Communication interruption (Profibus DP)

Cable malfunction, address conflict, incompatible module firmware version

1. Use Profibus testing tool to check cable continuity and signal strength, and replace faulty cables; 2. Confirm that the Profibus address of IW93-2 is not duplicated with other devices in the system; 3. Upgrade the module firmware to a version compatible with PM861K01

DO output has no action (indicator light is not on)

Power failure, output circuit short circuit, relay damage

1. Measure the power supply voltage of the module (normal 24V ± 15%) and check the power circuit; 2. Disconnect the DO load, measure the terminal output voltage, and eliminate the load short circuit; 3. Replace the backup DO channel for testing. If there is still no output, it is judged that the relay is damaged and the module needs to be replaced

The module fault light is always on (red)

Power overvoltage/undervoltage, communication failure, channel failure

1. Measure the input power supply voltage to ensure it is within the range of 24V ± 15%; 2. Check the communication link and eliminate communication interruptions; 3. Check the fault channel through diagnostic software, disable the fault channel or replace the module
