  • YASKAWA JANCD-CP50B Industrial Control Module
    ❤ Add to collection
  • YASKAWA JANCD-CP50B Industrial Control Module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    YASKAWA JANCCD-P50B is a high-performance industrial control module under the Yaskawa brand 3G3JZ series. Its core positioning is communication interaction and distributed control of complex industrial automation systems, with powerful Ethernet communication, multi protocol adaptation, and fieldbus management capabilities. It can achieve high-speed data exchange and collaborative control between control centers, distributed I/O units, and field instruments. This module adopts a modular rack structure design and is compatible with Yaskawa Industrial ™ The distributed I/O modules and fieldbus devices of the system and mainstream brands support redundant configuration and live plugging, with excellent environmental adaptability and operational reliability. They are the core components for improving industrial process control automation, optimizing system expansion flexibility, and ensuring stable and efficient production processes. At present, there is sufficient stock supply of this model module, which can meet diverse needs such as new system construction, upgrading of existing process control systems, and equipment maintenance.

    • ¥25513.00
      ¥26043.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.250KG
    • Quantity:
    • (Inventory: 99999)
Description

YASKAWA JANCCD-P50B is a high-performance industrial control module under the Yaskawa brand 3G3JZ series. Its core positioning is communication interaction and distributed control of complex industrial automation systems, with powerful Ethernet communication, multi protocol adaptation, and fieldbus management capabilities. It can achieve high-speed data exchange and collaborative control between control centers, distributed I/O units, and field instruments. This module adopts a modular rack structure design and is compatible with Yaskawa Industrial ™ The distributed I/O modules and fieldbus devices of the system and mainstream brands support redundant configuration and live plugging, with excellent environmental adaptability and operational reliability. They are the core components for improving industrial process control automation, optimizing system expansion flexibility, and ensuring stable and efficient production processes. At present, there is sufficient stock supply of this model module, which can meet diverse needs such as new system construction, upgrading of existing process control systems, and equipment maintenance.


YASKAWA JANCD-CP50B Industrial Control Module

Product Overview

YASKAWA JANCCD-P50B is a high-performance industrial control module under the Yaskawa brand 3G3JZ series. Its core positioning is communication interaction and distributed control of complex industrial automation systems, with powerful Ethernet communication, multi protocol adaptation, and fieldbus management capabilities. It can achieve high-speed data exchange and collaborative control between control centers, distributed I/O units, and field instruments. This module adopts a modular rack structure design and is compatible with Yaskawa Industrial ™ The distributed I/O modules and fieldbus devices of the system and mainstream brands support redundant configuration and live plugging, with excellent environmental adaptability and operational reliability. They are the core components for improving industrial process control automation, optimizing system expansion flexibility, and ensuring stable and efficient production processes. At present, there is sufficient stock supply of this model module, which can meet diverse needs such as new system construction, upgrading of existing process control systems, and equipment maintenance.


Specification parameters

-Core electrical parameters: rated voltage AC 220V, rated frequency 50/60Hz; equipped with a 32-bit data bus, data transfer rate of 100MB/s, using DMA (direct memory access) method, CPU operating load ≤ 4%; Analog I/O accuracy ≤ 0.1%, ensuring precise execution of data transmission and control instructions.

-Control interface: standard EE802.3 industrial Ethernet interface, optional 10BASE2 thin cable, 10BASE5 thick cable (AUI interface) or 10BASE-T twisted pair communication interface; Supports various fieldbus protocols such as Profibus, CAN, FF, ModBus, etc. It can connect 126 Profibus DP slave stations through a fieldbus interface card, with a communication speed of up to 12MBd. A single module can connect 496 fieldbus devices.

-Output performance: Supports multi-channel parallel data output and control signal output, compatible with S800/S900 series distributed I/O units; Equipped with short-circuit protection function, all I/O can set safety values, and the output signal can be directly connected to on-site transmitters and actuators, meeting the multi device linkage requirements of distributed control systems.

-Certification standards: Passed CE and UL international safety certifications, in compliance with industrial equipment safety operation standards.

-Physical parameters: Weight approximately 1.2kg, size in accordance with DIN standard rail mounting specifications; The protection level reaches IP20, suitable for conventional installation environments inside industrial control cabinets, effectively preventing dust and foreign objects from entering, and suitable for complex industrial environments such as process control workshops and chemical production workshops.


Performance characteristics

-High speed communication and distributed collaborative control: relying on a 32-bit high-speed data bus and industrial Ethernet interface, high-speed data exchange between the control center and field devices is achieved with low communication latency; It supports remote control of distributed I/O units, and can conduct centralized scheduling for decentralized field instruments and actuators, greatly improving system expansion flexibility and reducing cable laying and installation costs; Implementing redundant operations through redundant on-site controllers to ensure control continuity.

-Wide environmental adaptability and high reliability: using industrial grade high stability components and reinforced circuit design, operating temperature range -10 ℃~60 ℃, relative humidity ≤ 90% RH (no condensation); Having excellent resistance to electromagnetic interference and passing electromagnetic compatibility (EMC) testing, it can operate stably in process control scenarios with complex electromagnetic environments and harsh working conditions such as chemical and power industries; Supports power redundancy and can smoothly achieve automatic switching.

-Convenient integration and debugging: Provides detailed installation guidance and simplified setup process, supports seamless compatibility with various industrial automation systems, and can efficiently complete integration whether building new systems or upgrading old systems.

-Comprehensive fault diagnosis and convenient maintenance: All modules have fault self diagnosis function and are equipped with LED fault display, which can detect communication abnormalities, I/O signal abnormalities, power failures and other status in real time, and send alarm signals through communication interfaces; Support live plugging and online replacement, modules can be automatically identified, and maintenance can be completed without stopping the machine, greatly reducing downtime losses; Support real-time storage and export of operational data, providing data support for system maintenance and production optimization.

-Safety compliance: Complies with international safety standards and electromagnetic compatibility requirements, comes with a comprehensive electrical protection design, and reduces equipment operational risks.


Working principle

YASKAWA JANCD-CP50B industrial control module, as the core communication and control unit of complex industrial automation system, its working principle is based on the whole process control logic of "centralized scheduling distributed execution high-speed communication state feedback fault self diagnosis". Firstly, the module receives control commands from the upper control center (engineer station, operation station) through the industrial Ethernet interface, and also receives field instrument signals (such as temperature, pressure, flow rate, etc.) transmitted by distributed I/O units through fieldbus interface cards (Profibus, CAN, etc.); Subsequently, the internal 32-bit processor uses DMA to perform high-speed parsing and processing of instructions and signals, reducing CPU load while ensuring data processing efficiency and generating accurate control instructions; Next, control instructions are transmitted to each distributed I/O unit through the fieldbus to drive the field actuators to operate according to the set parameters; At the same time, the module provides real-time feedback on the operating status of on-site equipment, I/O signal status, and other data to the upper control center, achieving centralized monitoring; In addition, the internal fault self diagnostic circuit continuously monitors the operating status of the module and connected devices. Once an abnormality is detected, it will sound an alarm through the LED indicator light and record the fault information. It supports live plugging and unplugging maintenance to ensure the continuous and stable operation of the system.


Precautions

-Voltage matching and power protection: Before installation, it is necessary to confirm that the power supply voltage is consistent with the rated voltage of the module (AC 220V) to avoid voltage fluctuations beyond the allowable range; It is recommended to install a surge protector at the power input end to prevent damage to the internal circuit of the module caused by grid surge voltage; If configuring power redundancy, it is necessary to ensure that the parameters of the two power sources are consistent to ensure smooth switching; When not in use for a long time, the power should be disconnected to avoid component aging caused by standby current.

-Safety operation regulations: When wiring, repairing or replacing components, the power must be disconnected first, and touching the terminals while powered on is strictly prohibited to prevent electric shock accidents.

-Correct wiring and communication configuration: Strictly distinguish power interfaces, Ethernet interfaces, fieldbus interfaces, and I/O interfaces according to the wiring manual, strictly prohibit misconnection or mixing, and avoid permanent damage to the module; Ensure that the terminals are securely fastened during wiring to prevent loose connections or communication interruptions; Special shielded cables should be selected for communication cables according to the protocol requirements. The distance between power cables and signal cables should be ≥ 300mm to reduce signal interference; Parameters such as fieldbus address and communication rate need to be accurately configured according to system configuration requirements to ensure compatibility in multi device communication.

-Standardize grounding settings: The grounding terminals must be strictly connected according to local grounding regulations to avoid sharing grounding with welding machines, motors, and other equipment. When multiple modules are used side by side, they must be independently grounded, and grounding wire circuits are prohibited to prevent electric shock or fire risks.

-Professional operation: The parameter setting, system integration, and fault maintenance of modules need to be completed by professional technicians to avoid system failures or equipment damage caused by non professional operations.
