YASKAWA MB-01 Integrated Ethernet PLC Module

YASKAWA MB-01 Integrated Ethernet PLC Module

Product Overview

YASKAWA MB-01 is an integrated Ethernet PLC module launched by Yaskawa (YASKAWA) brand. Its core positioning is centralized control and network interconnection of general industrial automation systems, with reliable instruction processing, high-speed Ethernet communication, and multi device collaborative control capabilities. It can achieve seamless integration with upper computers, distributed I/O units, intelligent instruments, actuators, and other equipment, accurately transmitting control instructions and equipment operation data. This PLC module adopts a modular architecture design, compatible with the entire range of Yaskawa industrial control systems and mainstream automation equipment. It supports rail installation and flexible expansion, and has excellent anti-interference and environmental adaptability. It is a core control unit that enhances the network interconnection capability of industrial control systems, optimizes control processes, and ensures stable and efficient production processes. At present, there is sufficient stock supply of this model of PLC module, which can meet diverse needs such as new system construction, upgrading of existing automation equipment networks, and equipment maintenance.

Core specification parameters

-Core electrical parameters: rated input voltage DC 24V, rated power consumption ≤ 15W; equipped with high-performance industrial control processor, instruction processing speed up to 0.2 μ s/step, supporting multi device collaborative control; Working temperature range -10 ℃~60 ℃, relative humidity ≤ 90% RH (no condensation), suitable for complex industrial workshop electromagnetic environment, ensuring stable operation; Supports 8-16 point digital input/output expansion, which can match various low to medium power industrial load control requirements.

-Communication interface and protocol: Integrated 10/100M adaptive Ethernet interface, supporting mainstream industrial Ethernet protocols such as TCP/IP, UDP, Modbus TCP, etc; Standard RS-485 communication interface, compatible with Modbus RTU protocol; Equipped with Ethernet remote programming and monitoring functions, it can realize remote uploading and downloading of control programs and remote monitoring of device operation status. At the same time, it supports seamless interconnection with PLC, touch screen, and upper management system, and flexibly integrates into various industrial automation network architectures.

-Control and Communication Performance: Supports basic PLC control functions such as logic control, sequential control, and timed counting, which can meet the control requirements of general industrial scenarios; Ethernet communication latency is as low as 10ms, data transmission rate reaches 100Mbps, built-in data caching and verification mechanism, data transmission error rate ≤ 10 ⁻⁹, ensuring the integrity and accuracy of control instructions and operational data; Equipped with network fault detection and reconnection functions, ensuring stable and reliable communication links.

-Protection and expansion parameters: Built in overvoltage protection, undervoltage protection, short circuit protection, electromagnetic interference suppression circuit, can quickly respond to various electrical abnormalities, protect the safety of PLC modules and related equipment; Equipped with multiple expansion slots, compatible with digital I/O expansion modules and analog acquisition/output modules, to meet the functional expansion needs of different scenarios; Supports SD card data storage, enabling control program backup and running log recording.

-Physical parameters: Weight approximately 500g, size in accordance with industrial control cabinet standard installation specifications (100 × 150 × 80mm); The protection level reaches IP20, suitable for installation environment inside industrial control cabinets, effectively preventing dust and foreign objects from entering; The installation method supports standard 35mm rail installation and is suitable for various industrial scenarios such as general mechanical processing, electronic manufacturing, and municipal engineering.

Core Advantage Characteristics

-Integrated Ethernet and Remote Control: Leveraging the integrated 10/100M adaptive Ethernet interface, seamless integration between PLC modules and industrial networks is achieved, supporting remote programming, monitoring, and maintenance, reducing on-site debugging and operation costs; Through protocols such as Modbus TCP, data exchange can be achieved with multiple network node devices, enabling centralized control and information integration of industrial control systems.

-Multi protocol compatibility and flexible interconnection: By combining Ethernet and RS-485 dual communication interfaces, it is compatible with multiple industrial communication protocols, enabling seamless interconnection with different brands and types of industrial equipment without the need for customized development, reducing system integration complexity; Support interconnection with touch screens, upper computers, and cloud platforms, facilitating visual management and data analysis of production data.

-Strong environmental adaptability and high reliability: using industrial grade high stability components and anti-interference circuit design, it has excellent electromagnetic interference suppression ability. Through electromagnetic compatibility (EMC) testing, it can operate stably in complex industrial workshop environments with strong electromagnetic and high dust; The comprehensive electrical protection function can cope with various electrical abnormalities and operational failures, significantly reducing the probability of equipment damage; Has good adaptability to power fluctuations, adapts to slight voltage fluctuations in industrial power grids, and ensures the continuous and reliable operation of the control system.

-Comprehensive fault diagnosis and convenient maintenance: equipped with comprehensive fault self diagnosis function, it can detect power failure, communication abnormality, expansion module failure, I/O signal abnormality and other states in real time, send alarm signals through LED indicator lights and communication interfaces, and record detailed fault codes and fault logs; Support SD card data backup and recovery, key parameters can be quickly imported and exported; Modular design facilitates later replacement and maintenance, allowing for easy maintenance without the need for a complete shutdown, significantly reducing downtime losses.

-Modular design and flexible expansion: Adopting a modular architecture, expansion modules can be flexibly configured according to the requirements of the control system, achieving on-demand expansion of I/O points and functions; Compatible with the entire range of Yaskawa industrial control software, supporting secondary development of control logic, and adapting to personalized production needs of different industries; Supports multiple programming languages for engineers to quickly develop and debug.

Applicable scenarios

-General industrial control scenario: suitable for control systems of general machinery such as machine tools, conveying machinery, packaging equipment, etc., responsible for logical control, sequential control, and status monitoring of equipment. It is interconnected with the upper computer through Ethernet to improve control efficiency and management convenience.

-Industrial network monitoring system: a widely used network monitoring system in industrial production workshops, which realizes centralized control of multiple PLC modules through Ethernet, collects real-time equipment operation data and uploads it to the monitoring center, realizing visual management and abnormal warning of the production process.

-Existing equipment network upgrade: In response to the bottleneck of the lack of network interconnection capability in existing industrial control systems, old PLC modules can be directly replaced and upgraded to YASKAWA MB-01 integrated Ethernet PLC modules to achieve networked transformation of the control system, improve remote control capabilities and data integration efficiency, and adapt to the development needs of modern industrial Internet of Things.

-Municipal and Light Industry Automation Scenarios: Suitable for automation scenarios such as municipal water supply and power supply equipment, food processing production lines, textile printing and dyeing equipment, etc. Through reliable control and network communication capabilities, stable operation and centralized management of equipment are achieved, improving production efficiency and operational convenience.
