  • FOXBORO P0926KL control module
    ❤ Add to collection
  • FOXBORO P0926KL control module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    The module has strong signal compatibility and can adapt to various common input types in industrial scenarios, including resistance temperature detectors (RTDs), thermocouples, milliampere (mA), millivolt (mV), voltage (V), and ohm signals.

    • ¥10674.00
      ¥13463.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:1.000KG
    • Quantity:
    • (Inventory: 99999)
Description

The module has strong signal compatibility and can adapt to various common input types in industrial scenarios, including resistance temperature detectors (RTDs), thermocouples, milliampere (mA), millivolt (mV), voltage (V), and ohm signals.


FOXBORO P0926KL control module

Core technical parameters

As a dual input single output (DI SO) control module, P0926KL excels in signal processing, precision control, and environmental adaptability. The key technical parameters are as follows:

1. Signal input characteristics

The module has strong signal compatibility and can adapt to various common input types in industrial scenarios, including resistance temperature detectors (RTDs), thermocouples, milliampere (mA), millivolt (mV), voltage (V), and ohm signals. For the measurement requirements of different process variables, the input range coverage is as follows:

-Temperature: -200 ℃~1767 ℃ (corresponding to -328 ℉~3212 ℉)

-Pressure: 0~69 bar (corresponding to 0~1000 psi)

-Flow rate: 0~227 cubic meters per hour (corresponding to 0~1000 gpm)

-Liquid level: 0~305 meters (corresponding to 0~1000 feet)

2. Output and accuracy indicators

The module adopts standard industrial control signal output, with an output type of 4-20mA DC signal and an output accuracy of ± 0.1% of the range, ensuring the precise transmission of control instructions. Fast response speed, signal processing delay less than 100 milliseconds, able to provide timely feedback on process variable changes and execute control actions.

3. Power supply and physical characteristics

The power supply supports 24V DC (typical value), and some models are compatible with 79-180V AC input, meeting the power supply conditions of different industrial sites. In terms of physical dimensions, the standard specification is about 330 × 350 × 65 millimeters, weighing 1.6 kilograms, and shipping weight is about 3.6 pounds, making it easy to install and deploy in a standard control cabinet. The internal storage configuration includes 300KB of basic memory, with some versions expanding to 16MB SDRAM and 32MB flash memory, supporting program storage and data caching.

4. Environmental adaptability

The module has undergone rigorous industrial environment adaptability design, with a working and storage temperature range of -40 ℃~85 ℃. In some application scenarios, it can operate stably in an environment of 0~60 ℃. Has a certain anti-interference ability, can maintain signal stability in industrial electromagnetic environments, and is suitable for complex on-site conditions.


Typical application scenarios

Based on its multi signal processing capability and high reliability, FOXBORO P0926KL is widely used in various industrial automation control scenarios, with core application areas including:

1. Oil and gas industry: used for key processes such as wellhead pressure monitoring, pipeline flow control, and tank level measurement to ensure the safety and stability of extraction and transportation processes.

2. In the field of chemical and petrochemical engineering: adapt to processes such as temperature control of reaction vessels, adjustment of material ratio and flow rate, and tolerate corrosive gas environments in chemical workshops (with protective measures in place).

3. Power production industry: applied to boiler water level control, steam pressure monitoring, auxiliary system regulation of generator sets, etc., to ensure the efficiency and safety of the power generation process.

4. Pulp and paper industry: used for pulp concentration measurement, paper machine speed control, wastewater treatment process parameter monitoring, and other processes.

5. Food and beverage processing: Adapt temperature, liquid level, and flow control during the production process to meet the hygiene and safety requirements of the food industry.

This module mainly undertakes the core functions of process variable acquisition, signal conversion processing, and control instruction output in these fields, and is a key connection node between DCS system and on-site execution mechanism.


Installation and operation specifications

To ensure stable operation and extend the service life of the module, the following installation, operation, and maintenance specifications must be strictly followed:

1. Installation environment requirements

The installation location should avoid high temperature direct exposure, high humidity water accumulation, strong vibration, and corrosive gas accumulation areas. It is recommended to install it inside the control cabinet and equip it with ventilation and heat dissipation devices. The control cabinet should be kept away from strong electromagnetic interference sources (such as large motors and transformers), and the installation distance between modules and other equipment should meet the requirements of heat dissipation and operating space.

2. Electrical connection specifications

The connection between power and signal lines must strictly follow the wiring guidelines provided by the manufacturer, distinguish between input, output, and power terminals, and avoid module damage caused by misconnection. The power line should have overload protection function, and the signal line should use shielded cables to reduce electromagnetic interference. After the wiring is completed, it is necessary to check the tightness of the connector to prevent poor contact from causing signal abnormalities.

3. System integration and software adaptation

The module needs to be compatible with DCS systems such as FOXBORO I/A Series to ensure that the programming and configuration software versions match and avoid software conflicts. When integrated into existing systems, accurate input of configuration information is required, including parameter settings such as input signal type, range, and output correspondence. In redundant systems, it is necessary to confirm the correct connection of redundant terminal wires to avoid the inability to switch normally in standby mode.

4. Maintenance and safe operation

-Daily maintenance requires regular cleaning of module surfaces and connectors, checking for circuit integrity and loose terminals. It is recommended to develop a periodic maintenance plan.

-Firmware updates should be performed in the event of a power outage or system backup, strictly following the update process to prevent module failures caused by update failures.

-During the operation, it is necessary to comply with the safety regulations for high-voltage power supply and high current. In case of module failure, the power supply should be cut off before maintenance to avoid the risk of electric shock.

-When signing for and storing, it is necessary to check the integrity of the packaging to avoid module damage or moisture. When idle, it should be stored in a dry and ventilated environment.
